Filters1

Liquid Aluminum Electrolytic

Clear All Filters

Found 2,613 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	tanδ Frequency (Hz)	Dimension D (mm)	Dimension L (mm)	Terminal Pitch (mm)	Terminal Material	Terminal Type	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		SMD	VK7B0791V4R7MVTM	VK7	Mass Production	Polarized	35 V	4.7 µF	-20%~+20%	-55 ~ 105 ℃	4000 h	—	120 kHz	50 mArms	3 µA	16	120 Hz	5 mm	7.9 mm	1.5±0.2 mm	tin	—	—	900	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	✓		Apply
		SMD	VKO(R)E1001H101MVTM	VKO(R)	Mass Production	Polarized	50 V	100 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	0.4 Ω	100 kHz	666 mArms	50 µA	14	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	—		Apply
		SMD	VKLC0771V101MVTMCG	VKL	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-40 ~ 125 ℃	1000 h	—	100 kHz	150 mArms	35 µA	16	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKLC0771H220MVTMCG	VKL	Mass Production	Polarized	50 V	22 µF	-20%~+20%	-40 ~ 125 ℃	2000 h	2 Ω	100 kHz	95 mArms	11 µA	14	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKGE1452G100MVTM	VKG	Mass Production	Polarized	400 V	10 µF	-20%~+20%	-40 ~ 105 ℃	12000 h	—	100 kHz	350 mArms	90 µA	15	120 Hz	10 mm	14.5 mm	4.6±0.2 mm	tin	—	—	350	Extra-long life, High high-frequency ripple current capability, 105°C, Wide voltage & wide temperature range, High capacitance density	✓		Apply
		SMD	VKML1702D560MVTM	VKM	Mass Production	Polarized	200 V	56 µF	-20%~+20%	-40 ~ 105 ℃	10000 h	—	100 kHz	960 mArms	234 µA	15	120 Hz	12.5 mm	17 mm	4.6±0.2 mm	tin	—	—	200	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKGL1651H331MVTM	VKG	Mass Production	Polarized	50 V	330 µF	-20%~+20%	-55 ~ 105 ℃	12000 h	—	100 kHz	1752 mArms	165 µA	14	120 Hz	12.5 mm	16.5 mm	4.6±0.2 mm	tin	—	—	200	Extra-long life, High high-frequency ripple current capability, 105°C, Wide voltage & wide temperature range, High capacitance density	✓		Apply
		SMD	V3ML1351C152MVTMCG	V3M	Mass Production	Polarized	16 V	1500 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.098 Ω	100 kHz	1320 mArms	240 µA	16	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKGB1001V470MVTM	VKG	Mass Production	Polarized	35 V	47 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	100 kHz	220 mArms	16.45 µA	16	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Extra-long life, High high-frequency ripple current capability, 105°C, Wide voltage & wide temperature range, High capacitance density	✓		Apply
		SMD	VK7C0771H220MVTM	VK7	Mass Production	Polarized	50 V	22 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	—	120 kHz	65 mArms	11 µA	14	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	✓		Apply
		SMD	V3M(R)B0541V220MVTMCG	V3M(R)	Mass Production	Polarized	35 V	22 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	1 Ω	100 kHz	240 mArms	7.7 µA	12	120 Hz	5 mm	5.4 mm	1.5±0.2 mm	tin	—	—	1200	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	—		Apply
		SMD	V3ML1351K151MVTMCG	V3M	Mass Production	Polarized	80 V	150 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.36 Ω	100 kHz	600 mArms	120 µA	12	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKO(T)L1351V471MVTM	VKO(T)	Mass Production	Polarized	35 V	470 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.1 Ω	100 kHz	1100 mArms	164.5 µA	16	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	—		Apply
		SMD	VKO(R)I2102E121MVTM	VKO(R)	Mass Production	Polarized	250 V	120 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	3.05 Ω	100 kHz	1350 mArms	610 µA	15	120 Hz	16 mm	21 mm	6.7±0.2 mm	tin	—	—	120	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	—		Apply
