Filters1

Liquid Aluminum Electrolytic

Clear All Filters

Found 2,613 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	tanδ Frequency (Hz)	Dimension D (mm)	Dimension L (mm)	Terminal Pitch (mm)	Terminal Material	Terminal Type	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		Snap-in	SW32H102M3580S2NNYXX	SW3	Mass Production	Polarized	500 V	1000 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	264 mΩ	120 Hz	3290 mArms	2121 µA	0.15	—	35 mm	80 mm	10 mm	Tin plating	S2	0 g	50	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW31V822M2240S2NNYXX	SW3	Mass Production	Polarized	35 V	8200 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	56 mΩ	120 Hz	2460 mArms	1607 µA	0.4	—	22 mm	40 mm	8.4 mm	Tin plating	S2	0 g	270	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW32H102M3590S2NNYXX	SW3	Mass Production	Polarized	500 V	1000 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	264 mΩ	120 Hz	3410 mArms	2121 µA	0.15	—	35 mm	90 mm	10 mm	Tin plating	S2	0 g	50	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	CW32W561M3535S4NNYXX	CW3	Mass Production	Polarized	450 V	560 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	308 mΩ	120 Hz	1730 mArms	1506 µA	0.2	—	35 mm	35 mm	10 mm	Tin plating	S4	0 g	100	High Capacitance Density，Low ESR，High Ripple Current，High Temperature Long Life，Low Temperature Rise，Small Capacitance Degradation	—		Apply
		Snap-in	SW32h331M3530S2NNYXX	SW3	Mass Production	Polarized	525 V	330 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	455 mΩ	120 Hz	1510 mArms	1249 µA	0.15	—	35 mm	30 mm	10 mm	Tin plating	S2	0 g	150	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW32I680M2235S2NNYXX	SW3	Mass Production	Polarized	550 V	68 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	2172 mΩ	120 Hz	580 mArms	580 µA	0.15	—	22 mm	35 mm	8.4 mm	Tin plating	S2	0 g	270	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	CW62W561M3550S2NNYXX	CW6	Mass Production	Polarized	450 V	560 µF	-20%~+20%	-40 ~ 105 ℃	6000 h	284 mΩ	120 Hz	1930 mArms	1506 µA	0.2	—	35 mm	50 mm	10 mm	Tin plating	S2	0 g	100	High Ripple Current Capability,Low Impedance,Excellent Low-Temperature Performance,Long Service Life,Wide Temperature Range	—		Apply
		Snap-in	CW62I331M3050S2NNYXX	CW6	Mass Production	Polarized	550 V	330 µF	-20%~+20%	-40 ~ 105 ℃	6000 h	563 mΩ	120 Hz	1530 mArms	1278 µA	0.2	—	30 mm	50 mm	10 mm	Tin plating	S2	0 g	144	High Ripple Current Capability,Low Impedance,Excellent Low-Temperature Performance,Long Service Life,Wide Temperature Range	—		Apply
		Snap-in	SW32I151M3045S2NNYXX	SW3	Mass Production	Polarized	550 V	150 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	985 mΩ	120 Hz	1060 mArms	862 µA	0.15	—	30 mm	45 mm	10 mm	Tin plating	S2	0 g	144	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW32W331M3530S2NNYXX	SW3	Mass Production	Polarized	450 V	330 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	245 mΩ	120 Hz	1220 mArms	1156 µA	0.15	—	35 mm	30 mm	10 mm	Tin plating	S2	0 g	150	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW32W271M3530S2NNYXX	SW3	Mass Production	Polarized	450 V	270 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	275 mΩ	120 Hz	1100 mArms	1046 µA	0.15	—	35 mm	30 mm	10 mm	Tin plating	S2	0 g	150	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	CW32H331M2550S2NNYXX	CW3	Mass Production	Polarized	500 V	330 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	563 mΩ	120 Hz	1090 mArms	1219 µA	0.2	—	25 mm	50 mm	10 mm	Tin plating	S2	0 g	208	High Capacitance Density，Low ESR，High Ripple Current，High Temperature Long Life，Low Temperature Rise，Small Capacitance Degradation	—		Apply
