Found 670 results
| Compare | Package Form | Product Image | Product Line | Lifecycle Status | Polarity | Tolerance | Operating Temp. (℃) | Rated Life (Hours) | ESR (max.) | ESR Frequency | Rated Ripple Current | 72h Leakage Current (μA) | Max Charge Voltage (V) | Max Charge Current (A) | Peak Current (A) | Continuous Current (A) | Terminal Pitch (mm) | Terminal Material | Weight | Min. Package Qty | Feature Tags | Remark | Dimension L (mm) | AEC-Q200 | 3D-CAD | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Module Type |  | Electric Double-Layer Supercapacitor | SDMG5R5M5041614 | SDM(G) | Mass Production | polarized | 5.5 V | 0.5 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 600 mΩ | 1 kHz | — | 2 µA | 5.5 V | 0.252293577981651 A | 0.948275862068966 A | 0.252293577981651 A | 11.5 mm | tin | 0 g | 250 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量0.47F参考 | 8 mm | 16 mm | — | Apply | ||
| Module Type |  | Electric Double-Layer Supercapacitor | SMG5R5M1051919 | SM(G) | Mass Production | polarized | 5.5 V | 1 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 240 mΩ | 1 kHz | — | 4 µA | 5.5 V | 0.513059701492537 A | 2.02205882352941 A | 0.513059701492537 A | 11.5 mm | tin | 0 g | 750 | Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考 | 10 mm | 18.5 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SMG5R5M1051917 | SM(G) | Mass Production | polarized | 5.5 V | 1 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 240 mΩ | 1 kHz | — | 4 µA | 5.5 V | 0.513059701492537 A | 2.02205882352941 A | 0.513059701492537 A | 11.5 mm | tin | 0 g | 750 | Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考 | 10 mm | 18.5 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDS2R7L1061020 | SDS | Mass Production | polarized | 2.7 V | 10 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 80 mΩ | 1 kHz | — | 40 µA | 2.7 V | 2.17741935483871 A | 6.13636363636364 A | 2.17741935483871 A | 5 mm | tin | 0 g | 250 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 20 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L1061030 | SDL | Mass Production | polarized | 2.7 V | 10 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 40 mΩ | 1 kHz | — | 20 µA | 2.7 V | 2.41071428571429 A | 8.4375 A | 2.41071428571429 A | 5 mm | tin | 0 g | 150 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 30 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDB3R0L3351013 | SDB | Mass Production | polarized | 3 V | 3.3 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 100 mΩ | 1 kHz | — | 6 µA | 3 V | 0.900818926296633 A | 3.31103678929766 A | 0.900818926296633 A | 5 mm | tin | 0 g | 500 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 13 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L1550611 | SDS | Mass Production | polarized | 2.7 V | 1.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 400 mΩ | 1 kHz | — | 5 µA | 2.7 V | 0.343220338983051 A | 1.06578947368421 A | 0.343220338983051 A | 2.5 mm | tin | 0 g | 1000 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 6.3 mm | 11 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L5051020 | SDB | Mass Production | polarized | 3 V | 5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 80 mΩ | 1 kHz | — | 10 µA | 3 V | 1.33928571428571 A | 4.6875 A | 1.33928571428571 A | 5 mm | tin | 0 g | 250 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 20 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L3351016 | SDL | Mass Production | polarized | 2.7 V | 3.3 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 70 mΩ | 1 kHz | — | 6 µA | 2.7 V | 0.833255400729449 A | 3.30857779428147 A | 0.833255400729449 A | 5 mm | tin | 0 g | 500 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 16 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L7051016 | SDS | Mass Production | polarized | 2.7 V | 7 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 100 mΩ | 1 kHz | — | 25 µA | 2.7 V | 1.56198347107438 A | 4.60975609756098 A | 1.56198347107438 A | 5 mm | tin | 0 g | 500 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 16 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L1061025 | SDH | Mass Production | Polarized | 2.7 V | 10 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 