Filters1

Liquid Aluminum Electrolytic

Clear All Filters

Found 2,613 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	tanδ Frequency (Hz)	Dimension D (mm)	Dimension L (mm)	Terminal Pitch (mm)	Terminal Material	Terminal Type	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		SMD	VMMD0622W1R8MVTMCG	VMM	Mass Production	Polarized	450 V	1.8 µF	-20%~+20%	-40 ~ 105 ℃	3000 h	—	120 kHz	37 mArms	26.2 µA	20	120 Hz	8 mm	6.2 mm	3.1±0.2 mm	tin	—	—	800	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMML1352G150MVTMCG	VMM	Mass Production	Polarized	400 V	15 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	120 kHz	150 mArms	130 µA	20	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMM(R)C0771A221MVTMCG	VMM(R)	Mass Production	Polarized	10 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.39 Ω	120 kHz	400 mArms	22 µA	28	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	VMME0841C471MVTMCG	VMM	Mass Production	Polarized	16 V	470 µF	-20%~+20%	-55 ~ 105 ℃	4000 h	—	120 kHz	295 mArms	75.2 µA	24	120 Hz	10 mm	8.4 mm	4.6±0.2 mm	tin	—	—	600	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKMB1001C470MVTM	VKM	Mass Production	Polarized	16 V	47 µF	-20%~+20%	-55 ~ 105 ℃	7000 h	—	100 kHz	161 mArms	7.52 µA	24	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKLJ2101K681MVTMCG	VKL	Mass Production	Polarized	80 V	680 µF	-20%~+20%	-40 ~ 125 ℃	40000 h	0.1 Ω	100 kHz	2600 mArms	544 µA	12	120 Hz	18 mm	21 mm	6.7±0.2 mm	tin	—	—	120	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VMML1651J471MVTMCG	VMM	Mass Production	Polarized	63 V	470 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	480 mArms	296.1 µA	16	120 Hz	12.5 mm	16.5 mm	4.6±0.2 mm	tin	—	—	200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKLI2101J471MVTMCG	VKL	Mass Production	Polarized	63 V	470 µF	-20%~+20%	-40 ~ 125 ℃	5000 h	0.188 Ω	100 kHz	1570 mArms	296.1 µA	14	120 Hz	16 mm	21 mm	6.7±0.2 mm	tin	—	—	120	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VMME1651H471MVTMCG	VMM	Mass Production	Polarized	50 V	470 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	—	120 kHz	500 mArms	235 µA	16	120 Hz	10 mm	16.5 mm	4.6±0.2 mm	tin	—	—	350	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKOL1651H471MVTM	VKO	Mass Production	Polarized	50 V	470 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	100 kHz	1080 mArms	235 µA	14	120 Hz	12.5 mm	16.5 mm	4.6±0.2 mm	tin	—	—	200	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	V3ML1351H391MVTMCG	V3M	Mass Production	Polarized	50 V	390 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.12 Ω	100 kHz	600 mArms	195 µA	12	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VMME0691J560MVTMCG	VMM	Mass Production	Polarized	63 V	56 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	98 mArms	35.28 µA	16	120 Hz	10 mm	6.9 mm	4.6±0.2 mm	tin	—	—	800	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMM(T)E1001V471MVTMCG	VMM(T)	Mass Production	Polarized	35 V	470 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	0.24 Ω	120 kHz	570 mArms	164.5 µA	12	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	V3MCC0770J821MVTMCG	V3MC	Mass Production	有	6.3 V	820 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.24 Ω	100 kHz	610 mArms	51.66 µA	26	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	镀锡	—	—	900	超高容量密度、超低 ESR、高纹波电流、耐高温回流焊	✓		Apply
		SMD	V3MC0771J470MVTMCG	V3M	Mass Production	Polarized	63 V	47 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	1 Ω	100 kHz	320 mArms	29.61 µA	14	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKMB1001C101MVTM	VKM	Mass Production	Polarized	16 V	100 µF	-20%~+20%	-55 ~ 105 ℃	7000 h	—	100 kHz	345 mArms	16 µA	24	120 Hz	5 mm	10 mm	1.5±0.2 mm	tin	—	—	700	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKME1301E681MVTM	VKM	Mass Production	Polarized	25 V	680 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	1760 mArms	170 µA	20	120 Hz	10 mm	13 mm	4.6±0.2 mm	tin	—	—	400	