		Snap-in	CW32V102M3050S2NNYXX	CW3	Mass Production	Polarized	350 V	1000 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	146 mΩ	120 Hz	2440 mArms	1775 µA	0.2	—	30 mm	50 mm	10 mm	Tin plating	S2	0 g	144	High Capacitance Density，Low ESR，High Ripple Current，High Temperature Long Life，Low Temperature Rise，Small Capacitance Degradation	—		Apply
		Snap-in	SW61H472M2535S2NNYXX	SW6	Mass Production	有极性	50 V	4700 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	99 mΩ	120 Hz	2000 mArms	1454 µA	0.35	—	25 mm	35 mm	10 mm	镀锡	S2	0 g	208	—	—	—	Apply
		Snap-in	SW32G102D3560S2NNYXX	SW3	Mass Production	Polarized	400 V	1000 µF	-5%~+5%	-25 ~ 105 ℃	3000 h	85 mΩ	120 Hz	2760 mArms	1897 µA	0.15	—	35 mm	60 mm	10 mm	Tin plating	S2	0 g	50	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW61J103M3550S2NNYXX	SW6	Mass Production	有极性	63 V	10000 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	40 mΩ	120 Hz	4500 mArms	2381 µA	0.3	—	35 mm	50 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	SN32E102M3045S2NNYXX	SN3	Mass Production	有极性	250 V	1000 µF	-20%~+20%	-25 ~ 85 ℃	3000 h	202 mΩ	120 Hz	1670 mArms	1500 µA	0.15	—	30 mm	45 mm	10 mm	镀锡	S2	0 g	144	—	—	—	Apply
		Snap-in	SW32W471M3050S2NNYXX	SW3	Mass Production	Polarized	450 V	470 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	179 mΩ	120 Hz	1590 mArms	1380 µA	0.15	—	30 mm	50 mm	10 mm	Tin plating	S2	0 g	144	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW61J333M4280S2NNYXX	SW6	Mass Production	有极性	63 V	33000 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	12 mΩ	120 Hz	10030 mArms	4326 µA	0.3	—	42 mm	80 mm	10 mm	镀锡	S2	0 g	32	—	—	—	Apply
		Snap-in	SW32D332M3570S2NNYXX	SW3	Mass Production	Polarized	200 V	3300 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	60 mΩ	120 Hz	4510 mArms	2437 µA	0.15	—	35 mm	70 mm	10 mm	Tin plating	S2	0 g	50	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	CW3S2H331M3535S2NNYXX	CW3S	Mass Production	Polarized	500 V	330 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	563 mΩ	120 Hz	1160 mArms	1219 µA	0.2	—	35 mm	35 mm	10 mm	Tin plating	S2	0 g	100	High Capacitance Density，Low ESR，High Ripple Current，High Temperature Long Life，Low Temperature Rise，Small Capacitance Degradation	—		Apply
		Snap-in	SW62A103M3570S2NNYXX	SW6	Mass Production	有极性	100 V	10000 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	27 mΩ	120 Hz	6360 mArms	3000 µA	0.2	—	35 mm	70 mm	10 mm	镀锡	S2	0 g	50	—	—	—	Apply