40 mΩ | 1 kHz | — | 30 µA | 2.7 V | 2.41071428571429 A | 8.4375 A | 2.41071428571429 A | 5 mm | tin | 0 g | 250 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 25 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L7551020 | SDH | Mass Production | Polarized | 2.7 V | 7.5 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 50 mΩ | 1 kHz | — | 20 µA | 2.7 V | 1.82022471910112 A | 6.48 A | 1.82022471910112 A | 5 mm | tin | 0 g | 250 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量7F参考 | 10 mm | 20 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L1050611 | SDS | Mass Production | polarized | 2.7 V | 1 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 600 mΩ | 1 kHz | — | 4 µA | 2.7 V | 0.228813559322034 A | 0.710526315789474 A | 0.228813559322034 A | 2.5 mm | tin | 0 g | 1000 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 6.3 mm | 11 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L1550813 | SDB | Mass Production | polarized | 3 V | 1.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 160 mΩ | 1 kHz | — | 3 µA | 3 V | 0.419776119402985 A | 1.65441176470588 A | 0.419776119402985 A | 3.5 mm | tin | 0 g | 500 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考 | 8 mm | 13 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L3350813 | SDS | Mass Production | polarized | 2.7 V | 3.3 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 160 mΩ | 1 kHz | — | 14 µA | 2.7 V | 0.769164364640884 A | 2.48604910714286 A | 0.769164364640884 A | 3.5 mm | tin | 0 g | 500 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 13 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L2050809 | SDS | Mass Production | polarized | 2.7 V | 2 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 300 mΩ | 1 kHz | — | 6 µA | 2.7 V | 0.457627118644068 A | 1.42105263157895 A | 0.457627118644068 A | 3.5 mm | tin | 0 g | 500 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 9 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L5040512 | SDB | Mass Production | polarized | 3 V | 0.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 240 mΩ | 1 kHz | — | 3 µA | 3 V | 0.144787644787645 A | 0.635593220338983 A | 0.144787644787645 A | 2 mm | tin | 0 g | 1000 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考 | 5 mm | 12 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L1561316 | SDS | Mass Production | polarized | 2.7 V | 15 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 70 mΩ | 1 kHz | — | 50 µA | 2.7 V | 3.07984790874525 A | 7.86407766990291 A | 3.07984790874525 A | 5 mm | tin | 0 g | 125 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 16 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDLG2R7L5051020 | SDL（G） | Mass Production | polarized | 2.7 V | 5 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 60 mΩ | 1 kHz | — | 10 µA | 2.7 V | 1.23853211009174 A | 4.6551724137931 A | 1.23853211009174 A | 5 mm | tin | 0 g | 250 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 20 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDBH3R0L1061320 | SDB(H) | Mass Production | polarized | 3 V | 10 F | -10%~+30% | -40 ~ 105 ℃ | 1000 h | 60 mΩ | 1 kHz | — | 20 µA | 3 V | 2.54237288135593 A | 7.89473684210526 A | 2.54237288135593 A | 5 mm | tin | 0 g | 100 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 20 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDLG2R7L7051016 | SDL（G） | Mass Production | polarized | 2.7 V | 7 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 50 mΩ | 1 kHz | — | 14 µA | 2.7 V | 1.710407239819 A | 6.19672131147541 A | 1.710407239819 A | 5 mm | tin | 0 g | 500 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 16 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L1061320 | SDB | Mass Production | polarized | 3 V | 10 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 60 mΩ | 1 kHz | — | 20 µA | 3 V | 2.54237288135593 A | 7.89473684210526 A | 2.54237288135593 A | 5 mm | tin | 0 g | 100 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 20 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L2250816 | SDL | Mass Production | polarized | 2.7 V | 2.2 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 120 mΩ | 1 kHz | — | 4 µA | 2.7 V | 0.550407709414381 A | 2.12750716332378 A | 0.550407709414381 A | 3.5 mm | tin | 0 g | 500 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量2F参考 | 8 mm | 16 mm | — | Apply | ||
