Filters1

Liquid Aluminum Electrolytic

Clear All Filters

Found 2,613 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	tanδ Frequency (Hz)	Dimension D (mm)	Dimension L (mm)	Terminal Pitch (mm)	Terminal Material	Terminal Type	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		SMD	VKL(R)D1001E101MVTMCG	VKL(R)	Mass Production	Polarized	25 V	100 µF	-20%~+20%	-55 ~ 135 ℃	2000 h	0.4 Ω	100 kHz	270 mArms	25 µA	20	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	High temperature resistance, High-frequency high ripple resistance, Long life, Low ESR	✓		Apply
		SMD	VMML1352A121MVTMCG	VMM	Mass Production	Polarized	100 V	120 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	320 mArms	120 µA	14	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	V3ME1651E102MVTMCG	V3M	Mass Production	Polarized	25 V	1000 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.1 Ω	100 kHz	1300 mArms	250 µA	14	120 Hz	10 mm	16.5 mm	4.6±0.2 mm	tin	—	—	350	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKLD1001H560MVTMCG	VKL	Mass Production	Polarized	50 V	56 µF	-20%~+20%	-40 ~ 125 ℃	3000 h	—	100 kHz	330 mArms	28 µA	14	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VMMC0772C6R8MVTMCG	VMM	Mass Production	Polarized	160 V	6.8 µF	-20%~+20%	-40 ~ 105 ℃	5000 h	—	120 kHz	40 mArms	31.76 µA	15	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKL(R)D1001V101MVTMCG	VKL(R)	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-55 ~ 135 ℃	2000 h	0.4 Ω	100 kHz	324 mArms	35 µA	16	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	High temperature resistance, High-frequency high ripple resistance, Long life, Low ESR	✓		Apply
		SMD	VMM(T)C0541V470MVTMCG	VMM(T)	Mass Production	Polarized	35 V	47 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.66 Ω	120 kHz	167 mArms	16.45 µA	18	120 Hz	6.3 mm	5.4 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	VMM(T)E1001V221MVTMCG	VMM(T)	Mass Production	Polarized	35 V	220 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.3 Ω	120 kHz	567 mArms	77 µA	18	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	VKOD1001V101MVTM	VKO	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	100 kHz	580 mArms	35 µA	16	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VMMC0541V470MVTMCG	VMM	Mass Production	Polarized	35 V	47 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	67 mArms	16.45 µA	18	120 Hz	6.3 mm	5.4 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMMJ2102H470MVTMCG	VMM	Mass Production	Polarized	500 V	47 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	120 kHz	258 mArms	480 µA	25	120 Hz	18 mm	21 mm	6.7±0.2 mm	tin	—	—	120	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKMB1001C220MVTM	VKM	Mass Production	Polarized	16 V	22 µF	-20%~+20%	-55 ~ 105 ℃	7000 h	—	100 kHz	111 mArms	3.52 µA	24	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKL(T)D1001E101MVTMCG	VKL(T)	Mass Production	Polarized	25 V	100 µF	-20%~+20%	-40 ~ 125 ℃	2000 h	0.4 Ω	100 kHz	324 mArms	25 µA	20	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	—		Apply
		SMD	VKMJ2101E472MVTM	VKM	Mass Production	Polarized	25 V	4700 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	4010 mArms	1175 µA	26	120 Hz	18 mm	21 mm	6.7±0.2 mm	tin	—	—	120	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKLI1651V681MVTMCG	VKL	Mass Production	Polarized	35 V	680 µF	-20%~+20%	-40 ~ 125 ℃	5000 h	0.05 Ω	100 kHz	2400 mArms	238 µA	16	120 Hz	16 mm	16.5 mm	6.7±0.2 mm	tin	—	—	150	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKM(R)B1001A470MVTM	VKM(R)	Mass Production	Polarized	10 V	47 µF	-20%~+20%	-55 ~ 105 ℃	7000 h	1 Ω	100 kHz	143 mArms	4.7 µA	28	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	—		Apply
