Filters1

Liquid Aluminum Electrolytic

Clear All Filters

Found 2,613 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	tanδ Frequency (Hz)	Dimension D (mm)	Dimension L (mm)	Terminal Pitch (mm)	Terminal Material	Terminal Type	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		Snap-in	SW62C821M2545S2NNYXX	SW6	Mass Production	有极性	160 V	820 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	243 mΩ	120 Hz	1630 mArms	1087 µA	0.15	—	25 mm	45 mm	10 mm	镀锡	S2	0 g	208	—	—	—	Apply
		Snap-in	SW62I331M3050S2NNYXX	SW6	Mass Production	有极性	550 V	330 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	528 mΩ	120 Hz	1440 mArms	1278 µA	0.2	—	30 mm	50 mm	10 mm	镀锡	S2	0 g	144	—	—	—	Apply
		Snap-in	SW32W271M3030S2NNYXX	SW3	Mass Production	Polarized	450 V	270 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	275 mΩ	120 Hz	1030 mArms	1046 µA	0.15	—	30 mm	30 mm	10 mm	Tin plating	S2	0 g	216	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW32W151M2235S2NNYXX	SW3	Mass Production	Polarized	450 V	150 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	561 mΩ	120 Hz	640 mArms	779 µA	0.15	—	22 mm	35 mm	8.4 mm	Tin plating	S2	0 g	270	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW62W471M3545S2NNYXX	SW6	Mass Production	有极性	450 V	470 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	565 mΩ	120 Hz	1500 mArms	1380 µA	0.2	—	35 mm	45 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	CW32G221M2235S2NNYXX	CW3	Mass Production	Polarized	400 V	220 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	723 mΩ	120 Hz	880 mArms	890 µA	0.2	—	22 mm	35 mm	8.4 mm	Tin plating	S2	0 g	270	High Capacitance Density，Low ESR，High Ripple Current，High Temperature Long Life，Low Temperature Rise，Small Capacitance Degradation	—		Apply
		Snap-in	SW32W471M3535S2NNYXX	SW3	Mass Production	Polarized	450 V	470 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	179 mΩ	120 Hz	1560 mArms	1380 µA	0.15	—	35 mm	35 mm	10 mm	Tin plating	S2	0 g	100	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW62I331M3555S2NNYXX	SW6	Mass Production	有极性	550 V	330 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	528 mΩ	120 Hz	1580 mArms	1278 µA	0.2	—	35 mm	55 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	SW62I471M3570S2NNYXX	SW6	Mass Production	有极性	550 V	470 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	371 mΩ	120 Hz	2010 mArms	1525 µA	0.2	—	35 mm	70 mm	10 mm	镀锡	S2	0 g	50	—	—	—	Apply
		Snap-in	SW62J121M3030S2NNYXX	SW6	Mass Production	有极性	600 V	120 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	1410 mΩ	120 Hz	780 mArms	805 µA	0.2	—	30 mm	30 mm	10 mm	镀锡	S2	0 g	216	—	—	—	Apply
		Snap-in	SW62W331M3535S2NNYXX	SW6	Mass Production	有极性	450 V	330 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	804 mΩ	120 Hz	1140 mArms	1156 µA	0.2	—	35 mm	35 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	SW62G561D3545S2NNYXX	SW6	Mass Production	有极性	400 V	560 µF	-5%~+5%	-25 ~ 105 ℃	6000 h	356 mΩ	120 Hz	1550 mArms	1420 µA	0.15	—	35 mm	45 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	SW62G102M3560S2NNYXX	SW6	Mass Production	有极性	400 V	1000 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	199 mΩ	120 Hz	2690 mArms	1897 µA	0.15	—	35 mm	60 mm	10 mm	镀锡	S2	0 g	50	—	—	—	Apply

1…5253
