Conductive Polymer Tantalum Electrolytic

Clear All Filters

Found 44 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	Dimension L (mm)	Width W (mm)	Dimension H (mm)	Terminal Pitch (mm)	Terminal Material	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		SMD	TQD101M1CD15100RN	TQD15	Mass Production	Polarized	16 V	100 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	160 µA	10	7.3 mm	4.3 mm	1.5 mm	5.3 mm	Copper, nickel-plated then tin-plated	211.8825 g	1000	Low ESR, high ripple current, large capacitance, wide temperature range	—		Apply
		SMD	TQD151M1CD15100RD	TQD15	Mass Production	Polarized	16 V	150 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	160 µA	10	7.3 mm	4.3 mm	1.5 mm	5.3 mm	Copper, nickel-plated then tin-plated	211.8825 g	1000	Low ESR, high ripple current, large capacitance, wide temperature range	—		Apply
		SMD	TQD151M1CD15100RN	TQD15	Mass Production	Polarized	16 V	150 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	160 µA	10	7.3 mm	4.3 mm	1.5 mm	5.3 mm	Copper, nickel-plated then tin-plated	211.8825 g	1000	Low ESR, high ripple current, large capacitance, wide temperature range	—		Apply
		SMD	TQD470M1DD15045RN	TQD15	Mass Production	Polarized	20 V	47 µF	±20%	-55 ~ 105 ℃	2000 h	45 mΩ	100 kHz	2000 mArms	94 µA	10	7.3 mm	4.3 mm	1.5 mm	5.3 mm	Copper, nickel-plated then tin-plated	211.8825 g	1000	Low ESR, high ripple current, large capacitance, wide temperature range	—		Apply
		SMD	TQD470M1VD15100RN	TQD15	Mass Production	Polarized	35 V	47 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	164.5 µA	10	7.3 mm	4.3 mm	1.5 mm	5.3 mm	Copper, nickel-plated then tin-plated	211.8825 g	1000	Low ESR, high ripple current, large capacitance, wide temperature range	—		Apply
		SMD	TQD470M1VD15120RN	TQD15	Mass Production	Polarized	35 V	47 µF	±20%	-55 ~ 105 ℃	2000 h	120 mΩ	100 kHz	1200 mArms	164.5 µA	10	7.3 mm	4.3 mm	1.5 mm	5.3 mm	Copper, nickel-plated then tin-plated	211.8825 g	1000	Low ESR, high ripple current, large capacitance, wide temperature range	—		Apply
		SMD	TQD680M1VD15100RN	TQD15	Mass Production	Polarized	35 V	68 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	238 µA	10	7.3 mm	4.3 mm	1.5 mm	5.3 mm	Copper, nickel-plated then tin-plated	211.8825 g	1000	Low ESR, high ripple current, large capacitance, wide temperature range	—		Apply
		SMD	TQD4R7M1HD15100RN	TQD15	Mass Production	Polarized	50 V	4.7 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	235 µA	10	7.3 mm	4.3 mm	1.5 mm	5.3 mm	Copper, nickel-plated then tin-plated	211.8825 g	1000	Low ESR, high ripple current, large capacitance, wide temperature range	—		Apply
		SMD	TQD100M1JD15100RN	TQD15	Mass Production	Polarized	63 V	10 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	164.5 µA	10	7.3 mm	4.3 mm	1.5 mm	5.3 mm	Copper, nickel-plated then tin-plated	211.8825 g	1000	Low ESR, high ripple current, large capacitance, wide temperature range	—		Apply
		SMD	TQD680M1CD19090RN	TQD19	Mass Production	Polarized	16 V	68 µF	±20%	-55 ~ 105 ℃	2000 h	90 mΩ	100 kHz	1500 mArms	108.8 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD101M1CD19100RN	TQD19	Mass Production	Polarized	16 V	100 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	160 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD101M1CD19050RN	TQD19	Mass Production	Polarized	16 V	100 µF	±20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	2200 mArms	160 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD151M1CD19050RN	TQD19	Mass Production	Polarized	16 V	150 µF	±20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	2200 mArms	240 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD151M1CD19100RN	TQD19	Mass Production	Polarized	16 V	150 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	240 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD330M1ED19060RN	TQD19	Mass Production	Polarized	25 V	33 µF	±20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	1900 mArms	82.5 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD470M1VD19100RN	TQD19	Mass Production	Polarized	35 V	47 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	164.5 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD680M1VD19100RN	TQD19	Mass Production	Polarized	35 V	68 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	238 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD680M1VD19120RN	TQD19	Mass Production	Polarized	35 V	68 µF	±20%	-55 ~ 105 ℃	2000 h	120 mΩ	100 kHz	1200 mArms	238 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD100M1JD19060RN	TQD19	Mass Production	Polarized	63 V	10 µF	±20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	1900 mArms	63 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD100M1JD19100RN	TQD19	Mass Production	Polarized	63 V	10 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1400 mArms	63 µA	10	7.3 mm	4.3 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	268.3845 g	1000	Low ESR, high ripple current, high capacitance, wide temperature range	—		Apply
