Filters1

Stacked Polymer Solid Aluminum Electrolytic

Clear All Filters

Found 156 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	Dimension L (mm)	Width W (mm)	Dimension H (mm)	Terminal Pitch (mm)	Terminal Material	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		SMD	MPX471M0ED194R5R	MPX	Mass Production	Polarized	2.5 V	470 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	4.5 mΩ	100 kHz	8500 mArms	117.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.145 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	✓		Apply
		SMD	MPD101M1CD19030R	MPD19	Mass Production	Polarized	16 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	30 mΩ	100 kHz	3500 mArms	160 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.136 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPX221M0LD19012R	MPX	Mass Production	Polarized	6.3 V	220 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	12 mΩ	100 kHz	5600 mArms	138.6 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.138 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	✓		Apply
		SMD	MPX471M0ED19003RC	MPX	Mass Production	Polarized	2.5 V	470 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	3 mΩ	100 kHz	10200 mArms	117.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.147 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	✓		Apply
		SMD	MPD680M1DD19040R	MPD19	Mass Production	Polarized	20 V	68 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	136 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.139 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD221M1CD28040R	MPD28	Mass Production	Polarized	16 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	352 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD470M1CD19055R	MPD19	Mass Production	Polarized	16 V	47 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	55 mΩ	100 kHz	2700 mArms	75.2 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.131 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD4R7M2AD28040R	MPD28	Mass Production	Polarized	100 V	4.7 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	47 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD150M1HD28045R	MPD28	Mass Production	Polarized	50 V	15 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	45 mΩ	100 kHz	3000 mArms	75 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD100M1HD19045R	MPD19	Mass Production	Polarized	50 V	10 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	45 mΩ	100 kHz	3000 mArms	50 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.143 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD220M1DD15065R	MPD15	Mass Production	Polarized	20 V	22 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	65 mΩ	100 kHz	2500 mArms	44 µA	6	7.3 mm	4.3 mm	1.5 mm	6 mm	Ni/Sn	0 g	4000	Polarized, thin profile, laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	—		Apply
		SMD	MPD221M0LD19006R	MPD19	Mass Production	Polarized	6.3 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	6 mΩ	100 kHz	7500 mArms	138.6 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.138 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD331M1AD28025R	MPD28	Mass Production	Polarized	10 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	25 mΩ	100 kHz	3800 mArms	330 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.187 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD330M1ED19080R	MPD19	Mass Production	Polarized	25 V	33 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	80 mΩ	100 kHz	2200 mArms	82.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.134 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD101M1AD19025R	MPD19	Mass Production	Polarized	10 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	25 mΩ	100 kHz	3800 mArms	100 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.134 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD331M0JD19018R	MPD19	Mass Production	Polarized	4 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	18 mΩ	100 kHz	4600 mArms	132 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.135 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD470M1CD10030R	MPD10	Mass Production	Polarized	16 V	47 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	30 mΩ	100 kHz	3500 mArms	75.2 µA	6	7.3 mm	4.3 mm	1 mm	6 mm	Ni/Sn	0 g	4000	Ultra-thin, laminated structure, low ESR, high ripple current, wide temp., high capacitance, RoHS compliant	—		Apply
		SMD	MPD151M0JD19007R	MPD19	Mass Production	Polarized	4 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	7 mΩ	100 kHz	7000 mArms	60 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.133 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD470M1DD19045R	MPD19	Mass Production	Polarized	20 V	47 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	45 mΩ	100 kHz	3000 mArms	94 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.134 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD151M1CD28050R	MPD28	Mass Production	Polarized	16 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	2800 mArms	240 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.181 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD680M1CD19090R	MPD19	Mass Production	Polarized	16 V	68 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	90 mΩ	100 kHz	2100 mArms	108.8 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.139 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD221M0ED19045R	MPD19	Mass Production	Polarized	2.5 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	45 mΩ	100 kHz	3000 mArms	55 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.134 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD221M0DD10009R	MPD10	Mass Production	Polarized	2 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	44 µA	6	7.3 mm	4.3 mm	1 mm	6 mm	Ni/Sn	0 g	4000	Ultra-thin, laminated structure, low ESR, high ripple current, wide temp., high capacitance, RoHS compliant	—		Apply