		Snap-in	SW32H331M3045S2NNYXX	SW3	Mass Production	Polarized	500 V	330 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	799 mΩ	120 Hz	1510 mArms	1219 µA	0.15	—	30 mm	45 mm	10 mm	Tin plating	S2	0 g	144	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW32W391M3535S2NNYXX	SW3	Mass Production	Polarized	450 V	390 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	213 mΩ	120 Hz	1390 mArms	1257 µA	0.15	—	35 mm	35 mm	10 mm	Tin plating	S2	0 g	100	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW62C222M3540S2NNYXX	SW6	Mass Production	有极性	160 V	2200 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	91 mΩ	120 Hz	3020 mArms	1780 µA	0.15	—	35 mm	40 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	SW62G681M3555S2NNYXX	SW6	Mass Production	有极性	400 V	680 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	293 mΩ	120 Hz	1930 mArms	1565 µA	0.15	—	35 mm	55 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	CW62W471M3050S2NNYXX	CW6	Mass Production	Polarized	450 V	470 µF	-20%~+20%	-40 ~ 105 ℃	6000 h	339 mΩ	120 Hz	1610 mArms	1380 µA	0.2	—	30 mm	50 mm	10 mm	Tin plating	S2	0 g	144	High Ripple Current Capability,Low Impedance,Excellent Low-Temperature Performance,Long Service Life,Wide Temperature Range	—		Apply
		Snap-in	CN32A472M3540S2NNYXX	CN3	Mass Production	有极性	100 V	4700 µF	-20%~+20%	-40 ~ 85 ℃	3000 h	64 mΩ	120 Hz	2430 mArms	2057 µA	0.15	—	35 mm	40 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	CN32W101M3020S2NNYXX	CN3	Mass Production	有极性	450 V	100 µF	-20%~+20%	-40 ~ 85 ℃	3000 h	1857 mΩ	120 Hz	460 mArms	636 µA	0.15	—	30 mm	20 mm	10 mm	镀锡	S2	0 g	216	—	—	—	Apply
		Snap-in	SW32G122M4060S2NNYXX	SW3	Mass Production	Polarized	400 V	1200 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	73 mΩ	120 Hz	3040 mArms	2078 µA	0.15	—	40 mm	60 mm	10 mm	Tin plating	S4	0 g	40	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW32A102M2230S2NNYXX	SW3	Mass Production	Polarized	100 V	1000 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	254 mΩ	120 Hz	1440 mArms	949 µA	0.2	—	22 mm	30 mm	8.4 mm	Tin plating	S2	0 g	405	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW62M182M3545S2NNYXX	SW6	Mass Production	有极性	180 V	1800 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	111 mΩ	120 Hz	2870 mArms	1708 µA	0.15	—	35 mm	45 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	SN32A222M2540S2NNYXX	SN3	Mass Production	有极性	100 V	2200 µF	-20%~+20%	-40 ~ 85 ℃	3000 h	93 mΩ	120 Hz	1320 mArms	1407 µA	0.2	—	25 mm	40 mm	10 mm	镀锡	S2	0 g	208	—	—	—	Apply
		Snap-in	SW32G391M2545S2NNYXX	SW3	Mass Production	Polarized	400 V	390 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	209 mΩ	120 Hz	1600 mArms	1185 µA	0.15	—	25 mm	45 mm	10 mm	Tin plating	S2	0 g	208	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW32G391M3040S2NNYXX	SW3	Mass Production	Polarized	400 V	390 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	209 mΩ	120 Hz	1680 mArms	1185 µA	0.15	—	30 mm	40 mm	10 mm	Tin plating	S2	0 g	144	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW62E471M2535S2NNYXX	SW6	Mass Production	有极性	250 V	470 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	424 mΩ	120 Hz	1150 mArms	1028 µA	0.15	—	25 mm	35 mm	10 mm	镀锡	S2	0 g	208	—	—	—	Apply
		Snap-in	SW62E561M2550S2NNYXX	SW6	Mass Production	有极性	250 V	560 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	355 mΩ	120 Hz	1450 mArms	1122 µA	0.15	—	25 mm	50 mm	10 mm	镀锡	S2	0 g	208	—	—	—	Apply
		Snap-in	SW62E102M2550S2NNYXX	SW6	Mass Production	有极性	250 V	1000 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	199 mΩ	120 Hz	1960 mArms	1500 µA	0.15	—	25 mm	50 mm	10 mm	镀锡	S2	0 g	208	—	—	—	Apply