		SMD	TQD331M1AD28070RN	TQD28	Mass Production	Polarized	10 V	330 µF	±20%	-55 ~ 105 ℃	2000 h	70 mΩ	100 kHz	2100 mArms	330 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD151M1CD28050RN	TQD28	Mass Production	Polarized	16 V	150 µF	±20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	2300 mArms	240 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD221M1CD28050RN	TQD28	Mass Production	Polarized	16 V	220 µF	±20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	2300 mArms	352 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD221M1CD28100RN	TQD28	Mass Production	Polarized	16 V	220 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1800 mArms	352 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD271M1CD28050RN	TQD28	Mass Production	Polarized	16 V	270 µF	±20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	2300 mArms	432 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD101M1DD28100RN	TQD28	Mass Production	Polarized	20 V	100 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1800 mArms	200 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD470M1ED28060RN	TQD28	Mass Production	Polarized	25 V	47 µF	±20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	2200 mArms	117.5 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD470M1ED28100RN	TQD28	Mass Production	Polarized	25 V	47 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1800 mArms	117.5 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD680M1ED28060RN	TQD28	Mass Production	Polarized	25 V	68 µF	±20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	2200 mArms	170 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD680M1ED28100RN	TQD28	Mass Production	Polarized	25 V	68 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1800 mArms	170 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD101M1VD28120RN	TQD28	Mass Production	Polarized	35 V	100 µF	±20%	-55 ~ 105 ℃	2000 h	120 mΩ	100 kHz	1600 mArms	350 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD4R7M2AD28100RN	TQD28	Mass Production	Polarized	100 V	4.7 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	1900 mArms	47 µA	10	7.3 mm	4.3 mm	2.8 mm	5.3 mm	Copper, nickel-plated then tin-plated	395.514 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD331M1AD42100RN	TQD42	Mass Production	Polarized	10 V	330 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	2000 mArms	330 µA	10	7.3 mm	4.3 mm	4.2 mm	5.3 mm	Copper, nickel-plated then tin-plated	593.271 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD331M1CD42100RN	TQD42	Mass Production	Polarized	16 V	330 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	2000 mArms	528 µA	10	7.3 mm	4.3 mm	4.2 mm	5.3 mm	Copper, nickel-plated then tin-plated	593.271 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD471M1CD42100RN	TQD42	Mass Production	Polarized	16 V	470 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	2000 mArms	752 µA	10	7.3 mm	4.3 mm	4.2 mm	5.3 mm	Copper, nickel-plated then tin-plated	593.271 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD470M1HD42100RN	TQD42	Mass Production	Polarized	50 V	47 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	2000 mArms	235 µA	10	7.3 mm	4.3 mm	4.2 mm	5.3 mm	Copper, nickel-plated then tin-plated	593.271 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD680M1HD42100RN	TQD42	Mass Production	Polarized	50 V	68 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	2000 mArms	340 µA	10	7.3 mm	4.3 mm	4.2 mm	5.3 mm	Copper, nickel-plated then tin-plated	593.271 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQD120M2AD42100RN	TQD42	Mass Production	Polarized	100 V	12 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	2000 mArms	12 µA	10	7.3 mm	4.3 mm	4.2 mm	5.3 mm	Copper, nickel-plated then tin-plated	593.271 g	500	Low ESR, High Ripple Current Capability, RoHS Compliant, Long Service Life, High Capacitance, Small Form Factor	—		Apply
		SMD	TQW221M1EW19100RN	TQW19	Mass Production	Polarized	25 V	220 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	2000 mArms	550 µA	10	7.3 mm	6 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	374.49 g	400	High Capacitance Density, Low ESR, High Ripple Current Capability, RoHS Compliant, Low ESL	—		Apply
		SMD	TQW101M1VW19100RN	TQW19	Mass Production	Polarized	35 V	100 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	2000 mArms	350 µA	10	7.3 mm	6 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	374.49 g	400	High Capacitance Density, Low ESR, High Ripple Current Capability, RoHS Compliant, Low ESL	—		Apply
		SMD	TQW101M1VW19120RN	TQW19	Mass Production	Polarized	35 V	100 µF	±20%	-55 ~ 105 ℃	2000 h	120 mΩ	100 kHz	1800 mArms	350 µA	10	7.3 mm	6 mm	1.9 mm	5.3 mm	Copper, nickel-plated then tin-plated	374.49 g	400	High Capacitance Density, Low ESR, High Ripple Current Capability, RoHS Compliant, Low ESL	—		Apply
		SMD	TQW151M1VW42100RN	TQW42	Mass Production	Polarized	35 V	150 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	2050 mArms	525 µA	10	7.3 mm	6 mm	4.2 mm	5.3 mm	Copper, nickel-plated then tin-plated	827.82 g	400	Low ESR, High Ripple Current Capability, Low ESL, Long Service Life, Wide Temperature Range	—		Apply
		SMD	TQW221M1VW42100RN	TQW42	Mass Production	Polarized	35 V	220 µF	±20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	2050 mArms	770 µA	10	7.3 mm	6 mm	4.2 mm	5.3 mm	Copper, nickel-plated then tin-plated	827.82 g	400	Low ESR, High Ripple Current Capability, Low ESL, Long Service Life, Wide Temperature Range	—		Apply
		SMD	TQW470M1HW42060RN	TQW42	Mass Production	Polarized	50 V	47 µF	±20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	2600 mArms	235 µA	10	7.3 mm	6 mm	4.2 mm	5.3 mm	Copper, nickel-plated then tin-plated	827.82 g	400	Low ESR, High Ripple Current Capability, Low ESL, Long Service Life, Wide Temperature Range	—		Apply
