Found 670 results
| Compare | Package Form | Product Image | Product Line | Lifecycle Status | Polarity | Tolerance | Operating Temp. (℃) | Rated Life (Hours) | ESR (max.) | ESR Frequency | Rated Ripple Current | 72h Leakage Current (μA) | Max Charge Voltage (V) | Max Charge Current (A) | Peak Current (A) | Continuous Current (A) | Terminal Pitch (mm) | Terminal Material | Weight | Min. Package Qty | Feature Tags | Remark | Dimension L (mm) | AEC-Q200 | 3D-CAD | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Custom Module |  | Electric Double-Layer Supercapacitor | SDM10.8V3.75FRCA | SDM | Mass Production | polarized | 10.8 V | 3.75 F | 0%~+30% | -40 ~ 85 ℃ | 1000 h | 260 mΩ | 1 kHz | 0 mArms | 90 µA | 10.8 V | 3.4 A | 5 A | 3.4 A | 50 mm | tin | 40 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 18 mm | 55 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM10.8V40FREA | SDM | Mass Production | polarized | 10.8 V | 40 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 120 mΩ | 1 kHz | 0 mArms | 860 µA | 10.8 V | 3 A | 5 A | 3 A | 2.54 mm | tin | 150 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 23 mm | 95 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM10.8V40FREB | SDM | Mass Production | polarized | 10.8 V | 40 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 120 mΩ | 1 kHz | 0 mArms | 860 µA | 10.8 V | 3 A | 5 A | 3 A | 3.96 mm | tin | 150 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 23 mm | 95 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM10.8V40FREC | SDM | Mass Production | polarized | 10.8 V | 40 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 120 mΩ | 1 kHz | 0 mArms | 860 µA | 10.8 V | 3 A | 5 A | 3 A | 7.92 mm | tin | 150 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 23 mm | 95 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM10V117FREA | SDM | Mass Production | polarized | 10 V | 117 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 35 mΩ | 1 kHz | 0 mArms | 2540 µA | 10.8 V | 3 A | 5 A | 3 A | 3.96 mm | tin | 410 g | 24 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 36 mm | 142 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM10V50FREA | SDM | Mass Production | polarized | 10 V | 50 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 55 mΩ | 1 kHz | 0 mArms | 1000 µA | 10.8 V | 3 A | 5 A | 3 A | 3.96 mm | tin | 210 g | 16 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 32 mm | 122 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM12.5V0.2FRLA | SDM | Mass Production | polarized | 12.5 V | 0.2 F | 0%~+30% | -40 ~ 70 ℃ | 1000 h | 1000 mΩ | 1 kHz | 0 mArms | 35 µA | 13.5 V | 0.2 A | 1 A | 0.2 A | 37.5 mm | tin | 5 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 16 mm | 43 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM12V1.25FRCA | SDM | Mass Production | polarized | 12 V | 1.25 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 420 mΩ | 1 kHz | 0 mArms | 30 µA | 12 V | 1.2 A | 2.5 A | 1.2 A | 39 mm | tin | 40 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 16 mm | 44 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM12V2.5FRCA | SDM | Mass Production | polarized | 12 V | 2.5 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 350 mΩ | 1 kHz | 0 mArms | 60 µA | 12 V | 2 A | 4 A | 2 A | 39 mm | tin | 40 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 16 mm | 44 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM12V2.5FREA | SDM | Mass Production | polarized | 12 V | 2.5 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 350 mΩ | 1 kHz | 0 mArms | 120 µA | 12 V | 2 A | 4 A | 2 A | 2 mm | tin | 40 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 21.5 mm | 22.5 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM12V2FRDA | SDM | Mass Production | polarized | 12 V | 2 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 240 mΩ | 1 kHz | 0 mArms | 27 µA | 13.5 V | 2.4 A | 8.8 A | 2.4 A | 2.54 mm | tin | 45 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 10 mm | 75 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM12V3.5FRCA | SDM | Mass Production | polarized | 12 V | 3.5 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 200 mΩ | 1 kHz | 0 mArms | 90 µA | 12 V | 3.8 A | 10 A | 3.8 A | 50 mm | tin | 40 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 18 mm | 55 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM12V3.75FRCA | SDM | Mass Production | polarized | 12 V | 3.75 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 200 mΩ | 1 kHz | 0 mArms | 60 µA | 12 V | 3.8 A | 10 A | 3.8 A | 50 mm | tin | 40 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 18 mm | 55 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM12V3.75FRCA-EG | SDM | Mass Production | polarized | 12 V | 3.75 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 200 mΩ | 1 kHz | 0 mArms | 60 µA | 12 V | 3.8 A | 10 A | 3.8 A | 50 mm | tin | 40 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 18 mm | 55 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM12V30FRCA | SDM | Mass Production | polarized | 12 V | 30 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 80 mΩ | 1 kHz | 0 mArms | 720 µA | 12 V | 10 A | 20 A | 10 A | 81 mm | tin | 152 g | 12 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 29 mm | 93 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM12V40FRCA | SDM | Mass Production | polarized | 12 V | 40 F | 0%~+30% | -40 ~ 70 ℃ | 1000 h | 60 mΩ | 1 kHz | 0 mArms | 960 µA | 12 V | 10 A | 20 A | 10 