Found 670 results

Package Form	Product Line			Lifecycle Status	Polarity			Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	72h Leakage Current (μA)	Max Charge Voltage (V)	Max Charge Current (A)	Peak Current (A)	Continuous Current (A)	Terminal Pitch (mm)	Terminal Material	Min. Package Qty	Feature Tags	Remark		Dimension L (mm)	AEC-Q200	3D-CAD
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M1551622	SDM	Mass Production	polarized	5.5 V	1.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	200 mΩ	1 kHz	—	6 µA	5.5 V	0.756880733944954 A	2.8448275862069 A	0.756880733944954 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDBG3R0L1561325	SDB(G)	Mass Production	polarized	3 V	15 F	-10%~+30%	-40 ~ 85 ℃	1000 h	50 mΩ	1 kHz	—	30 µA	3 V	3.6734693877551 A	10.5882352941176 A	3.6734693877551 A	5 mm	tin	100	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	12.5 mm	25 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM6R0M3551627	SDM	Mass Production	polarized	6 V	3.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	12 µA	6 V	1.8308631211857 A	6.05187319884726 A	1.8308631211857 A	11.5 mm	tin	50	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDA2R7L5051020	SDA	Mass Production	polarized	2.7 V	5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	80 mΩ	1 kHz	—	10 µA	2.7 V	1.20535714285714 A	4.21875 A	1.20535714285714 A	5 mm	tin	250	SDA, EDLC (Electric Double Layer Capacitor), Polarized, High-capacity Standard Grade, Leaded, RoHS Compliant, Low ESR, Low Self-discharge	—	10 mm	20 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM6R0M7552527	SDM	Mass Production	polarized	6 V	7.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	60 mΩ	1 kHz	—	30 µA	6 V	3.9647577092511 A	13.4328358208955 A	3.9647577092511 A	17.5 mm	tin	50	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	12.5 mm	25 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SMG5R5M2241517	SM(G)	Mass Production	polarized	5.5 V	0.22 F	0%~+50%	-40 ~ 85 ℃	1000 h	800 mΩ	1 kHz	—	2 µA	5.5 V	0.114931610942249 A	0.478639240506329 A	0.114931610942249 A	9 mm	tin	100	Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考	8.5 mm	15 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDS2R7L1561320	SDS	Mass Production	polarized	2.7 V	15 F	-10%~+30%	-40 ~ 70 ℃	1000 h	70 mΩ	1 kHz	—	50 µA	2.7 V	3.07984790874525 A	7.86407766990291 A	3.07984790874525 A	5 mm	tin	100	High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	12.5 mm	20 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDS2R7L5040512	SDS	Mass Production	polarized	2.7 V	0.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	1200 mΩ	1 kHz	—	2 µA	2.7 V	0.114406779661017 A	0.355263157894737 A	0.114406779661017 A	2 mm	tin	1000	High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	5 mm	12 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM6R0M1051618	SDM	Mass Production	polarized	6 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	240 mΩ	1 kHz	—	4 µA	6 V	0.559701492537313 A	2.20588235294118 A	0.559701492537313 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM6R0M5041614	SDM	Mass Production	polarized	6 V	0.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	600 mΩ	1 kHz	—	2 µA	6 V	0.275229357798165 A	1.03448275862069 A	0.275229357798165 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量0.47F参考	8 mm	16 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M5052522	SDM	Mass Production	polarized	5.5 V	5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	100 mΩ	1 kHz	—	20 µA	5.5 V	2.39130434782609 A	7.85714285714286 A	2.39130434782609 A	17.5 mm	tin	50	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	12.5 mm	25 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M3052022	SDM	Mass Production	polarized	5.5 V	3 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	10 µA	5.5 V	1.46536412078153 A	5.06134969325153 A	1.46536412078153 A	15.5 mm	tin	125	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量2.5F参考	10 mm	20 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M2551627	SDM	Mass Production	polarized	5.5 V	2.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	10 µA	5.5 V	1.24434389140271 A	4.50819672131148 A	1.24434389140271 A	11.5 mm	tin	200	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M1051318	SDM	Mass Production	polarized	5.5 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	240 mΩ	1 kHz	—	4 µA	5.5 V	0.513059701492537 A	2.02205882352941 A	0.513059701492537 A	9 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	6.5 mm	13 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M1051313	SDM	Mass Production	polarized	5.5 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	240 mΩ	1 kHz	—	4 µA	5.5 V	0.513059701492537 A	2.02205882352941 A	0.513059701492537 A	9 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	6.3 mm	13 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M2241312	SDM	Mass Production	polarized	5.5 V	0.22 F	-10%~+30%	-40 ~ 70 ℃	1000 h	800 mΩ	1 kHz	—	2 µA	5.5 V	0.114931610942249 A	0.478639240506329 A	0.114931610942249 A	9 