Filters1

Stacked Polymer Solid Aluminum Electrolytic

Clear All Filters

Found 156 resultsDefaultVoltage Low to HighCapacity Low to HighLife High to Low

Compare	Product Image	Package Form	Part Number	Series	Lifecycle Status	Polarity	Rated Voltage (V)	Nominal Cap.	Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	Leakage Current Max	tanδ max.	Dimension L (mm)	Width W (mm)	Dimension H (mm)	Terminal Pitch (mm)	Terminal Material	Weight	Min. Package Qty	Feature Tags	AEC-Q200	PDF	3D-CAD
		SMD	MPD331M0JD19009R	MPD19	Mass Production	Polarized	4 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	132 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.135 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD6R8M1KD28040R	MPD28	Mass Production	Polarized	80 V	6.8 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	54.4 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPX471M0ED19006RC	MPX	Mass Production	Polarized	2.5 V	470 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	6 mΩ	100 kHz	7500 mArms	117.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.146 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	✓		Apply
		SMD	MPD220M1CD19040R	MPD19	Mass Production	Polarized	16 V	22 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	35.2 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD150M1CD15080R	MPD15	Mass Production	Polarized	16 V	15 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	80 mΩ	100 kHz	2200 mArms	24 µA	6	7.3 mm	4.3 mm	1.5 mm	6 mm	Ni/Sn	0 g	4000	Polarized, thin profile, laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	—		Apply
		SMD	MPX471M0DD19003RC	MPX	Mass Production	Polarized	2 V	470 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	3 mΩ	100 kHz	10200 mArms	94 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.138 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	✓		Apply
		SMD	MPX471M0ED194R5RC	MPX	Mass Production	Polarized	2.5 V	470 µF	-20%~+20%	-55 ~ 105 ℃	3000 h	4.5 mΩ	100 kHz	8500 mArms	117.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.145 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	✓		Apply
		SMD	MPS471M0DD19003R	MPS	Mass Production	Polarized	2 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	3 mΩ	100 kHz	10200 mArms	94 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.144 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPS471M0ED19003R	MPS	Mass Production	Polarized	2.5 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	3 mΩ	100 kHz	10200 mArms	117.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.148 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD6R8M1KD28080R	MPD28	Mass Production	Polarized	80 V	6.8 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	80 mΩ	100 kHz	2200 mArms	54.4 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD471M0LD28009R	MPD28	Mass Production	Polarized	6.3 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	296.1 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.186 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD471M0LD28015R	MPD28	Mass Production	Polarized	6.3 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	15 mΩ	100 kHz	5100 mArms	296.1 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.186 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD471M0LD28012R	MPD28	Mass Production	Polarized	6.3 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	12 mΩ	100 kHz	5600 mArms	296.1 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.186 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD331M0LD28009R	MPD28	Mass Production	Polarized	6.3 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	207.9 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.181 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD331M0LD28007R	MPD28	Mass Production	Polarized	6.3 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	7 mΩ	100 kHz	7000 mArms	207.9 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.181 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD331M0LD28018R	MPD28	Mass Production	Polarized	6.3 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	18 mΩ	100 kHz	4600 mArms	207.9 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.181 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD331M0LD28015R	MPD28	Mass Production	Polarized	6.3 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	15 mΩ	100 kHz	5100 mArms	207.9 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.181 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD331M0LD28012R	MPD28	Mass Production	Polarized	6.3 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	12 mΩ	100 kHz	5600 mArms	207.9 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.181 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD150M1HD28040R	MPD28	Mass Production	Polarized	50 V	15 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	75 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD471M0JD28009R	MPD28	Mass Production	Polarized	4 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	188 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.18 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD471M0JD28007R	MPD28	Mass Production	Polarized	4 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	7 mΩ	100 kHz	7000 mArms	188 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.18 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD471M0JD28018R	MPD28	Mass Production	Polarized	4 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	18 mΩ	100 kHz	4600 mArms	188 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.18 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD471M0JD28015R	MPD28	Mass Production	Polarized	4 V	470 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	15 mΩ	100 kHz	5100 mArms	188 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.18 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD470M1VD28040R	MPD28	Mass Production	Polarized	35 V	47 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	164.5 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.185 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD330M1VD28040R	MPD28	Mass Production	Polarized	35 V	33 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	