| Snap-in |  | Electric Double-Layer Supercapacitor | SDN3R0S4773560 | SDN | Mass Production | polarized | 3 V | 470 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 3 mΩ | 1 kHz | 0 mArms | 450 µA | 3 V | 133.33333333333334 A | 226.32423756019264 A | 99.08643710470837 A | 10 mm | tin | 73.5 g | 100 | RoHS Compliant, Ultra High Capacity, High Energy Density, High Power Output, High Current Discharge, Low ESR, Long Cycle Life, Wide Temperature Range, Fast Charge & Discharge | — | 35 mm | 60 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDLH2R7L2561625 | SDL(H) | Mass Production | polarized | 2.7 V | 25 F | -10%~+30% | -40 ~ 105 ℃ | 1000 h | 24 mΩ | 1 kHz | 0 mArms | 50 µA | 2.7 V | 15.000000000000002 A | 17.763157894736842 A | 5.720338983050847 A | 7.5 mm | tin | 6.9 g | 176 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 16 mm | 25 mm | ✓ | Apply | ||
| Li-ion Capacitor |  | Hybrid Supercapacitor (Lithium-ion Capacitor) | SLAH3R8O2571620 | SLA(H) | Mass Production | polarized | 3.8 V | 250 F | -10%~+30% | -40 ~ 90 ℃ | 1000 h | 50 mΩ | 1 kHz | 0 mArms | 6 µA | 4.2 V | 2 A | 10 A | 0.8 A | 7.5 mm | 锡 | 8.1 g | 240 | Leaded, Polarized, Automotive Grade, AEC-Q200 Qualified, Long Cycle Life, Ultra Wide Temperature Range, High Temperature Resistant, Smart Cabin, IoT Device | — | 16 mm | 20 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L3561630 | SDB | Mass Production | polarized | 3 V | 35 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 28 mΩ | 1 kHz | 0 mArms | 70 µA | 3 V | 14.285714285714285 A | 21.255060728744937 A | 8.11437403400309 A | 7.5 mm | tin | 7.9 g | 176 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 16 mm | 30 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L2561625 | SDH | Mass Production | Polarized | 2.7 V | 25 F | +10%~+30% | -40 ~ 85 ℃ | 1000 h | 25 mΩ | 1 kHz | 0 mArms | 60 µA | 2.7 V | 14.4 A | 17.419354838709676 A | 5.684210526315789 A | 7.5 mm | tin | 7.1 g | 50 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1; leakage current shall refer to the 1F of adjacent capacitance in the same series as specified in Appendix 3 | 16 mm | 25 mm | ✓ | Apply | ||
| Snap-in | | Electric Double-Layer Supercapacitor | SDN3R0S2073050 | SDN | Mass Production | polarized | 3 V | 200 F | 0%~+30% | -40 ~ 70 ℃ | 1000 h | 6 mΩ | 1 kHz | 0 mArms | 240 µA | 3 V | 66.66666666666667 A | 107.14285714285715 A | 44.11764705882353 A | 10 mm | tin | 37.5 g | 20 | RoHS Compliant, Ultra High Capacity, High Energy Density, High Power Output, High Current Discharge, Low ESR, Long Cycle Life, Wide Temperature Range, Fast Charge & Discharge | — | 30 mm | 50 mm | — | Apply | ||
| Snap-in | | Electric Double-Layer Supercapacitor | SDN2R7S1272250 | SDN | Mass Production | polarized | 2.7 V | 120 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 12 mΩ | 1 kHz | 0 mArms | 180 µA | 2.7 V | 30.000000000000004 A | 51.26582278481013 A | 22.625698324022345 A | 10 mm | tin | 22.5 g | 200 | RoHS Compliant, Ultra High Capacity, High Energy Density, High Power Output, High Current Discharge, Low ESR, Long Cycle Life, Wide Temperature Range, Fast Charge & Discharge | — | 22 mm | 50 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L4061640 | SDB | Mass Production | polarized | 3 V | 40 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 26 mΩ | 1 kHz | 0 mArms | 80 µA | 3 V | 15.384615384615383 A | 23.4375 A | 9.146341463414634 A | 7.5 mm | tin | 8.6 g | 108 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 16 mm | 40 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L2061620 | SDL | Mass Production | polarized | 2.7 V | 20 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 28 mΩ | 1 kHz | 0 mArms | 40 µA | 2.7 V | 12.857142857142858 A | 14.67391304347826 A | 4.623287671232877 A | 7.5 mm | tin | 5.6 g | 176 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1; leakage current shall refer to the 3.3F of adjacent capacitance in the same series as specified in Appendix 3 | 16 mm | 20 mm | — | Apply | ||
