Polymer Solid Aluminum Electrolytic

Clear All Filters

Found 2,813 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	Dimension D (mm)	Dimension L (mm)	Terminal Pitch (mm)	Terminal Material	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		Radial Lead	NPLE0800J152MJTM	NPL	Mass Production	Polarized	6.3 V	1500 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	12 mΩ	100 kHz	4500 mArms	1890 µA	9	10 mm	8 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Extra Long Service Life, Wide Temperature Range	—		Apply
		Radial Lead	NPHE1002E6R8MJTM	NPH	Mass Production	Polarized	250 V	6.8 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	2050 mArms	340 µA	12	10 mm	10 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, DC-DC Converter, Base Station Equipment	—		Apply
		Radial Lead	NPHE0902D6R8MJTM	NPH	Mass Production	Polarized	200 V	6.8 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	80 mΩ	100 kHz	1950 mArms	300 µA	12	10 mm	9 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, DC-DC Converter, Base Station Equipment	—		Apply
		Radial Lead	NPTE2001V821MJTM	NPT	Mass Production	Polarized	35 V	820 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	30 mΩ	100 kHz	5200 mArms	5740 µA	13	10 mm	20 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	250	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		Radial Lead	NPLE1601V681MJTM	NPL	Mass Production	Polarized	35 V	680 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	20 mΩ	100 kHz	4700 mArms	4760 µA	12	10 mm	16 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Extra Long Service Life, Wide Temperature Range	—		Apply
		SMD	VPXC0581A121MVTM	VPX	Mass Production	有极性	10 V	120 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	30 mΩ	100 kHz	2200 mArms	500 µA	8	6.3 mm	5.8 mm	2.5 mm	铁镀铜包锡	0.1 g	1200	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		Radial Lead	NPTD1601C152MJTM	NPT	Mass Production	Polarized	16 V	1500 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	12 mΩ	100 kHz	3150 mArms	4800 µA	8	8 mm	16 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		SMD	VPLE1251E681MVTM	VPL	Mass Production	Polarized	25 V	680 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	16 mΩ	100 kHz	4700 mArms	3400 µA	8	10 mm	12.5 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	400	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		Radial Lead	NPXB1201H101MJTM	NPX	Mass Production	有极性	50 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	2300 mArms	1000 µA	12	5 mm	12 mm	2 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPLD1601H221MJTM	NPL	Mass Production	Polarized	50 V	220 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	30 mΩ	100 kHz	3500 mArms	2200 µA	12	8 mm	16 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Extra Long Service Life, Wide Temperature Range	—		Apply
		Radial Lead	NPLC0901E221MJTM	NPL	Mass Production	Polarized	25 V	220 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	20 mΩ	100 kHz	3500 mArms	1100 µA	8	6.3 mm	9 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Extra Long Service Life, Wide Temperature Range	—		Apply
		Radial Lead	NPMA0701C101MJTM	NPM	Mass Production	Polarized	16 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	100 mΩ	100 kHz	850 mArms	16 µA	12	4 mm	7 mm	1.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, DC-DC Converter, Consumer Electronics	—		Apply
		Radial Lead	NPLD2001H331MJTM	NPL	Mass Production	Polarized	50 V	330 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	30 mΩ	100 kHz	3900 mArms	3300 µA	12	8 mm	20 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Extra Long Service Life, Wide Temperature Range	—		Apply
		Radial Lead	NPTC0570L221MJTM	NPT	Mass Production	Polarized	7.5 V	220 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	30 mΩ	100 kHz	2200 mArms	330 µA	8	6.3 mm	5.7 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		Radial Lead	NPGJ1802A271MJTM	NPG	Mass Production	Polarized	100 V	270 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	4000 mArms	5400 µA	12	18 mm	18 mm	7.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	75	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life	—		Apply
		SMD	VPLE0951C102MVTM	VPL	Mass Production	Polarized	16 V	1000 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	16 mΩ	100 kHz	5200 mArms	160 µA	8	10 mm	9.5 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		SMD	VPTE2202A101MVTM	VPT	Mass Production	Polarized	100 V	100 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	40 mΩ	100 kHz	1600 mArms	2000 µA	12	10 mm	22 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	175	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range	—		Apply