A | 81 mm | tin | 172 g | 12 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 29 mm | 93 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM13.5V40FRYA | SDM | Mass Production | polarized | 13.5 V | 40 F | 0%~+30% | -40 ~ 70 ℃ | 1000 h | 34 mΩ | 1 kHz | 0 mArms | 1000 µA | 13.5 V | 7 A | 30 A | 7 A | 0 mm | tin | 270 g | 12 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 32 mm | 162 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM13.5V5FREB | SDM | Mass Production | polarized | 13.5 V | 5 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 180 mΩ | 1 kHz | 0 mArms | 135 µA | 13.5 V | 3 A | 5 A | 3 A | 2 mm | tin | 65 g | 60 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 16 mm | 97 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM13.5V5FREC | SDM | Mass Production | polarized | 13.5 V | 5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 150 mΩ | 1 kHz | 0 mArms | 240 µA | 13.5 V | 3 A | 5 A | 3 A | 2.54 mm | tin | 50 g | 60 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 17.5 mm | 85 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM13.5V7FREA | SDM | Mass Production | polarized | 13.5 V | 7 F | 0%~+30% | -40 ~ 85 ℃ | 1000 h | 160 mΩ | 1 kHz | 0 mArms | 115 µA | 13.5 V | 7 A | 15 A | 7 A | 3.96 mm | tin | 100 g | 36 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 17 mm | 83 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM14V26FTDA | SDM | Mass Production | polarized | 14 V | 26 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 105 mΩ | 1 kHz | 0 mArms | 860 µA | 16.2 V | 5 A | 8 A | 5 A | 8.9 mm | tin | 480 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 65 mm | 110 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM14V78FTDA | SDM | Mass Production | polarized | 14 V | 78 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 60 mΩ | 1 kHz | 0 mArms | 2540 µA | 16.2 V | 15 A | 80 A | 15 A | 8.5 mm | tin | 900 g | 12 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 90 mm | 165 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM15V1.66FRLA | SDM | Mass Production | polarized | 15 V | 1.66 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 210 mΩ | 1 kHz | 0 mArms | 190 µA | 16.2 V | 2.15 A | 7 A | 2.15 A | 70 mm | tin | 30 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 13.5 mm | 78 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM16.2V0.55FRYA | SDM | Mass Production | polarized | 16.2 V | 0.55 F | 0%~+30% | -40 ~ 85 ℃ | 1000 h | 500 mΩ | 1 kHz | 0 mArms | 38 µA | 16.2 V | 0.8 A | 3 A | 0.8 A | 0 mm | tin | 9 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 9 mm | 52 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM16V78FTDA | SDM | Mass Production | polarized | 16 V | 78 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 40 mΩ | 1 kHz | 0 mArms | 2540 µA | 16.2 V | 20 A | 80 A | 20 A | 8.5 mm | tin | 900 g | 12 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 90 mm | 165 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM2.7V50FLCA | SDM | Mass Production | polarized | 2.7 V | 50 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 40 mΩ | 1 kHz | 0 mArms | 165 µA | 2.7 V | 8.5 A | 18 A | 8.5 A | 15 mm | tin | 18 g | 60 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 18.5 mm | 38 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM20V25FRYA | SDM | Mass Production | polarized | 20 V | 25 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 70 mΩ | 1 kHz | 0 mArms | 1080 µA | 21.6 V | 8 A | 40 A | 8 A | 0 mm | tin | 420 g | 8 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 61 mm | 145 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V15FLYA | SDM | Mass Production | polarized | 27 V | 15 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 130 mΩ | 1 kHz | 0 mArms | 810 µA | 27 V | 22 A | 40 A | 22 A | 0 mm | tin | 350 g | 16 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 56 mm | 150 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V15FRYA | SDM | Mass Production | polarized | 27 V | 15 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 130 mΩ | 1 kHz | 0 mArms | 810 µA | 27 V | 22 A | 40 A | 22 A | 0 mm | tin | 350 g | 16 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 56 mm | 150 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V20FRYA | SDM | Mass Production | polarized | 27 V | 20 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 110 mΩ | 1 kHz | 0 mArms | 1080 µA | 27 V | 15 A | 30 A | 15 A | 0 mm | tin | 500 g | 10 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 61 mm | 168.5 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V22FRYA | SDM | Mass Production | polarized | 27 V | 22 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 105 mΩ | 1 kHz | 0 mArms | 1080 µA | 27 V | 15 A | 30 A | 15 A | 0 mm | tin | 520 g | 10 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 61 mm | 168.5 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V27FRYA | SDM | Mass Production | polarized | 27 V | 27 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 100 mΩ | 1 kHz | 0 mArms | 1460 µA | 27 V | 15 A | 30 A | 15 A | 0 mm | tin | 560 g | 10 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 61 mm | 168.5 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V40FRDA | SDM | Mass Production | polarized | 27 V | 40 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 98 mΩ | 1 kHz | 0 mArms | 2160 µA | 27 V | 20 A | 75 A | 20 A | 5.08 mm | tin | 960 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 