		SMD	V3MB0581H220MVTMCG	V3M	Mass Production	Polarized	50 V	22 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	1.76 Ω	100 kHz	165 mArms	11 µA	12	120 Hz	5 mm	5.8 mm	1.5±0.2 mm	tin	—	—	1200	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKLD1251C471MVTMCG	VKL	Mass Production	Polarized	16 V	470 µF	-20%~+20%	-40 ~ 125 ℃	3000 h	—	100 kHz	650 mArms	75.2 µA	24	120 Hz	8 mm	12.5 mm	3.1±0.2 mm	tin	—	—	400	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKL(T)I1651V102MVTMCG	VKL(T)	Mass Production	Polarized	35 V	1000 µF	-20%~+20%	-40 ~ 125 ℃	3000 h	0.05 Ω	100 kHz	1680 mArms	350 µA	16	120 Hz	16 mm	16.5 mm	6.7±0.2 mm	tin	—	—	150	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	—		Apply
		SMD	VMMC0572S2R2MVTMCG	VMM	Mass Production	Polarized	300 V	2.2 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	—	120 kHz	22 mArms	23.2 µA	15	120 Hz	6.3 mm	5.7 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMMD0772C100MVTMCG	VMM	Mass Production	Polarized	160 V	10 µF	-20%~+20%	-40 ~ 105 ℃	5000 h	—	120 kHz	56 mArms	42 µA	15	120 Hz	8 mm	7.7 mm	3.1±0.2 mm	tin	—	—	600	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMML1352E330MVTMCG	VMM	Mass Production	Polarized	250 V	33 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	120 kHz	270 mArms	175 µA	15	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMMD1002C150MVTMCG	VMM	Mass Production	Polarized	160 V	15 µF	-20%~+20%	-40 ~ 105 ℃	7000 h	—	120 kHz	87 mArms	58 µA	15	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	V3ML1352A151MVTMCG	V3M	Mass Production	Polarized	100 V	150 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.36 Ω	100 kHz	1050 mArms	150 µA	12	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKLD0622C5R6MVTMCG	VKL	Mass Production	Polarized	160 V	5.6 µF	-20%~+20%	-25 ~ 125 ℃	1000 h	—	100 kHz	50 mArms	27.92 µA	15	120 Hz	8 mm	6.2 mm	3.1±0.2 mm	tin	—	—	800	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKO(R)D1001H680MVTM	VKO(R)	Mass Production	Polarized	50 V	68 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.34 Ω	100 kHz	360 mArms	34 µA	14	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	—		Apply
		SMD	VKGC1001V470MVTM	VKG	Mass Production	Polarized	35 V	47 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	310 mArms	16.45 µA	16	120 Hz	6.3 mm	10 mm	1.8±0.2 mm	tin	—	—	700	Extra-long life, High high-frequency ripple current capability, 105°C, Wide voltage & wide temperature range, High capacitance density	✓		Apply
		SMD	VKGC1001C101MVTM	VKG	Mass Production	Polarized	16 V	100 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	350 mArms	16 µA	24	120 Hz	6.3 mm	10 mm	1.8±0.2 mm	tin	—	—	700	Extra-long life, High high-frequency ripple current capability, 105°C, Wide voltage & wide temperature range, High capacitance density	✓		Apply
		SMD	VKOD1001C471MVTM	VKO	Mass Production	Polarized	16 V	470 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	100 kHz	765 mArms	75.2 µA	24	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VMMB0542A4R7MVTMCG	VMM	Mass Production	Polarized	100 V	4.7 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	20 mArms	4.7 µA	14	120 Hz	5 mm	5.4 mm	1.5±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKL(T)E1001V221MVTMCG	VKL(T)	Mass Production	Polarized	35 V	220 µF	-20%~+20%	-40 ~ 125 ℃	3000 h	0.3 Ω	100 kHz	670 mArms	77 µA	16	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	—		Apply
