Filters1

Polymer Solid Aluminum Electrolytic

Clear All Filters

Found 2,813 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	Dimension D (mm)	Dimension L (mm)	Terminal Pitch (mm)	Terminal Material	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		SMD	VPTD1051H560MVTM	VPT	Mass Production	Polarized	50 V	56 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	30 mΩ	100 kHz	600 mArms	560 µA	10	8 mm	10.5 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range	—		Apply
		Radial Lead	NPLD1101V820MJTM	NPL	Mass Production	Polarized	35 V	82 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	30 mΩ	100 kHz	3200 mArms	574 µA	12	8 mm	11 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Extra Long Service Life, Wide Temperature Range	—		Apply
		Radial Lead	NPXD1601A182MJTM	NPX	Mass Production	有极性	10 V	1800 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	8 mΩ	100 kHz	7250 mArms	3600 µA	10	8 mm	16 mm	3.5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPXD1600A272MJTM	NPX	Mass Production	有极性	6.8 V	2700 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	16 mΩ	100 kHz	7000 mArms	183.6 µA	12	8 mm	16 mm	3.5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPLB0571A101MJTM	NPL	Mass Production	Polarized	10 V	100 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	30 mΩ	100 kHz	1900 mArms	300 µA	8	5 mm	5.7 mm	2 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Extra Long Service Life, Wide Temperature Range	—		View
		Radial Lead	NPXH0901V151MJTM	NPX	Mass Production	有极性	35 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	2200 mArms	1050 µA	12	5.5 mm	9 mm	2.5 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPXB1001V151MJTM	NPX	Mass Production	有极性	35 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	750 mArms	1050 µA	12	5 mm	10 mm	2 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPTB0901V101MJTM	NPT	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	50 mΩ	100 kHz	900 mArms	700 µA	12	5 mm	9 mm	2 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		SMD	VPXD1001J680MVTM	VPX	Mass Production	有极性	63 V	68 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	2300 mArms	856.8 µA	12	8 mm	10 mm	3.5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		SMD	VPLD1001J680MVTM	VPL	Mass Production	Polarized	63 V	68 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	60 mΩ	100 kHz	1900 mArms	856.8 µA	12	8 mm	10 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		Radial Lead	NPXD0801C681MJTM	NPX	Mass Production	有极性	16 V	680 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	12 mΩ	100 kHz	4500 mArms	2176 µA	8	8 mm	8 mm	3.5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		SMD	VPXC1601C102MVTM	VPX	Mass Production	有极性	16 V	1000 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	10 mΩ	100 kHz	5680 mArms	3200 µA	8	6.3 mm	16 mm	2.5 mm	铁镀铜包锡	0.1 g	350	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		SMD	VPLC1601C122MVTM	VPL	Mass Production	Polarized	16 V	1200 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	16 mΩ	100 kHz	5680 mArms	3840 µA	9	6.3 mm	16 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	350	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		SMD	VPTD1001C331MVTM	VPT	Mass Production	Polarized	16 V	330 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	20 mΩ	100 kHz	2250 mArms	52.8 µA	8	8 mm	10 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range	—		Apply
		SMD	VPUE1051K470MVTM	VPU	Mass Production	有极性	80 V	47 µF	-20%~+20%	-55 ~ 125 ℃	4000 h	40 mΩ	100 kHz	1500 mArms	752 µA	10	10 mm	10.5 mm	5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；125℃ 4000小时保证；已应对RoHS指令；耐高温品 表面贴装型	—	—	Apply
		SMD	VPXD1051V331MVTM	VPX	Mass Production	有极性	35 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	3100 mArms	2310 µA	12	8 mm	10.5 mm	3.5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		Radial Lead	NPXD1201C471MJTM	NPX	Mass Production	有极性	16 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	10 mΩ	100 kHz	5200 mArms	1504 µA	9	8 mm	12 mm	3.5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPTL2001J681MJTM	NPT	Mass Production	Polarized	63 V	680 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	30 mΩ	100 kHz	2150 mArms	7500 µA	12	12.5 mm	20 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	100	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		SMD	VPLD1251J101MVTM	VPL	Mass Production	Polarized	63 V	100 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	40 mΩ	100 kHz	2700 mArms	1260 µA	12	8 mm	12.5 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	400	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		Radial Lead	NPTC0801E181MJTM	NPT	Mass Production	Polarized	25 V	180 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	16 mΩ	100 kHz	1600 mArms	900 µA	8	6.3 mm	8 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		SMD	VPLB0581H150MVTM	VPL	Mass Production	Polarized	50 V	15 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	60 mΩ	100 kHz	1350 mArms	500 µA	12	5 mm	5.8 mm	2 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1200	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		SMD	VPTC0450J221MVTM	VPT	Mass Production	Polarized	6.3 V	220 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	60 mΩ	100 kHz	1150 mArms	500 µA	8	6.3 mm	4.5 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range	—		Apply
		SMD	VPTC0451A101MVTM	VPT	Mass Production	Polarized	10 V	100 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	60 mΩ	100 kHz	1100 mArms	500 µA	8	6.3 mm	4.5 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range	—		Apply
