liquid aluminum electrolytic capacitor
VKM(R)D1002G4R7MVTM
Mass ProductionVKM(R) Series · SMD
Miniaturizedhigh capacitance densityhigh ripple current capabilitylow temperature riselow leakage currentRoHS compliant
Rated Voltage (V)
400 V
Nominal Capacitance
4.7 µF
Operating Temp
-40 ~ 105 ℃
ESR (max)
23.5 Ω
Rated Lifetime
10000 h
Package Size
ø8 × 10 mm
Online Store
Min. Order Qty:500
Package:SMD
No online store link available for this part number
Detailed Specifications
Capacitor Categoryliquid aluminum electrolytic capacitor
ShapeSMD
Part NumberVKM(R)D1002G4R7MVTM
SeriesVKM(R)
Lifecycle StatusMass Production
Rated Voltage (V)400
Nominal Capacitance4.7 µF
ESR (max.)23.5 Ω
PolarityPolarized
Min Operating Temp (°C)-40
Max Operating Temp (°C)105
Rated Lifetime (Hours)10000
Rated Ripple Current140 mArms
ESR Frequency100 kHz
Diameter D (mm)8
Height L (mm)10
Terminal Pitch (mm)3.1±0.2
Min. Package Qty500
Tolerance-20%~+20%
Leakage Current (µA) Max47.6
Dissipation Factor (tanδ max.)15
Terminal Plating Materialtin
Weight (g)0.1
Dissipation Factor Frequency (Hz)120
Remarks—
Product Dimensions & Electrical Parameters
Actual dimensions and electrical parameters for this part number
Dimensions (unit: mm)
| Dimension | Symbol | Value (mm) |
|---|---|---|
| Diameter (D) | D | 8 |
| Height (L) | L | 10 |
Electrical Parameters
| Rated Ripple Current | Ripple Test Condition | ESR | ESR Frequency |
|---|---|---|---|
| 140 mArms | — | 23.5 Ω | 100 kHz |