		SMD	MPD221M0JD19007R	MPD19	Mass Production	Polarized	4 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	7 mΩ	100 kHz	7000 mArms	88 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.135 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD100M1ED19080R	MPD19	Mass Production	Polarized	25 V	10 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	80 mΩ	100 kHz	2200 mArms	25 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPX331M0ED19009RC	MPX	Mass Production	Polarized	2.5 V	330 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	9 mΩ	100 kHz	6300 mArms	82.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.133 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	✓		Apply
		SMD	MPD470M1CD19040R	MPD19	Mass Production	Polarized	16 V	47 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	75.2 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.134 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD101M1CD19018R	MPD19	Mass Production	Polarized	16 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	18 mΩ	100 kHz	4600 mArms	160 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.136 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD681M0ED28009R	MPD28	Mass Production	Polarized	2.5 V	680 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	170 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.182 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPX101M0LD19015RC	MPX	Mass Production	Polarized	6.3 V	100 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	15 mΩ	100 kHz	5100 mArms	63 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.131 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	✓		Apply
		SMD	MPD680M1VD28040R	MPD28	Mass Production	Polarized	35 V	68 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	238 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.189 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD4R7M1KD28080R	MPD28	Mass Production	Polarized	80 V	4.7 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	80 mΩ	100 kHz	2200 mArms	37.6 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD2R2M1KD19080R	MPD19	Mass Production	Polarized	80 V	2.2 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	80 mΩ	100 kHz	2200 mArms	17.6 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD6R8M1LD28040R	MPD28	Mass Production	Polarized	63 V	6.8 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	42.84 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD4R7M1LD19080R	MPD19	Mass Production	Polarized	63 V	4.7 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	80 mΩ	100 kHz	2200 mArms	29.61 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD2R2M1LD19080R	MPD19	Mass Production	Polarized	63 V	2.2 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	80 mΩ	100 kHz	2200 mArms	13.86 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD331M0LD19009R	MPD19	Mass Production	Polarized	6.3 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	207.9 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD331Y0ED19009R	MPD19	Mass Production	Polarized	2.5 V	330 µF	-35%~+10%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	82.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.133 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD221Y0DD19009R	MPD19	Mass Production	Polarized	2 V	220 µF	-35%~+10%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	44 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.13 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD101M0JD15070R	MPD15	Mass Production	Polarized	4 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	70 mΩ	100 kHz	2400 mArms	40 µA	6	7.3 mm	4.3 mm	1.5 mm	6 mm	Ni/Sn	0 g	4000	Polarized, thin profile, laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	—		Apply
		SMD	MPD221M0JD15070R	MPD15	Mass Production	Polarized	4 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	70 mΩ	100 kHz	2400 mArms	88 µA	6	7.3 mm	4.3 mm	1.5 mm	6 mm	Ni/Sn	0 g	4000	Polarized, thin profile, laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	—		Apply
		SMD	MPD151M0LD19009R	MPD19	Mass Production	Polarized	6.3 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	94.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.133 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD681M0ED28006R	MPD28	Mass Production	Polarized	2.5 V	680 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	6 mΩ	100 kHz	7500 mArms	170 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.182 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD471M0LD28018R	MPD28	Mass Production	Polarized	6.3 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	18 mΩ	100 kHz	4600 mArms	296.1 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.186 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD151M1AD19040R	MPD19	Mass Production	Polarized	10 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	150 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.135 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD331M0LD28025R	MPD28	Mass Production	Polarized	6.3 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	25 mΩ	100 kHz	3800 mArms	207.9 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.181 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD331Y0DD19009R	MPD19	Mass Production	Polarized	2 V	330 µF	-35%~+10%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	66 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.131 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD471M0DD19006R	MPD19	Mass Production	Polarized	2 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	6 mΩ	100 kHz	7500 mArms	94 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.139 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD470M1DD15040R	MPD15	Mass Production	Polarized	20 V	47 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	94 µA	6	7.3 mm	4.3 mm	1.5 mm	6 mm	Ni/Sn	0 g	4000	Polarized, thin profile, laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	—		Apply
		SMD	MPX221M0ED19009RC	MPX	Mass Production	Polarized	2.5 V	220 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	9 mΩ	100 kHz	6300 mArms	55 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.134 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	✓		Apply