		Snap-in	CW32G102M3545S2NNYXX	CW3	Mass Production	Polarized	400 V	1000 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	159 mΩ	120 Hz	2490 mArms	1897 µA	0.2	—	35 mm	45 mm	10 mm	Tin plating	S2	0 g	100	High Capacitance Density，Low ESR，High Ripple Current，High Temperature Long Life，Low Temperature Rise，Small Capacitance Degradation	—		Apply
		Snap-in	SW62E152M3550S2NNYXX	SW6	Mass Production	有极性	250 V	1500 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	133 mΩ	120 Hz	2770 mArms	1837 µA	0.15	—	35 mm	50 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	SW32D102M3035S2NNYXX	SW3	Mass Production	Polarized	200 V	1000 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	197 mΩ	120 Hz	2040 mArms	1342 µA	0.15	—	30 mm	35 mm	10 mm	Tin plating	S2	0 g	144	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW62F222M3580S2NNYXX	SW6	Mass Production	有极性	315 V	2200 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	90 mΩ	120 Hz	3020 mArms	2497 µA	0.15	—	35 mm	80 mm	10 mm	镀锡	S2	0 g	50	—	—	—	Apply
		Snap-in	CW32I681M4070S2NNYXX	CW3	Mass Production	Polarized	550 V	680 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	223 mΩ	120 Hz	2520 mArms	1835 µA	0.2	—	40 mm	70 mm	10 mm	Tin plating	S2	0 g	40	High Capacitance Density，Low ESR，High Ripple Current，High Temperature Long Life，Low Temperature Rise，Small Capacitance Degradation	—		Apply
		Snap-in	SW31J103M3550S2NNYXX	SW3	Mass Production	Polarized	63 V	10000 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	25 mΩ	120 Hz	4660 mArms	2381 µA	0.2	—	35 mm	50 mm	10 mm	Tin plating	S2	0 g	100	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	CW62J221M3545S2NNYXX	CW6	Mass Production	Polarized	600 V	220 µF	-20%~+20%	-40 ~ 105 ℃	6000 h	893 mΩ	120 Hz	1380 mArms	1090 µA	0.2	—	35 mm	45 mm	10 mm	Tin plating	S2	0 g	100	High Ripple Current Capability,Low Impedance,Excellent Low-Temperature Performance,Long Service Life,Wide Temperature Range	—		Apply
		Snap-in	SW32W561M3545S2NNYXX	SW3	Mass Production	Polarized	450 V	560 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	157 mΩ	120 Hz	1820 mArms	1506 µA	0.15	—	35 mm	45 mm	10 mm	Tin plating	S2	0 g	100	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW62G471M3535S2NNYXX	SW6	Mass Production	有极性	400 V	470 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	424 mΩ	120 Hz	1270 mArms	1301 µA	0.15	—	35 mm	35 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	SW32D222M3550S2NNYXX	SW3	Mass Production	Polarized	200 V	2200 µF	-20%~+20%	-25 ~ 105 ℃	3000 h	90 mΩ	120 Hz	3360 mArms	1990 µA	0.15	—	35 mm	50 mm	10 mm	Tin plating	S2	0 g	100	Wide Operating Temperature,Low Leakage Current,High Ripple Current Capability,Low ESR	—		Apply
		Snap-in	SW62G681M3545S2NNYXX	SW6	Mass Production	有极性	400 V	680 µF	-20%~+20%	-25 ~ 105 ℃	6000 h	293 mΩ	120 Hz	1830 mArms	1565 µA	0.15	—	35 mm	45 mm	10 mm	镀锡	S2	0 g	100	—	—	—	Apply
		Snap-in	CW3H2W331M2550SSNNYXX	CW3H	Mass Production	Polarized	450 V	330 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	449 mΩ	120 Hz	1240 mArms	1156 µA	0.2	—	25 mm	50 mm	10 mm	Tin plating	S2	0 g	208	High Capacitance Density，Low ESR，High Ripple Current，High Temperature Long Life，Low Temperature Rise，Small Capacitance Degradation	✓		Apply

1…50515253