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VMMD0771V101MVTMCG	VMM	Mass Production	Polarized	35 V	100 µF	-20%~+20%	-55 ~ 105 ℃	4000 h	—	120 kHz	160 mArms	35 µA	18	120 Hz	8 mm	7.7 mm	3.1±0.2 mm	tin	—	—	600	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKOI1652W100MVTM	VKO	Mass Production	Polarized	450 V	10 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	100 kHz	312 mArms	100 µA	20	120 Hz	16 mm	16.5 mm	6.7±0.2 mm	tin	—	—	150	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VMML1652V330MVTMCG	VMM	Mass Production	Polarized	350 V	33 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	120 kHz	182 mArms	241 µA	20	120 Hz	12.5 mm	16.5 mm	4.6±0.2 mm	tin	—	—	200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMM(U)B0581A101MVTMCG	VMM(U)	Mass Production	Polarized	10 V	100 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	—	120 kHz	65 mArms	10 µA	24	120 Hz	5 mm	5.8 mm	1.5±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	—		Apply
		SMD	VKM(T)E1001C681MVTM	VKM(T)	Mass Production	Polarized	16 V	680 µF	-20%~+20%	-55 ~ 105 ℃	5000 h	0.15 Ω	100 kHz	850 mArms	108.8 µA	24	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	—		Apply
		SMD	VKLC1002W1R0MVTMCG	VKL	Mass Production	Polarized	450 V	1 µF	-20%~+20%	-25 ~ 125 ℃	2000 h	—	100 kHz	60 mArms	19 µA	20	120 Hz	6.3 mm	10 mm	1.8±0.2 mm	tin	—	—	700	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKOI2102C181MVTM	VKO	Mass Production	Polarized	160 V	180 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	100 kHz	1520 mArms	586 µA	15	120 Hz	16 mm	21 mm	6.7±0.2 mm	tin	—	—	120	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VKOI2102C151MVTM	VKO	Mass Production	Polarized	160 V	150 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	100 kHz	1260 mArms	490 µA	15	120 Hz	16 mm	21 mm	6.7±0.2 mm	tin	—	—	120	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VKGC1001K120MVTM	VKG	Mass Production	Polarized	80 V	12 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	150 mArms	9.6 µA	12	120 Hz	6.3 mm	10 mm	1.8±0.2 mm	tin	—	—	700	Extra-long life, High high-frequency ripple current capability, 105°C, Wide voltage & wide temperature range, High capacitance density	✓		Apply
		SMD	VKMI2101K681MVTM	VKM	Mass Production	Polarized	80 V	680 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	2270 mArms	544 µA	12	120 Hz	16 mm	21 mm	6.7±0.2 mm	tin	—	—	120	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKMD1452G6R8MVTM	VKM	Mass Production	Polarized	400 V	6.8 µF	-20%~+20%	-40 ~ 105 ℃	10000 h	—	100 kHz	220 mArms	64.4 µA	15	120 Hz	8 mm	14.5 mm	3.1±0.2 mm	tin	—	—	350	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKML1702H120MVTM	VKM	Mass Production	Polarized	500 V	12 µF	-20%~+20%	-40 ~ 105 ℃	10000 h	—	100 kHz	270 mArms	130 µA	25	120 Hz	12.5 mm	17 mm	4.6±0.2 mm	tin	—	—	200	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKLL1351V681MVTMCG	VKL	Mass Production	Polarized	35 V	680 µF	-20%~+20%	-40 ~ 125 ℃	5000 h	0.14 Ω	100 kHz	750 mArms	238 µA	16	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	V3MC0772A220MVTMCG	V3M	Mass Production	Polarized	100 V	22 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	4.73 Ω	100 kHz	150 mArms	22 µA	12	120 Hz	6.3 mm	7.7 mm	1.8±0.2 mm	tin	—	—	900	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VMMB0572A3R3MVTMCG	VMM	Mass Production	Polarized	100 V	3.3 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	16 mArms	3.3 µA	14	120 Hz	5 mm	5.7 mm	1.5±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMME1001E681MVTMCG	VMM	Mass Production	Polarized	25 V	680 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	580 mArms	170 µA	20	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMME1251E681MVTMCG	VMM	Mass Production	Polarized	25 V	680 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	640 mArms	170 µA	20	120 Hz	10 mm	12.5 mm	4.6±0.2 mm	tin	—	—	400	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKME1651K221MVTM	VKM	Mass Production	Polarized	80 V	220 