| Li-ion Capacitor |  | Hybrid Supercapacitor (Lithium-ion Capacitor) | SLR3R8O5071640 | SLR | Mass Production | polarized | 3.8 V | 500 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 40 mΩ | 1 kHz | 0 mArms | 10 µA | 4.2 V | 2 A | 20 A | 2 A | 7.5 mm | tin | 14.5 g | 240 | High Energy Density, Ultra Low Self-discharge, High Current Withstand, High Safety, Ultra Wide Temperature Range, Communication Tower, Short-time Backup Power | — | 16 mm | 40 mm | — | Apply | ||
| Li-ion Capacitor |  | Hybrid Supercapacitor (Lithium-ion Capacitor) | SLA3R8O1181850 | SLA | Mass Production | polarized | 3.8 V | 1100 F | -10%~+30% | -20 ~ 85 ℃ | 1000 h | 20 mΩ | 1 kHz | 0 mArms | 15 µA | 4.2 V | 3 A | 30 A | 3 A | 7.5 mm | tin | 24.4 g | 240 | Leaded, Polarized, High Energy Density, Ultra Low Self-discharge, Long Cycle Life, Wide Temperature Range, Long Service Life, Smart Instrument, IoT Device, Industrial Controller | — | 18 mm | 50 mm | — | Apply | ||
| Li-ion Capacitor | | Hybrid Supercapacitor (Lithium-ion Capacitor) | SLA3R8O7571840 | SLA | Mass Production | polarized | 3.8 V | 750 F | -10%~+30% | -20 ~ 85 ℃ | 1000 h | 25 mΩ | 1 kHz | 0 mArms | 12 µA | 4.2 V | 3 A | 30 A | 3 A | 7.5 mm | tin | 20.1 g | 240 | Leaded, Polarized, High Energy Density, Ultra Low Self-discharge, Long Cycle Life, Wide Temperature Range, Long Service Life, Smart Instrument, IoT Device, Industrial Controller | — | 18 mm | 40 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L6061840 | SDB | Mass Production | polarized | 3 V | 60 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 22 mΩ | 1 kHz | 0 mArms | 120 µA | 3 V | 18.18181818181818 A | 30.201342281879196 A | 12.893982808022923 A | 7.5 mm | tin | 12.5 g | 140 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 18 mm | 40 mm | — | Apply | ||
| Li-ion Capacitor |  | Hybrid Supercapacitor (Lithium-ion Capacitor) | CDSLR3R8O7571840 | CDSLR | Mass Production | polarized | 3.8 V | 750 F | -10%~+30% | -20 ~ 85 ℃ | 1000 h | 25 mΩ | 1 kHz | 0 mArms | 12 µA | 4.2 V | 3 A | 30 A | 3 A | 7.5 mm | tin | 20.1 g | 240 | High Energy Density, Ultra Low Self-discharge, High Current Withstand, High Safety, Ultra Wide Temperature Range, Communication Tower, Short-time Backup Power | — | 18 mm | 40 mm | — | Apply | ||
| Snap-in |  | Electric Double-Layer Supercapacitor | CDSDN3R0S6073572 | CDSDN | Mass Production | polarized | 3 V | 600 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 2.5 mΩ | 1 kHz | 0 mArms | 550 µA | 3 V | 159.99999999999997 A | 276.9230769230769 A | 124.13793103448276 A | 10 mm | tin | 112.5 g | 20 | RoHS Compliant, Ultra High Capacity, High Energy Density, High Power Output, High Current Discharge, Low ESR, Long Cycle Life, Wide Temperature Range, Fast Charge & Discharge | — | 35 mm | 72 mm | — | Apply | ||
| Snap-in | | Electric Double-Layer Supercapacitor | CDSDN3R0S5073565 | CDSDN | Mass Production | polarized | 3 V | 500 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 3 mΩ | 1 kHz | 0 mArms | 500 µA | 3 V | 133.33333333333334 A | 230.76923076923077 A | 103.44827586206897 A | 10 mm | tin | 78.2 g | 20 | RoHS Compliant, Ultra High Capacity, High Energy Density, High Power Output, High Current Discharge, Low ESR, Long Cycle Life, Wide Temperature Range, Fast Charge & Discharge | — | 35 mm | 65 mm | — | Apply | ||
| Snap-in | | Electric Double-Layer Supercapacitor | SDN3R0S5073565 | SDN | Mass Production | polarized | 3 V | 500 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 3 mΩ | 1 kHz | 0 mArms | 500 µA | 3 V | 133.33333333333334 A | 230.76923076923077 A | 103.44827586206897 A | 10 mm | tin | 78.2 g | 20 | RoHS Compliant, Ultra High Capacity, High Energy Density, High Power Output, High Current Discharge, Low ESR, Long Cycle Life, Wide Temperature Range, Fast Charge & Discharge | — | 35 mm | 65 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDA2R7L1071860 | SDA | Mass Production | polarized | 2.7 V | 100 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 16 mΩ | 1 kHz | 0 mArms | 160 µA | 2.7 V | 22.500000000000004 A | 39.705882352941174 A | 18.243243243243242 A | 7.5 mm | tin | 19.2 g | 66 | SDA, EDLC (Electric Double Layer Capacitor), Polarized, High-capacity Standard Grade, Leaded, RoHS Compliant, Low ESR, Low Self-discharge | — | 18 mm | 60 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L3061625 | SDH | Mass Production | Polarized | 2.7 V | 30 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 24 mΩ | 1 kHz | 0 mArms | 70 µA | 2.7 V | 15.000000000000002 A | 19.471153846153847 A | 6.661184210526316 A | 7.5 mm | tin | 7.5 g | 176 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1; leakage current shall refer to the 1F of adjacent capacitance in the same series as specified in Appendix 3 | 16 mm | 25 mm | ✓ | Apply | ||