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	6.3 mm	13 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M2241010	SDM	Mass Production	polarized	5.5 V	0.22 F	-10%~+30%	-40 ~ 70 ℃	1000 h	800 mΩ	1 kHz	—	2 µA	5.5 V	0.114931610942249 A	0.478639240506329 A	0.114931610942249 A	7 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	5 mm	10 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDH2R7L5040609	SDH	Mass Production	Polarized	2.7 V	0.5 F	-10%~+30%	-40 ~ 85 ℃	1000 h	160 mΩ	1 kHz	—	4 µA	2.7 V	0.1318359375 A	0.602678571428571 A	0.1318359375 A	2.5 mm	tin	1000	RoHS, high capacitance, low ESR, fast charge & discharge, long service life	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考	6.3 mm	9 mm	✓	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M5031012	SDM	Mass Production	polarized	5.5 V	0.05 F	-10%~+30%	-40 ~ 70 ℃	1000 h	1200 mΩ	1 kHz	—	2 µA	5.5 V	0.0270137524557957 A	0.126146788990826 A	0.0270137524557957 A	7 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量0.1F参考	5 mm	10 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M2241012	SDM	Mass Production	polarized	5.5 V	0.22 F	-10%~+30%	-40 ~ 70 ℃	1000 h	800 mΩ	1 kHz	—	2 µA	5.5 V	0.114931610942249 A	0.478639240506329 A	0.114931610942249 A	7 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	5 mm	10 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDMG5R5M3552022	SDM(G)	Mass Production	polarized	5.5 V	3.5 F	0%~+30%	-40 ~ 85 ℃	1000 h	140 mΩ	1 kHz	—	12 µA	5.5 V	1.67829119442023 A	5.54755043227666 A	1.67829119442023 A	15.5 mm	tin	125	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	20 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDMR6R0M5041614	SDM(R)	Mass Production	polarized	6 V	0.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	600 mΩ	1 kHz	—	2 µA	6 V	0.275229357798165 A	1.03448275862069 A	0.275229357798165 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量0.47F参考	8 mm	16 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDMG5R5M1551622	SDM(G)	Mass Production	polarized	5.5 V	1.5 F	-10%~+30%	-40 ~ 85 ℃	1000 h	200 mΩ	1 kHz	—	6 µA	5.5 V	0.756880733944954 A	2.8448275862069 A	0.756880733944954 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M4741312	SDM	Mass Production	polarized	5.5 V	0.47 F	-10%~+30%	-40 ~ 70 ℃	1000 h	600 mΩ	1 kHz	—	2 µA	5.5 V	0.238336713995943 A	0.908292340126493 A	0.238336713995943 A	9 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	6.3 mm	13 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M3551625	SDM	Mass Production	polarized	5.5 V	3.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	12 µA	5.5 V	1.67829119442023 A	5.54755043227666 A	1.67829119442023 A	11.5 mm	tin	50	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDH2R7L6051020	SDH	Mass Production	Polarized	2.7 V	6 F	-10%~+30%	-40 ~ 85 ℃	1000 h	50 mΩ	1 kHz	—	15 µA	2.7 V	1.48623853211009 A	5.58620689655173 A	1.48623853211009 A	5 mm	tin	250	RoHS, high capacitance, low ESR, fast charge & discharge, long service life	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量5F参考	10 mm	20 mm	✓	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDH2R7L1061030	SDH	Mass Production	Polarized	2.7 V	10 F	-10%~+30%	-40 ~ 85 ℃	1000 h	40 mΩ	1 kHz	—	30 µA	2.7 V	2.41071428571429 A	8.4375 A	2.41071428571429 A	5 mm	tin	150	RoHS, high capacitance, low ESR, fast charge & discharge, long service life	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	30 mm	✓	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M2051324	SDM	Mass Production	polarized	5.5 V	2 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	6 µA	5.5 V	1.01476014760148 A	3.87323943661972 A	1.01476014760148 A	9 mm	tin	50	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1.5F参考	6.3 mm	13 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDB3R0L1061030	SDB	Mass Production	polarized	3 V	10 F	-10%~+30%	-40 ~ 70 ℃	1000 h	70 mΩ	1 kHz	—	20 µA	3 V	2.47933884297521 A	7.31707317073171 A	2.47933884297521 A	5 mm	tin	150	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	30 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDB3R0L1050809	SDB	Mass Production	polarized	3 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	240 mΩ	1 kHz	—	3 µA	3 V	0.279850746268657 A	1.10294117647059 A	0.279850746268657 A	3.5 mm	tin	500	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	9 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDB3R0L1050512	SDB	Mass Production	polarized	3 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	240 mΩ	1 kHz	—	3 µA	3 V	0.279850746268657 A	1.10294117647059 A	0.279850746268657 A	2 mm	tin	1000	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	5 mm	12 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M4052624	SDM	Mass Production	polarized	5.5 V	4 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	12 µA	5.5 V	1.88356164383562 A	5.97826086956522 A	1.88356164383562 A	9 mm	tin	50	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量3.5F参考	6.5 mm	26 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDA2R7L3350820	SDA	Mass Production	polarized	2.7 V	3.3 F	