Found 2,613 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	tanδ Frequency (Hz)	Dimension D (mm)	Dimension L (mm)	Terminal Pitch (mm)	Terminal Material	Terminal Type	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		SMD	VKLI2101H102MVTMCG	VKL	Mass Production	Polarized	50 V	1000 µF	-20%~+20%	-40 ~ 125 ℃	5000 h	0.1 Ω	100 kHz	1600 mArms	500 µA	14	120 Hz	16 mm	21 mm	6.7±0.2 mm	tin	—	—	120	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	V3ME1001H331MVTMCG	V3M	Mass Production	Polarized	50 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.24 Ω	100 kHz	900 mArms	165 µA	12	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VMM(R)C0771E101MVTMCG	VMM(R)	Mass Production	Polarized	25 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.54 Ω	120 kHz	200 mArms	25 µA	20	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	V3MC0771A471MVTMCG	V3M	Mass Production	Polarized	10 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.32 Ω	100 kHz	600 mArms	47 µA	19	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	V3M(R)E1001H221MVTMCG	V3M(R)	Mass Production	Polarized	50 V	220 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.25 Ω	100 kHz	670 mArms	110 µA	12	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	—		Apply
		SMD	VMM(R)E1001E471MVTMCG	VMM(R)	Mass Production	Polarized	25 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.15 Ω	120 kHz	800 mArms	117.5 µA	20	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	VMM(T)C0771C221MVTMCG	VMM(T)	Mass Production	Polarized	16 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.52 Ω	120 kHz	194 mArms	35.2 µA	24	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	VKO(T)D1001C471MVTM	VKO(T)	Mass Production	Polarized	16 V	470 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.22 Ω	100 kHz	600 mArms	75.2 µA	24	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	—		Apply
		SMD	VMMC0571V390MVTMCG	VMM	Mass Production	Polarized	35 V	39 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	61 mArms	13.65 µA	18	120 Hz	6.3 mm	5.7 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	V3M(T)C0581C101MVTMCG	V3M(T)	Mass Production	Polarized	16 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.56 Ω	100 kHz	255 mArms	16 µA	16	120 Hz	6.3 mm	5.8 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	—		Apply
		SMD	VKOB1001C220MVTM	VKO	Mass Production	Polarized	16 V	22 µF	-20%~+20%	-55 ~ 105 ℃	6000 h	—	100 kHz	112 mArms	3.52 µA	24	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VKME1301E561MVTM	VKM	Mass Production	Polarized	25 V	560 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	1760 mArms	140 µA	20	120 Hz	10 mm	13 mm	4.6±0.2 mm	tin	—	—	400	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKGB1001H100MVTM	VKG	Mass Production	Polarized	50 V	10 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	100 kHz	100 mArms	5 µA	14	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Extra-long life, High high-frequency ripple current capability, 105°C, Wide voltage & wide temperature range, High capacitance density	✓		Apply
		SMD	VKME1301C821MVTM	VKM	Mass Production	Polarized	16 V	820 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	1760 mArms	131.2 µA	24	120 Hz	10 mm	13 mm	4.6±0.2 mm	tin	—	—	400	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKL(T)J1651K471MVTMCG	VKL(T)	Mass Production	Polarized	80 V	470 µF	-20%~+20%	-40 ~ 125 ℃	2000 h	0.36 Ω	100 kHz	400 mArms	376 µA	12	120 Hz	18 mm	16.5 mm	6.7±0.2 mm	tin	—	—	150	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	—		Apply
		SMD	VK7E0841A221MVTM	VK7	Mass Production	Polarized	10 V	220 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	220 mArms	22 µA	28	120 Hz	10 mm	8.4 mm	4.6±0.2 mm	tin	—	—	600	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	✓		Apply