		SMD	VMMC0542A100MVTMCG	VMM	Mass Production	Polarized	100 V	10 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	28 mArms	10 µA	14	120 Hz	6.3 mm	5.4 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKMD1251A102MVTM	VKM	Mass Production	Polarized	10 V	1000 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	1250 mArms	100 µA	28	120 Hz	8 mm	12.5 mm	3.1±0.2 mm	tin	—	—	400	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKG(U)B1001A101MVTM	VKG(U)	Mass Production	Polarized	10 V	100 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	182 mArms	10 µA	28	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	—		Apply
		SMD	VKMD1652A820MVTM	VKM	Mass Production	Polarized	100 V	82 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	780 mArms	82 µA	12	120 Hz	8 mm	16.5 mm	3.1±0.2 mm	tin	—	—	350	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VMME1002W5R6MVTMCG	VMM	Mass Production	Polarized	450 V	5.6 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	120 kHz	88 mArms	60.4 µA	20	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKL(R)L1351H391MVTMCG	VKL(R)	Mass Production	Polarized	50 V	390 µF	-20%~+20%	-55 ~ 135 ℃	2000 h	0.18 Ω	100 kHz	750 mArms	195 µA	20	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	High temperature resistance, High-frequency high ripple resistance, Long life, Low ESR	✓		Apply
		SMD	V3M(T)D1001V331MVTMCG	V3M(T)	Mass Production	Polarized	35 V	330 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.2 Ω	100 kHz	600 mArms	115.5 µA	12	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	—		Apply
		SMD	V3MCD1001V471MVTMCG	V3MC	Mass Production	有	35 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.12 Ω	100 kHz	860 mArms	164.5 µA	12	120 Hz	8 mm	10 mm	3.1±0.2 mm	镀锡	—	—	500	超高容量密度、超低 ESR、高纹波电流、耐高温回流焊	✓		Apply
		SMD	VMMC0771V101MVTMCG	VMM	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-55 ~ 105 ℃	4000 h	—	120 kHz	116 mArms	35 µA	18	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMMD0622D3R9MVTMCG	VMM	Mass Production	Polarized	200 V	3.9 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	—	120 kHz	40 mArms	25.6 µA	15	120 Hz	8 mm	6.2 mm	3.1±0.2 mm	tin	—	—	800	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKMD1001H101MVTM	VKM	Mass Production	Polarized	50 V	100 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	724 mArms	50 µA	14	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VK7C0771H330MVTM	VK7	Mass Production	Polarized	50 V	33 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	—	120 kHz	78 mArms	16.5 µA	14	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	✓		Apply
		SMD	VKME1452W100MVTM	VKM	Mass Production	Polarized	450 V	10 µF	-20%~+20%	-40 ~ 105 ℃	10000 h	—	100 kHz	350 mArms	100 µA	20	120 Hz	10 mm	14.5 mm	4.6±0.2 mm	tin	—	—	350	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKMD1001C471MVTM	VKM	Mass Production	Polarized	16 V	470 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	900 mArms	75.2 µA	24	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKL(U)E1001V221MVTMCG	VKL(U)	Mass Production	Polarized	35 V	220 µF	-20%~+20%	-40 ~ 125 ℃	5000 h	0.3 Ω	100 kHz	400 mArms	77 µA	16	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	—		Apply
		SMD	VKLA0541C100MVTMCG	VKL	Mass Production	Polarized	16 V	10 µF	-20%~+20%	-40 ~ 125 ℃	1000 h	7 Ω	100 kHz	14 mArms	3 µA	19	120 Hz	4 mm	5.4 mm	1.0±0.2 mm	tin	—	—	2000	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VMMC0771J330MVTMCG	VMM	Mass Production	Polarized	63 V	33 µF	-20%~+20%	-55 ~ 105 ℃	4000 h	—	120 kHz	72 mArms	20.79 µA	16	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKLL1601E132MVTMCG	VKL	Mass Production	Polarized	25 V	1300 µF	-20%~+20%	-40 ~ 125 ℃	5000 h	0.07 Ω	100 kHz	1180 mArms	325 µA	14	120 Hz	12.5 mm	16 mm	4.6±0.2 mm	tin	—	—	200	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKOC1201A471MVTM	VKO	Mass Production	Polarized	10 V	470 µF	-20%~+20%	-55 ~ 105 ℃	6000 h	—	100 