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	1040 mArms	176 µA	12	120 Hz	10 mm	16.5 mm	4.6±0.2 mm	tin	—	—	350	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VMMJ2102C221MVTMCG	VMM	Mass Production	Polarized	160 V	220 µF	-20%~+20%	-40 ~ 105 ℃	8000 h	—	120 kHz	835 mArms	714 µA	15	120 Hz	18 mm	21 mm	6.7±0.2 mm	tin	—	—	120	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKOE1301V331MVTM	VKO	Mass Production	Polarized	35 V	330 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	100 kHz	1330 mArms	115.5 µA	16	120 Hz	10 mm	13 mm	4.6±0.2 mm	tin	—	—	400	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	V3MCE1001V681MVTMCG	V3MC	Mass Production	有	35 V	680 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	0.09 Ω	100 kHz	1200 mArms	238 µA	12	120 Hz	10 mm	10 mm	4.6±0.2 mm	镀锡	—	—	500	超高容量密度、超低 ESR、高纹波电流、耐高温回流焊	✓		Apply
		SMD	VMMD0620J331MVTMCG	VMM	Mass Production	Polarized	6.3 V	330 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	135 mArms	20.79 µA	32	120 Hz	8 mm	6.2 mm	3.1±0.2 mm	tin	—	—	800	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMML1351K221MVTMCG	VMM	Mass Production	Polarized	80 V	220 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	320 mArms	176 µA	14	120 Hz	12.5 mm	13.5 mm	4.6±0.2 mm	tin	—	—	250	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VMME0772A470MVTMCG	VMM	Mass Production	Polarized	100 V	47 µF	-20%~+20%	-55 ~ 105 ℃	4000 h	—	120 kHz	140 mArms	47 µA	14	120 Hz	10 mm	7.7 mm	4.6±0.2 mm	tin	—	—	600	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKLE1001V471MVTMCG	VKL	Mass Production	Polarized	35 V	470 µF	-20%~+20%	-40 ~ 125 ℃	2000 h	0.2 Ω	100 kHz	780 mArms	164.5 µA	16	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VMMC0571H180MVTMCG	VMM	Mass Production	Polarized	50 V	18 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	—	120 kHz	55 mArms	9 µA	16	120 Hz	6.3 mm	5.7 mm	1.8±0.2 mm	tin	—	—	1200	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply
		SMD	VKLD1001H101MVTMCG	VKL	Mass Production	Polarized	50 V	100 µF	-20%~+20%	-40 ~ 125 ℃	3000 h	0.51 Ω	100 kHz	350 mArms	50 µA	14	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	Low Leakage Current, High Temp Resistant, Long Life @ High Temp, High Ripple Current	✓		Apply
		SMD	VKML1702A181MVTM	VKM	Mass Production	Polarized	100 V	180 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	1530 mArms	180 µA	12	120 Hz	12.5 mm	17 mm	4.6±0.2 mm	tin	—	—	200	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	V3MA0581A680MVTMCG	V3M	Mass Production	Polarized	10 V	68 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	2 Ω	100 kHz	160 mArms	6.8 µA	19	120 Hz	4 mm	5.8 mm	1.0±0.2 mm	tin	—	—	2000	Low ESR, Low Impedance at High Frequency, High Ripple Current, Miniature Size, High Capacitance Density, Wide Temperature Range, RoHS Compliant	✓		Apply
		SMD	VKME2101A272MVTM	VKM	Mass Production	Polarized	10 V	2700 µF	-20%~+20%	-55 ~ 105 ℃	10000 h	—	100 kHz	2250 mArms	270 µA	30	120 Hz	10 mm	21 mm	4.6±0.2 mm	tin	—	—	175	Miniaturized, high capacitance density, high ripple current capability, low temperature rise, low leakage current, RoHS compliant	✓		Apply
		SMD	VKOD1001H680MVTM	VKO	Mass Production	Polarized	50 V	68 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	100 kHz	666 mArms	34 µA	14	120 Hz	8 mm	10 mm	3.1±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VKOE1001E471MVTM	VKO	Mass Production	Polarized	25 V	470 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	100 kHz	850 mArms	117.5 µA	20	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	High temperature resistance, small size & high capacitance density, high ripple current, low ESR, wide temperature range, long service life	✓		Apply
		SMD	VMME1001E471MVTMCG	VMM	Mass Production	Polarized	25 V	470 µF	-20%~+20%	-55 ~ 105 ℃	8000 h	—	120 kHz	490 mArms	117.5 µA	20	120 Hz	10 mm	10 mm	4.6±0.2 mm	tin	—	—	500	Low ESR, high ripple current capability, RoHS compliant, wide temperature range, long service life	✓		Apply

1…91011…53