		Radial Lead	NPXE2101K331MJTM	NPX	Mass Production	有极性	80 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	30 mΩ	100 kHz	4350 mArms	5280 µA	12	10 mm	21 mm	5 mm	铁镀铜包锡	0.1 g	250	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		SMD	VPXE1051V561MVTM	VPX	Mass Production	有极性	35 V	560 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	3300 mArms	3920 µA	12	10 mm	10.5 mm	5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		Radial Lead	NPXD1201J101MJTM	NPX	Mass Production	有极性	63 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	2900 mArms	1260 µA	8	8 mm	12 mm	3.5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPXH0901H680MJTM	NPX	Mass Production	有极性	50 V	68 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	850 mArms	680 µA	12	5.5 mm	9 mm	2.5 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPXE0701K101MJTM	NPX	Mass Production	有极性	80 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	2000 mArms	1600 µA	12	10 mm	7 mm	5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPWD0901C561MJTM	NPW	Mass Production	有极性	16 V	560 µF	-20%~+20%	-55 ~ 105 ℃	15000 h	18 mΩ	100 kHz	3600 mArms	1792 µA	12	8 mm	9 mm	3.5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流 105℃ 15000小时保证 已应对RoHS指令 超长寿命品	—		Apply
		Radial Lead	NPXC0421V470MJTM	NPX	Mass Production	有极性	35 V	47 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	1400 mArms	329 µA	12	6.3 mm	4.2 mm	2.5 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPTH0901C331MJTM	NPT	Mass Production	Polarized	16 V	330 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	22 mΩ	100 kHz	1800 mArms	1056 µA	8	5.5 mm	9 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		SMD	VPXC0541A221MVTM	VPX	Mass Production	有极性	10 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	2100 mArms	500 µA	8	6.3 mm	5.4 mm	2.5 mm	铁镀铜包锡	0.1 g	1200	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		SMD	VPXC0771V101MVTM	VPX	Mass Production	有极性	35 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	20 mΩ	100 kHz	1900 mArms	700 µA	12	6.3 mm	7.7 mm	2.5 mm	铁镀铜包锡	0.1 g	900	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		SMD	VPXC0771E221MVTM	VPX	Mass Production	有极性	25 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	20 mΩ	100 kHz	3400 mArms	1100 µA	8	6.3 mm	7.7 mm	2.5 mm	铁镀铜包锡	0.1 g	900	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		SMD	VPLD1701C182MVTM	VPL	Mass Production	Polarized	16 V	1800 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	10 mΩ	100 kHz	7000 mArms	5760 µA	8	8 mm	17 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	350	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		Radial Lead	NPWE1801V102MJTM	NPW	Mass Production	有极性	35 V	1000 µF	-20%~+20%	-55 ~ 105 ℃	15000 h	20 mΩ	100 kHz	5000 mArms	7000 µA	13	10 mm	18 mm	5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流 105℃ 15000小时保证 已应对RoHS指令 超长寿命品	—		Apply
		SMD	VPXC0541A331MVTM	VPX	Mass Production	有极性	10 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	2100 mArms	660 µA	8	6.3 mm	5.4 mm	2.5 mm	铁镀铜包锡	0.1 g	1200	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		Radial Lead	NPTH1501E681MJTM	NPT	Mass Production	Polarized	25 V	680 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	20 mΩ	100 kHz	3900 mArms	3400 µA	8	5.5 mm	15 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		Radial Lead	NP1D1101C681MJTM	NP1	Mass Production	Polarized	16 V	680 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	10 mΩ	100 kHz	5500 mArms	2176 µA	8	8 mm	11 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life	—		Apply
		Radial Lead	NPXB1001B561MJTM	NPX	Mass Production	有极性	12 V	560 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	20 mΩ	100 kHz	4100 mArms	1344 µA	8	5 mm	10 mm	2 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPTJ4001J222MJTM	NPT	Mass Production	Polarized	63 V	2200 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	16 mΩ	100 kHz	7500 mArms	7500 µA	12	18 mm	40 mm	7.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	45	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		SMD	VPUC0581H100MVTM	VPU	Mass Production	有极性	50 V	10 µF	-20%~+20%	-55 ~ 125 ℃	4000 h	60 mΩ	100 kHz	750 mArms	500 µA	12	6.3 mm	5.8 mm	2.5 mm	铁镀铜包锡	0.1 g	1200	高可靠性 低ESR 高容许纹波电流；125℃ 4000小时保证；已应对RoHS指令；耐高温品 表面贴装型	—	—	Apply
		SMD	VPHD1501H221MVTM	VPH	Mass Production	Polarized	50 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	30 mΩ	100 kHz	3500 mArms	2200 µA	12	8 mm	15 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	350	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		Radial Lead	NPMA1101E151MJTM	NPM	Mass Production	Polarized	25 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	950 mArms	750 µA	12	4 mm	11 mm	1.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, DC-DC Converter, Consumer Electronics	—		Apply
		Radial Lead	NPXB1001E221MJTM	NPX	Mass Production	有极性	25 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	20 mΩ	100 kHz	2500 mArms	1100 µA	8	5 mm	10 mm	2 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPXC1201H101MJTM	NPX	Mass Production	有极性	50 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	2700 mArms	1000 µA	12	6.3 mm	12 mm	2.5 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPTC0701C221MJTM	NPT	Mass Production	Polarized	16 V	220 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	16 mΩ	100 kHz	1800 mArms	35.2 µA	8	6.3 mm	7 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		View
		SMD	VPXE0850J821MVTM	VPX	Mass Production	有极性	6.3 V	820 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	8 mΩ	100 kHz	6050 mArms	1033.2 µA	9	10 mm	8.5 mm	5 mm	铁镀铜包锡	0.1 g	600	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		SMD	VPXC0850J821MVTM	VPX	Mass Production	有极性	6.3 V	820 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	8 mΩ	100 kHz	5250 mArms	1033.2 µA	8	6.3 mm	8.5 mm	2.5 mm	铁镀铜包锡	0.1 g	800	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		Radial Lead	NPHE1502C270MJTM	NPH	Mass Production	Polarized	160 V	27 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	2700 mArms	864 µA	12	10 mm	15 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, DC-DC Converter, Base Station Equipment	—		Apply
