liquid aluminum electrolytic capacitor
VKL(T)I1651K331MVTMCG
Mass ProductionVKL(T) Series · SMD
Low Leakage CurrentHigh Temp ResistantLong Life @ High TempHigh Ripple Current
Rated Voltage (V)
80 V
Nominal Capacitance
330 µF
Operating Temp
-40 ~ 125 ℃
ESR (max)
0.36 Ω
Rated Lifetime
2000 h
Package Size
ø16 × 16.5 mm
Online Store
Min. Order Qty:150
Package:SMD
No online store link available for this part number
Detailed Specifications
Capacitor Categoryliquid aluminum electrolytic capacitor
ShapeSMD
Part NumberVKL(T)I1651K331MVTMCG
SeriesVKL(T)
Lifecycle StatusMass Production
Rated Voltage (V)80
Nominal Capacitance330 µF
ESR (max.)0.36 Ω
PolarityPolarized
Min Operating Temp (°C)-40
Max Operating Temp (°C)125
Rated Lifetime (Hours)2000
Rated Ripple Current350 mArms
ESR Frequency100 kHz
Diameter D (mm)16
Height L (mm)16.5
Terminal Pitch (mm)6.7±0.2
Min. Package Qty150
Tolerance-20%~+20%
Leakage Current (µA) Max264
Dissipation Factor (tanδ max.)12
Terminal Plating Materialtin
Weight (g)—
Dissipation Factor Frequency (Hz)120
Remarks—
Product Dimensions & Electrical Parameters
Actual dimensions and electrical parameters for this part number
Dimensions (unit: mm)
| Dimension | Symbol | Value (mm) |
|---|---|---|
| Diameter (D) | D | 16 |
| Height (L) | L | 16.5 |
Electrical Parameters
| Rated Ripple Current | Ripple Test Condition | ESR | ESR Frequency |
|---|---|---|---|
| 350 mArms | — | 0.36 Ω | 100 kHz |