		SMD	V3MI1651J681MVTMCG	V3M	Mass Production	Polarized	63 V	680 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.164 Ω	100 kHz	1740 mArms	428.4 µA	12	120 Hz	16 mm	16.5 mm	6.7±0.2 mm	tin	—	—	150	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKMB1001A470MVTM	VKM	Mass Production	Polarized	10 V	47 µF	-20%~+20%	-55 ~ 105 ℃	7000 h	—	100 kHz	143 mArms	4.7 µA	28	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	V3MC0581C151MVTMCG	V3M	Mass Production	Polarized	16 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.52 Ω	100 kHz	300 mArms	24 µA	16	120 Hz	6.3 mm	5.8 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	V3MC0581E101MVTMCG	V3M	Mass Production	Polarized	25 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.52 Ω	100 kHz	300 mArms	25 µA	14	120 Hz	6.3 mm	5.8 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VMME1301V471MVTMCG	VMM	Mass Production	Polarized	35 V	470 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	570 mArms	164.5 µA	18	120 Hz	10 mm	13 mm	4.6±0.2 mm	tin	—	—	400	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKL(T)D1001V221MVTMCG	VKL(T)	Mass Production	Polarized	35 V	220 µF	-20%~+20%	-40 ~ 125 ℃	2000 h	0.9 Ω	100 kHz	600 mArms	77 µA	16	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	—		Apply
		SMD	VKOC1001V101MVTM	VKO	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-55 ~ 105 ℃	6000 h	—	100 kHz	390 mArms	35 µA	16	120 Hz	6.3 mm	10 mm	1.8±0.2 mm	tin	—	—	700	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VK7(R)C0771V470MVTM	VK7(R)	Mass Production	Polarized	35 V	47 µF	-20%~+20%	-55 ~ 105 ℃	6000 h	1 Ω	120 kHz	155 mArms	16.45 µA	16	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	—		Apply
		SMD	VMME0772A330MVTMCG	VMM	Mass Production	Polarized	100 V	33 µF	-20%~+20%	-55 ~ 105 ℃	4000 h	—	120 kHz	86 mArms	33 µA	14	120 Hz	10 mm	7.7 mm	4.6±0.2 mm	tin	—	—	600	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	V3MI1652A331MVTMCG	V3M	Mass Production	Polarized	100 V	330 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.2 Ω	100 kHz	1500 mArms	330 µA	12	120 Hz	16 mm	16.5 mm	6.7±0.2 mm	tin	—	—	150	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKLJ2102A331MVTMCG	VKL	Mass Production	Polarized	100 V	330 µF	-20%~+20%	-40 ~ 125 ℃	5000 h	0.36 Ω	100 kHz	1400 mArms	330 µA	12	120 Hz	18 mm	21 mm	6.7±0.2 mm	tin	—	—	120	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKLL1652A101MVTMCG	VKL	Mass Production	Polarized	100 V	100 µF	-20%~+20%	-40 ~ 125 ℃	5000 h	—	100 kHz	700 mArms	100 µA	12	120 Hz	12.5 mm	16.5 mm	4.6±0.2 mm	tin	—	—	200	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKMC1002C6R8MVTM	VKM	Mass Production	Polarized	160 V	6.8 µF	-20%~+20%	-40 ~ 105 ℃	9000 h	—	100 kHz	125 mArms	31.76 µA	15	120 Hz	6.3 mm	10 mm	1.8±0.2 mm	tin	—	—	700	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VMM(R)C0541J100MVTMCG	VMM(R)	Mass Production	Polarized	63 V	10 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	1.2 Ω	120 kHz	87 mArms	6.3 µA	16	120 Hz	6.3 mm	5.4 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	VKGD1001V101MVTM	VKG	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-55 ~ 105 ℃	12000 h	—	100 kHz	441 mArms	35 µA	16	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Extra-long life, High high-frequency ripple current capability, 105°C, Wide voltage & wide temperature range, High capacitance density	✓		Apply
		SMD	VKMB1002G1R0MVTM	VKM	Mass Production	Polarized	400 V	1 µF	-20%~+20%	-40 ~ 105 ℃	7000 h	—	100 kHz	73 mArms	18 µA	15	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VK7D0792V3R3MVTM	VK7	Mass Production	Polarized	350 V	3.3 µF	-20%~+20%	-40 ~ 105 ℃	6000 h	—	120 kHz	70 mArms	33.1 µA	15	120 Hz	8 mm	7.9 mm	3.1±0.2 mm	tin	—	—	600	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	✓		Apply
		SMD	VMMD1001E221MVTMCG	VMM	Mass Production	Polarized	25 V	220 µF	-20%~+20%	-55 ~ 105 ℃	6000 h	—	120 kHz	250 mArms	55 µA	20	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	V3M(T)E1001E821MVTMCG	V3M(T)	Mass Production	Polarized	25 V	820 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.28 Ω	100 kHz	1190 mArms	205 µA	14	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	—		Apply

1…567…53