		Radial Lead	NPLC0901E271MJTM	NPL	Mass Production	Polarized	25 V	270 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	20 mΩ	100 kHz	3500 mArms	1350 µA	8	6.3 mm	9 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Extra Long Service Life, Wide Temperature Range	—		Apply
		SMD	VPLC0541C680MVTM	VPL	Mass Production	Polarized	16 V	68 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	40 mΩ	100 kHz	950 mArms	500 µA	8	6.3 mm	5.4 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1200	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		SMD	VPTC0771E221MVTM	VPT	Mass Production	Polarized	25 V	220 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	30 mΩ	100 kHz	1450 mArms	1100 µA	8	6.3 mm	7.7 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	900	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range	—		Apply
		SMD	VPXE1051V331MVTM	VPX	Mass Production	有极性	35 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	3300 mArms	2310 µA	12	10 mm	10.5 mm	5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		SMD	VPTC0771E151MVTM	VPT	Mass Production	Polarized	25 V	150 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	30 mΩ	100 kHz	1450 mArms	750 µA	8	6.3 mm	7.7 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	900	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range	—		Apply
		SMD	VPTC0771C151MVTM	VPT	Mass Production	Polarized	16 V	150 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	16 mΩ	100 kHz	3500 mArms	500 µA	8	6.3 mm	7.7 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	900	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range	—		Apply
		Radial Lead	NPGI2001V272MJTM	NPG	Mass Production	Polarized	35 V	2700 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	20 mΩ	100 kHz	5950 mArms	7500 µA	15	16 mm	20 mm	7.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	60	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life	—		Apply
		Radial Lead	NPLD1101V221MJTM	NPL	Mass Production	Polarized	35 V	220 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	30 mΩ	100 kHz	3200 mArms	1540 µA	12	8 mm	11 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Extra Long Service Life, Wide Temperature Range	—		Apply
		SMD	VPXD0771E331MVTM	VPX	Mass Production	有极性	25 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	30 mΩ	100 kHz	2700 mArms	1650 µA	8	8 mm	7.7 mm	3.5 mm	铁镀铜包锡	0.1 g	600	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		Radial Lead	NPXD0701J330MJTM	NPX	Mass Production	有极性	63 V	33 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	1800 mArms	415.8 µA	12	8 mm	7 mm	3.5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPXB1501V221MJTM	NPX	Mass Production	有极性	35 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	30 mΩ	100 kHz	2500 mArms	1540 µA	12	5 mm	15 mm	2 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPXB1301V221MJTM	NPX	Mass Production	有极性	35 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	35 mΩ	100 kHz	2400 mArms	1540 µA	12	5 mm	13 mm	2 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		SMD	VPXE1052A680MVTM	VPX	Mass Production	有极性	100 V	68 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	3800 mArms	1360 µA	8	10 mm	10.5 mm	5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		Radial Lead	NPGI1802A221MJTM	NPG	Mass Production	Polarized	100 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	4000 mArms	4400 µA	12	16 mm	18 mm	7.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	75	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life	—		Apply
		SMD	VPXB1101H390MVTM	VPX	Mass Production	有极性	50 V	39 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	2200 mArms	500 µA	12	5 mm	11 mm	2 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		Radial Lead	NPHE1702C330MJTM	NPH	Mass Production	Polarized	160 V	33 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	2700 mArms	1056 µA	12	10 mm	17 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, DC-DC Converter, Base Station Equipment	—		Apply
		Radial Lead	NPHE1702B390MJTM	NPH	Mass Production	Polarized	125 V	39 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	2700 mArms	975 µA	12	10 mm	17 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, DC-DC Converter, Base Station Equipment	—		Apply