		SMD	VK7E0841H470MVTM	VK7	Mass Production	Polarized	50 V	47 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	130 mArms	23.5 µA	14	120 Hz	10 mm	8.4 mm	4.6±0.2 mm	tin	—	—	600	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	✓		Apply
		SMD	VKO(R)J1652A221MVTM	VKO(R)	Mass Production	Polarized	100 V	220 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.16 Ω	100 kHz	1000 mArms	220 µA	7	120 Hz	18 mm	16.5 mm	6.7±0.2 mm	tin	—	—	150	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	—		Apply
		SMD	VMME1252V120MVTMCG	VMM	Mass Production	Polarized	350 V	12 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	120 kHz	126 mArms	94 µA	20	120 Hz	10 mm	12.5 mm	4.6±0.2 mm	tin	—	—	400	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMME1002V100MVTMCG	VMM	Mass Production	Polarized	350 V	10 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	120 kHz	105 mArms	80 µA	20	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKL(R)L1351H221MVTMCG	VKL(R)	Mass Production	Polarized	50 V	220 µF	-20%~+20%	-55 ~ 135 ℃	5000 h	0.23 Ω	100 kHz	580 mArms	110 µA	14	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	High temperature resistance, High-frequency high ripple resistance, Long life, Low ESR	✓		Apply
		SMD	VKLL1352A680MVTMCG	VKL	Mass Production	Polarized	100 V	68 µF	-20%~+20%	-40 ~ 125 ℃	5000 h	0.36 Ω	100 kHz	550 mArms	68 µA	12	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKLD1001V101MVTMCG	VKL	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-40 ~ 125 ℃	3000 h	—	100 kHz	324 mArms	35 µA	16	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VMM(R)B0571E100MVTMCG	VMM(R)	Mass Production	Polarized	25 V	10 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	1.2 Ω	120 kHz	114 mArms	3 µA	20	120 Hz	5 mm	5.7 mm	1.5±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	VK7E0771V101MVTM	VK7	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-55 ~ 105 ℃	6000 h	—	120 kHz	180 mArms	35 µA	16	120 Hz	10 mm	7.7 mm	4.6±0.2 mm	tin	—	—	600	Ultra-slim height, Long life, Wide voltage & wide temperature range, Compact size, Low leakage current	✓		Apply
		SMD	VKOD1001E101MVTM	VKO	Mass Production	Polarized	25 V	100 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	100 kHz	390 mArms	25 µA	20	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VMME1251K121MVTMCG	VMM	Mass Production	Polarized	80 V	120 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	250 mArms	96 µA	14	120 Hz	10 mm	12.5 mm	4.6±0.2 mm	tin	—	—	400	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMMB0572C1R5MVTMCG	VMM	Mass Production	Polarized	160 V	1.5 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	—	120 kHz	18 mArms	14.8 µA	15	120 Hz	5 mm	5.7 mm	1.5±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKLE1301J151MVTMCG	VKL	Mass Production	Polarized	63 V	150 µF	-20%~+20%	-40 ~ 125 ℃	2000 h	—	100 kHz	490 mArms	94.5 µA	14	120 Hz	10 mm	13 mm	4.6±0.2 mm	tin	—	—	400	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKGC1001A221MVTM	VKG	Mass Production	Polarized	10 V	220 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	310 mArms	22 µA	28	120 Hz	6.3 mm	10 mm	1.8±0.2 mm	tin	—	—	700	Extra-long life, High high-frequency ripple current capability, 105°C, Wide voltage & wide temperature range, High capacitance density	✓		Apply
		SMD	VKMC1002D6R8MVTM	VKM	Mass Production	Polarized	200 V	6.8 µF	-20%~+20%	-40 ~ 105 ℃	9000 h	—	100 kHz	140 mArms	37.2 µA	15	120 Hz	6.3 mm	10 mm	1.8±0.2 mm	tin	—	—	700	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	V3MA0541H3R3MVTMCG	V3M	Mass Production	Polarized	50 V	3.3 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	13.8 Ω	100 kHz	28 mArms	3 µA	12	120 Hz	4 mm	5.4 mm	1.0±0.2 mm	tin	—	—	2000	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKOD1252W3R3MVTM	VKO	Mass Production	Polarized	450 V	3.3 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	