kHz	650 mArms	47 µA	28	120 Hz	6.3 mm	12 mm	1.8±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VMMD0790J561MVTMCG	VMM	Mass Production	Polarized	6.3 V	560 µF	-20%~+20%	-55 ~ 105 ℃	4000 h	—	120 kHz	231 mArms	35.28 µA	32	120 Hz	8 mm	7.9 mm	3.1±0.2 mm	tin	—	—	600	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKMB1001J220MVTM	VKM	Mass Production	Polarized	63 V	22 µF	-20%~+20%	-55 ~ 105 ℃	7000 h	—	100 kHz	228 mArms	13.86 µA	14	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKLC0771V330MVTMCG	VKL	Mass Production	Polarized	35 V	33 µF	-20%~+20%	-40 ~ 125 ℃	2000 h	0.9 Ω	100 kHz	197 mArms	11.55 µA	16	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKMB1001H220MVTM	VKM	Mass Production	Polarized	50 V	22 µF	-20%~+20%	-55 ~ 105 ℃	7000 h	—	100 kHz	238 mArms	11 µA	14	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VMMB0571H100MVTMCG	VMM	Mass Production	Polarized	50 V	10 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	29 mArms	5 µA	16	120 Hz	5 mm	5.7 mm	1.5±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKLD0621H470MVTMCG	VKL	Mass Production	Polarized	50 V	47 µF	-20%~+20%	-40 ~ 125 ℃	3000 h	1.06 Ω	100 kHz	123 mArms	23.5 µA	14	120 Hz	8 mm	6.2 mm	3.1±0.2 mm	tin	—	—	800	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VMML1351H331MVTMCG	VMM	Mass Production	Polarized	50 V	330 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	415 mArms	165 µA	16	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKO(R)L1352A680MVTM	VKO(R)	Mass Production	Polarized	100 V	68 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	0.32 Ω	100 kHz	500 mArms	68 µA	12	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	—		Apply
		SMD	VKLD1001C331MVTMCG	VKL	Mass Production	Polarized	16 V	330 µF	-20%~+20%	-40 ~ 125 ℃	3000 h	—	100 kHz	380 mArms	52.8 µA	24	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VK7(R)C0771A101MVTM	VK7(R)	Mass Production	Polarized	10 V	100 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	0.85 Ω	120 kHz	230 mArms	10 µA	28	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	—		Apply
		SMD	VKGL2101K331MVTM	VKG	Mass Production	Polarized	80 V	330 µF	-20%~+20%	-55 ~ 105 ℃	12000 h	—	100 kHz	1620 mArms	264 µA	12	120 Hz	12.5 mm	21 mm	4.6±0.2 mm	tin	—	—	175	Extra-long life, High high-frequency ripple current capability, 105°C, Wide voltage & wide temperature range, High capacitance density	✓		Apply
		SMD	VMM(T)C0771V121MVTMCG	VMM(T)	Mass Production	Polarized	35 V	120 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.68 Ω	120 kHz	150 mArms	42 µA	18	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	VMMD0622A180MVTMCG	VMM	Mass Production	Polarized	100 V	18 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	44 mArms	18 µA	14	120 Hz	8 mm	6.2 mm	3.1±0.2 mm	tin	—	—	800	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VK7E0841A471MVTM	VK7	Mass Production	Polarized	10 V	470 µF	-20%~+20%	-55 ~ 105 ℃	6000 h	—	120 kHz	260 mArms	47 µA	28	120 Hz	10 mm	8.4 mm	4.6±0.2 mm	tin	—	—	600	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	✓		Apply
		SMD	VK7E0841H101MVTM	VK7	Mass Production	Polarized	50 V	100 µF	-20%~+20%	-55 ~ 105 ℃	6000 h	—	120 kHz	180 mArms	50 µA	14	120 Hz	10 mm	8.4 mm	4.6±0.2 mm	tin	—	—	600	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	✓		Apply
		SMD	V3M(R)I1651H102MVTMCG	V3M(R)	Mass Production	Polarized	50 V	1000 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.073 Ω	100 kHz	1820 mArms	500 µA	12	120 Hz	16 mm	16.5 mm	6.7±0.2 mm	tin	—	—	150	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	—		Apply
		SMD	V3M(T)E1001V471MVTMCG	V3M(T)	Mass Production	Polarized	35 V	470 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.2 Ω	100 kHz	680 mArms	164.5 µA	12	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	—		Apply

1234…53