		SMD	VPWC0580J331MVTM	VPW	Mass Production	Polarized	6.3 V	330 µF	-20%~+20%	-55 ~ 105 ℃	15000 h	22 mΩ	100 kHz	2550 mArms	500 µA	12	6.3 mm	5.8 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1200	High Capacitance, Ultra Low ESR, Super High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, RoHS Compliant	—		Apply
		Radial Lead	NPTD1801J181MJTM	NPT	Mass Production	Polarized	63 V	180 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	30 mΩ	100 kHz	2900 mArms	2268 µA	12	8 mm	18 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		Radial Lead	NPTD1601V681MJTM	NPT	Mass Production	Polarized	35 V	680 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	20 mΩ	100 kHz	2050 mArms	4760 µA	12	8 mm	16 mm	3.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		Radial Lead	NPXB0571J8R2MJTM	NPX	Mass Production	有极性	63 V	8.2 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	120 mΩ	100 kHz	1350 mArms	300 µA	12	5 mm	5.7 mm	2 mm	铁镀铜包锡	0.1 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		View
		SMD	VPLB0850J471MVTM	VPL	Mass Production	Polarized	6.3 V	470 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	12 mΩ	100 kHz	3400 mArms	592.2 µA	8	5 mm	8.5 mm	2 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	900	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		Radial Lead	NPTJ3101E562MJTM	NPT	Mass Production	Polarized	25 V	5600 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	16 mΩ	100 kHz	3800 mArms	7500 µA	10	18 mm	31 mm	7.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	51	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		SMD	VPLC0951C331MVTM	VPL	Mass Production	Polarized	16 V	330 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	12 mΩ	100 kHz	4300 mArms	52.8 µA	8	6.3 mm	9.5 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	700	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Reflow Soldering Support	—		Apply
		Radial Lead	NPLB0800J391MJTM	NPL	Mass Production	Polarized	6.3 V	390 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	12 mΩ	100 kHz	3400 mArms	491.4 µA	8	5 mm	8 mm	2 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Extra Long Service Life, Wide Temperature Range	—		Apply
		SMD	VPTC0581K100MVTM	VPT	Mass Production	Polarized	80 V	10 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	60 mΩ	100 kHz	750 mArms	500 µA	12	6.3 mm	5.8 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1200	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range	—		Apply
		SMD	VPTB0771K8R2MVTM	VPT	Mass Production	Polarized	80 V	8.2 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	60 mΩ	100 kHz	650 mArms	500 µA	12	5 mm	7.7 mm	2 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	900	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range	—		Apply
		Radial Lead	NPTE1202C150MJTM	NPT	Mass Production	Polarized	160 V	15 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	80 mΩ	100 kHz	1600 mArms	480 µA	12	10 mm	12 mm	5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	500	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
		SMD	VPXE0951J121MVTM	VPX	Mass Production	有极性	63 V	120 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	50 mΩ	100 kHz	2450 mArms	1512 µA	12	10 mm	9.5 mm	5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		Radial Lead	NPXE1201C152MJTM	NPX	Mass Production	有极性	16 V	1500 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	8 mΩ	100 kHz	6300 mArms	240 µA	9	10 mm	12 mm	5 mm	铁镀铜包锡	0.1 g	500	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		SMD	VPXL2102A331MVTM	VPX	Mass Production	有极性	100 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	4100 mArms	6600 µA	12	12.5 mm	21 mm	5 mm	铁镀铜包锡	0.1 g	175	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品 表面贴装型	—		Apply
		Radial Lead	NPXC0571J100MJTM	NPX	Mass Production	有极性	63 V	10 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	60 mΩ	100 kHz	1700 mArms	300 µA	12	6.3 mm	5.7 mm	2.5 mm	铁镀铜包锡	0 g	1000	高可靠性 低ESR 高容许纹波电流；105℃ 2000小时保证；已应对RoHS指令；小型化品	—		Apply
		Radial Lead	NPTH0571H220MJTM	NPT	Mass Production	Polarized	50 V	22 µF	-20%~+20%	-55 ~ 125 ℃	2000 h	60 mΩ	100 kHz	650 mArms	300 µA	12	5.5 mm	5.7 mm	2.5 mm	Iron Core, Copper Plated, Tin Coated	0.1 g	1000	High Capacitance, Low ESR, High Ripple Current Withstand, Low Leakage Current, High Reliability, Long Service Life, Wide Temperature Range, Automotive Power Supply, DC-DC Converter, Industrial Control	—		Apply