126 mm | 140 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V47FRDA | SDM | Mass Production | polarized | 27 V | 47 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 95 mΩ | 1 kHz | 0 mArms | 2540 µA | 27 V | 20 A | 75 A | 20 A | 5.08 mm | tin | 960 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 90 mm | 205 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V47FRDB | SDM | Mass Production | polarized | 27 V | 47 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 95 mΩ | 1 kHz | 0 mArms | 2540 µA | 27 V | 20 A | 75 A | 20 A | 5.08 mm | tin | 980 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 126 mm | 140 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V54FRDA | SDM | Mass Production | polarized | 27 V | 54 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 90 mΩ | 1 kHz | 0 mArms | 2900 µA | 27 V | 20 A | 75 A | 20 A | 5.08 mm | tin | 980 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 90 mm | 205 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V54FTDA | SDM | Mass Production | polarized | 27 V | 54 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 40 mΩ | 1 kHz | 0 mArms | 2900 µA | 27 V | 30 A | 50 A | 30 A | 10.5 mm | tin | 2000 g | 1 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 140 mm | 190 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V6FLYA | SDM | Mass Production | polarized | 27 V | 6 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 300 mΩ | 1 kHz | 0 mArms | 325 µA | 27 V | 9.8 A | 23 A | 9.8 A | 0 mm | tin | 255 g | 14 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 40 mm | 106 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM27V7FREA | SDM | Mass Production | polarized | 27 V | 7 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 250 mΩ | 1 kHz | 0 mArms | 375 µA | 27 V | 15 A | 38 A | 15 A | 5 mm | tin | 310 g | 14 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 52 mm | 120 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM29.7V13.6FRYA | SDM | Mass Production | polarized | 29.7 V | 13.6 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 140 mΩ | 1 kHz | 0 mArms | 810 µA | 29.7 V | 20 A | 40 A | 20 A | 0 mm | tin | 400 g | 30 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 51 mm | 178 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM29.7V3.6FRYA | SDM | Mass Production | polarized | 29.7 V | 3.6 F | 0%~+30% | -40 ~ 70 ℃ | 1000 h | 220 mΩ | 1 kHz | 0 mArms | 220 µA | 29.7 V | 7.9 A | 20 A | 7.9 A | 0 mm | tin | 300 g | 24 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 38 mm | 140 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM29.7V5.45FRYA | SDM | Mass Production | polarized | 29.7 V | 5.45 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 130 mΩ | 1 kHz | 0 mArms | 325 µA | 29.7 V | 12 A | 30 A | 12 A | 0 mm | tin | 380 g | 24 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 38 mm | 140 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM3.0V200FLCA | SDM | Mass Production | polarized | 3 V | 200 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 8 mΩ | 1 kHz | 0 mArms | 1200 µA | 3 V | 41 A | 94 A | 41 A | 17 mm | tin | 45 g | 40 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 30 mm | 35 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM3.0V200FLCB | SDM | Mass Production | polarized | 3 V | 200 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 8 mΩ | 1 kHz | 0 mArms | 1200 µA | 3 V | 41 A | 94 A | 41 A | 17 mm | tin | 45 g | 40 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 30 mm | 35 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM3.0V300FLCA | SDM | Mass Production | polarized | 3 V | 300 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 6 mΩ | 1 kHz | 0 mArms | 1800 µA | 3 V | 58 A | 121 A | 58 A | 17 mm | tin | 45 g | 40 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 30 mm | 55 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM30V11FRYA | SDM | Mass Production | polarized | 30 V | 11 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 125 mΩ | 1 kHz | 0 mArms | 720 µA | 33 V | 24 A | 60 A | 24 A | 0 mm | tin | 760 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 62 mm | 91 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM30V11FRYA-E2508 | SDM | Mass Production | polarized | 30 V | 11 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 125 mΩ | 1 kHz | 0 mArms | 720 µA | 33 V | 24 A | 60 A | 24 A | 0 mm | tin | 760 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 62 mm | 91 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM30V11FRYA-E2512 | SDM | Mass Production | polarized | 30 V | 11 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 125 mΩ | 1 kHz | 0 mArms | 720 µA | 33 V | 24 A | 60 A | 24 A | 0 mm | tin | 760 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 62 mm | 91 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM30V15FRYA | SDM | Mass Production | polarized | 30 V | 15 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 120 mΩ | 1 kHz | 0 mArms | 900 µA | 30 V | 20 A | 35 A | 20 A | 0 mm | tin | 480 g | 30 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 61 mm | 168.5 mm | — | Apply | ||
| Custom Module | | Electric Double-Layer Supercapacitor | SDM30V16.6FRDA | SDM | Mass Production | polarized | 30 V | 16.6 F | 0%~+30% | -40 ~ 70 ℃ | 1000 h | 120 mΩ | 1 kHz | 0 mArms | 1100 µA | 32.4 V | 20 A | 30 A | 20 A | 5.08 mm | tin | 550 g | 20 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 81 mm | 130 mm | — | Apply |