| Li-ion Capacitor | | Hybrid Supercapacitor (Lithium-ion Capacitor) | SLA3R8O5071640 | SLA | Mass Production | polarized | 3.8 V | 500 F | -10%~+30% | -20 ~ 85 ℃ | 1000 h | 40 mΩ | 1 kHz | 0 mArms | 10 µA | 4.2 V | 2 A | 20 A | 2 A | 7.5 mm | tin | 14.5 g | 240 | Leaded, Polarized, High Energy Density, Ultra Low Self-discharge, Long Cycle Life, Wide Temperature Range, Long Service Life, Smart Instrument, IoT Device, Industrial Controller | — | 16 mm | 40 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH3R0L5061840 | SDH | Mass Production | Polarized | 3 V | 50 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 18 mΩ | 1 kHz | 0 mArms | 110 µA | 3 V | 22.22222222222222 A | 31.914893617021274 A | 11.811023622047244 A | 7.5 mm | tin | 10.9 g | 140 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1; leakage current shall refer to the 1F of adjacent capacitance in the same series as specified in Appendix 3 | 18 mm | 40 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH3R0L4061840 | SDH | Mass Production | Polarized | 3 V | 40 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 20 mΩ | 1 kHz | 0 mArms | 90 µA | 3 V | 19.999999999999996 A | 27.27272727272727 A | 9.67741935483871 A | 7.5 mm | tin | 8.7 g | 140 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1; leakage current shall refer to the 1F of adjacent capacitance in the same series as specified in Appendix 3 | 18 mm | 40 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L3061630 | SDH | Mass Production | Polarized | 2.7 V | 30 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 24 mΩ | 1 kHz | 0 mArms | 70 µA | 2.7 V | 15.000000000000002 A | 19.471153846153847 A | 6.661184210526316 A | 7.5 mm | tin | 7.1 g | 176 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1; leakage current shall refer to the 1F of adjacent capacitance in the same series as specified in Appendix 3 | 16 mm | 30 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L3061625 | SDB | Mass Production | polarized | 3 V | 30 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 30 mΩ | 1 kHz | 0 mArms | 60 µA | 3 V | 13.333333333333334 A | 19.148936170212767 A | 7.086614173228347 A | 7.5 mm | tin | 6.9 g | 176 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 16 mm | 25 mm | — | Apply | ||
| Snap-in | | Electric Double-Layer Supercapacitor | SDN3R0S2072550 | SDN | Mass Production | polarized | 3 V | 200 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 6 mΩ | 1 kHz | 0 mArms | 240 µA | 3 V | 66.66666666666667 A | 107.14285714285715 A | 44.11764705882353 A | 10 mm | tin | 37.5 g | 20 | RoHS Compliant, Ultra High Capacity, High Energy Density, High Power Output, High Current Discharge, Low ESR, Long Cycle Life, Wide Temperature Range, Fast Charge & Discharge | — | 25 mm | 50 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L4061625 | SDB | Mass Production | polarized | 3 V | 40 F | 0%~+30% | -40 ~ 70 ℃ | 1000 h | 26 mΩ | 1 kHz | 0 mArms | 80 µA | 3 V | 15.384615384615383 A | 23.4375 A | 9.146341463414634 A | 7.5 mm | tin | 6.8 g | 176 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR shall refer to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 16 mm | 25 mm | — | Apply | ||
| Snap-in | | Electric Double-Layer Supercapacitor | SDN3R0S3673560 | SDN | Mass Production | polarized | 3 V | 360 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 4 mΩ | 1 kHz | 0 mArms | 340 µA | 3 V | 100 A | 170.88607594936707 A | 75.41899441340782 A | 10 mm | tin | 56.3 g | 20 | RoHS Compliant, Ultra High Capacity, High Energy Density, High Power Output, High Current Discharge, Low ESR, Long Cycle Life, Wide Temperature Range, Fast Charge & Discharge | — | 35 mm | 60 mm | — | Apply |