100 kHz	140 mArms	39.7 µA	20	120 Hz	8 mm	12.5 mm	3.1±0.2 mm	tin	—	—	400	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VMMD0621A221MVTMCG	VMM	Mass Production	Polarized	10 V	220 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	200 mArms	22 µA	28	120 Hz	8 mm	6.2 mm	3.1±0.2 mm	tin	—	—	800	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKML1702E560MVTM	VKM	Mass Production	Polarized	250 V	56 µF	-20%~+20%	-40 ~ 105 ℃	10000 h	—	100 kHz	960 mArms	290 µA	15	120 Hz	12.5 mm	17 mm	4.6±0.2 mm	tin	—	—	200	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VMML1352A101MVTMCG	VMM	Mass Production	Polarized	100 V	100 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	310 mArms	100 µA	14	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMML1651K331MVTMCG	VMM	Mass Production	Polarized	80 V	330 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	480 mArms	264 µA	14	120 Hz	12.5 mm	16.5 mm	4.6±0.2 mm	tin	—	—	200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKOE1002E100MVTM	VKO	Mass Production	Polarized	250 V	10 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	100 kHz	365 mArms	60 µA	15	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VMM(T)E1001E471MVTMCG	VMM(T)	Mass Production	Polarized	25 V	470 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.15 Ω	120 kHz	567 mArms	117.5 µA	20	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	V3ME1001E821MVTMCG	V3M	Mass Production	Polarized	25 V	820 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.12 Ω	100 kHz	1190 mArms	205 µA	14	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKO(T)E1001J121MVTM	VKO(T)	Mass Production	Polarized	63 V	120 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.45 Ω	100 kHz	500 mArms	75.6 µA	14	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	—		Apply
		SMD	VKO(T)E1001J101MVTM	VKO(T)	Mass Production	Polarized	63 V	100 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.45 Ω	100 kHz	500 mArms	63 µA	14	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	—		Apply
		SMD	VKME2101J391MVTM	VKM	Mass Production	Polarized	63 V	390 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	1870 mArms	245.7 µA	14	120 Hz	10 mm	21 mm	4.6±0.2 mm	tin	—	—	175	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VMML1351H471MVTMCG	VMM	Mass Production	Polarized	50 V	470 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	500 mArms	235 µA	16	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKML1701V102MVTM	VKM	Mass Production	Polarized	35 V	1000 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	2480 mArms	350 µA	16	120 Hz	12.5 mm	17 mm	4.6±0.2 mm	tin	—	—	200	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	V3MI1651E272MVTMCG	V3M	Mass Production	Polarized	25 V	2700 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.054 Ω	100 kHz	1910 mArms	675 µA	16	120 Hz	16 mm	16.5 mm	6.7±0.2 mm	tin	—	—	150	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKL(T)D1001V101MVTMCG	VKL(T)	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-40 ~ 125 ℃	3000 h	0.2 Ω	100 kHz	340 mArms	35 µA	16	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	—		Apply
		SMD	VMM(U)C0571C470MVTMCG	VMM(U)	Mass Production	Polarized	16 V	47 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	4 Ω	120 kHz	50 mArms	7.52 µA	24	120 Hz	6.3 mm	5.7 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	VKM(T)L1702A181MVTM	VKM(T)	Mass Production	Polarized	100 V	180 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	1530 mArms	180 µA	12	120 Hz	12.5 mm	17 mm	4.6±0.2 mm	tin	—	—	200	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	—		Apply
		SMD	VKME1302E150MVTM	VKM	Mass Production	Polarized	250 V	15 µF	-20%~+20%	-40 ~ 105 ℃	10000 h	—	100 kHz	320 mArms	85 µA	15	120 Hz	10 mm	13 mm	4.6±0.2 mm	tin	—	—	400	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