115.5 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.173 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD680M1ED28040R	MPD28	Mass Production	Polarized	25 V	68 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	170 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.173 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD101M1ED28025R	MPD28	Mass Production	Polarized	25 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	25 mΩ	100 kHz	3800 mArms	250 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.184 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD101M1ED28020R	MPD28	Mass Production	Polarized	25 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	20 mΩ	100 kHz	4200 mArms	250 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.184 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD101M1DD28040R	MPD28	Mass Production	Polarized	20 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	200 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.181 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD681M0ED284R5R	MPD28	Mass Production	Polarized	2.5 V	680 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	4.5 mΩ	100 kHz	8500 mArms	170 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.182 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD151M1CD28040R	MPD28	Mass Production	Polarized	16 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	240 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.181 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD151M1CD28015R	MPD28	Mass Production	Polarized	16 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	15 mΩ	100 kHz	5100 mArms	240 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0.181 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD221M1AD28040R	MPD28	Mass Production	Polarized	10 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	220 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD221M1AD28025R	MPD28	Mass Production	Polarized	10 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	25 mΩ	100 kHz	3800 mArms	220 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD221M1AD28010R	MPD28	Mass Production	Polarized	10 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	10 mΩ	100 kHz	5900 mArms	220 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD4R7M2AD28080R	MPD28	Mass Production	Polarized	100 V	4.7 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	80 mΩ	100 kHz	2200 mArms	47 µA	6	7.3 mm	4.3 mm	2.8 mm	6 mm	Ni/Sn	0 g	3000	Polarized, thin profile , laminated structure, low ESR, high ripple current, high voltage resistant, wide temperature range, ultra-high capacitance density, , RoHS compliant	—		Apply
		SMD	MPD22130LD19012R	MPD19	Mass Production	Polarized	6.3 V	220 µF	-30%~+10%	-55 ~ 105 ℃	2000 h	12 mΩ	100 kHz	5600 mArms	138.6 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.138 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD221M0LD19009R	MPD19	Mass Production	Polarized	6.3 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	9 mΩ	100 kHz	6300 mArms	138.6 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.138 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD221M0LD19018R	MPD19	Mass Production	Polarized	6.3 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	18 mΩ	100 kHz	4600 mArms	138.6 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.138 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD221M0LD19015R	MPD19	Mass Production	Polarized	6.3 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	15 mΩ	100 kHz	5100 mArms	138.6 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.138 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD221M0LD19012R	MPD19	Mass Production	Polarized	6.3 V	220 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	12 mΩ	100 kHz	5600 mArms	138.6 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.138 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD151M0LD19015R	MPD19	Mass Production	Polarized	6.3 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	15 mΩ	100 kHz	5100 mArms	94.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.133 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD151M0LD19012R	MPD19	Mass Production	Polarized	6.3 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	12 mΩ	100 kHz	5600 mArms	94.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.133 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD151M0LD19010R	MPD19	Mass Production	Polarized	6.3 V	150 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	10 mΩ	100 kHz	5900 mArms	94.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.133 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD101M0LD19030R	MPD19	Mass Production	Polarized	6.3 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	30 mΩ	100 kHz	3500 mArms	63 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.131 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD101M0LD19020R	MPD19	Mass Production	Polarized	6.3 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	20 mΩ	100 kHz	4200 mArms	63 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.131 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD101M0LD19015R	MPD19	Mass Production	Polarized	6.3 V	100 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	15 mΩ	100 kHz	5100 mArms	63 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.131 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD100M1HD19040R	MPD19	Mass Production	Polarized	50 V	10 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	50 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.143 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD331M0JD19006R	MPD19	Mass Production	Polarized	4 V	330 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	6 mΩ	100 kHz	7500 mArms	132 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.135 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
		SMD	MPD330M1VD19040R	MPD19	Mass Production	Polarized	35 V	33 µF	-20%~+20%	-55 ~ 105 ℃	2000 h	40 mΩ	100 kHz	3200 mArms	115.5 µA	6	7.3 mm	4.3 mm	1.9 mm	6 mm	Ni/Sn	0.138 g	3500	Polarized, thin profile , laminated structure, low ESR, high ripple current, wide temperature range, high capacitance, RoHS compliant	✓		Apply