-10%~+30%	-40 ~ 70 ℃	1000 h	120 mΩ	1 kHz	—	6 µA	2.7 V	0.796388988201645 A	2.79485570890841 A	0.796388988201645 A	3.5 mm	tin	500	SDA, EDLC (Electric Double Layer Capacitor), Polarized, High-capacity Standard Grade, Leaded, RoHS Compliant, Low ESR, Low Self-discharge	—	8 mm	20 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDA2R7L3351013	SDA	Mass Production	polarized	2.7 V	3.3 F	-10%~+30%	-40 ~ 70 ℃	1000 h	100 mΩ	1 kHz	—	6 µA	2.7 V	0.81073703366697 A	2.97993311036789 A	0.81073703366697 A	5 mm	tin	500	SDA, EDLC (Electric Double Layer Capacitor), Polarized, High-capacity Standard Grade, Leaded, RoHS Compliant, Low ESR, Low Self-discharge	—	10 mm	13 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M6053924	SDM	Mass Production	polarized	5.5 V	6 F	-10%~+30%	-40 ~ 70 ℃	1000 h	100 mΩ	1 kHz	—	20 µA	5.5 V	2.79661016949152 A	8.68421052631579 A	2.79661016949152 A	9 mm	tin	100	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量5F参考	6.5 mm	39 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SMG5R5M5052229	SM(G)	Mass Production	polarized	5.5 V	5 F	0%~+30%	-40 ~ 85 ℃	1000 h	100 mΩ	1 kHz	—	20 µA	5.5 V	2.39130434782609 A	7.85714285714286 A	2.39130434782609 A	15.5 mm	tin	50	Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考	11.5 mm	22 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDL2R7L1050813	SDL	Mass Production	polarized	2.7 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	160 mΩ	1 kHz	—	2 µA	2.7 V	0.25763358778626 A	1.08870967741935 A	0.25763358778626 A	3.5 mm	tin	500	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	13 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDB3R0L1550812	SDB	Mass Production	polarized	3 V	1.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	160 mΩ	1 kHz	—	3 µA	3 V	0.419776119402985 A	1.65441176470588 A	0.419776119402985 A	3.5 mm	tin	1000	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考	8 mm	11.5 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDLH2R7L2050813	SDL(H)	Mass Production	polarized	2.7 V	2 F	-10%~+30%	-40 ~ 105 ℃	1000 h	120 mΩ	1 kHz	—	4 µA	2.7 V	0.503731343283582 A	1.98529411764706 A	0.503731343283582 A	3.5 mm	tin	500	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	13 mm	✓	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDB3R0L1050813	SDB	Mass Production	polarized	3 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	240 mΩ	1 kHz	—	3 µA	3 V	0.279850746268657 A	1.10294117647059 A	0.279850746268657 A	3.5 mm	tin	1000	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	13 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM6R0M1551618	SDM	Mass Production	polarized	6 V	1.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	200 mΩ	1 kHz	—	6 µA	6 V	0.825688073394495 A	3.10344827586207 A	0.825688073394495 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDLG2R7L1561325	SDL（G）	Mass Production	polarized	2.7 V	15 F	0%~+30%	-40 ~ 85 ℃	1000 h	30 mΩ	1 kHz	—	30 µA	2.7 V	3.56828193832599 A	12.089552238806 A	3.56828193832599 A	5 mm	tin	100	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	12.5 mm	25 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDA2R7L2050813	SDA	Mass Production	polarized	2.7 V	2 F	-10%~+30%	-40 ~ 70 ℃	1000 h	180 mΩ	1 kHz	—	4 µA	2.7 V	0.487364620938628 A	1.75324675324675 A	0.487364620938628 A	3.5 mm	tin	500	SDA, EDLC (Electric Double Layer Capacitor), Polarized, High-capacity Standard Grade, Leaded, RoHS Compliant, Low ESR, Low Self-discharge	—	8 mm	13 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M2552022	SDM	Mass Production	polarized	5.5 V	2.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	10 µA	5.5 V	1.24434389140271 A	4.50819672131148 A	1.24434389140271 A	15.5 mm	tin	125	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	20 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SMG5R5M4741816	SM(G)	Mass Production	polarized	5.5 V	0.47 F	-10%~+30%	-40 ~ 85 ℃	1000 h	400 mΩ	1 kHz	—	2 µA	5.5 V	0.244698977659977 A	1.0081903276131 A	0.244698977659977 A	11.5 mm	tin	750	Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考	9.5 mm	17.5 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SMG5R5M2241414	SM(G)	Mass Production	polarized	5.5 V	0.22 F	0%~+80%	-40 ~ 85 ℃	1000 h	800 mΩ	1 kHz	—	2 µA	5.5 V	0.114931610942249 A	0.478639240506329 A	0.114931610942249 A	9 mm	tin	100	Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考	8 mm	14 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M4052522	SDM	Mass Production	polarized	5.5 V	4 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	12 µA	5.5 V	1.88356164383562 A	5.97826086956522 A	1.88356164383562 A	17.5 mm	tin	120	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量3.5F参考	12.5 mm	25 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M3341312	SDM	Mass Production	polarized	5.5 V	0.33 F	-10%~+30%	-40 ~ 70 ℃	1000 h	800 mΩ	1 kHz	—	2 µA	5.5 V	0.168180133432172 A	0.650071633237822 A	0.168180133432172 A	9 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	6.3 mm	13 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M3341012	SDM	Mass Production	polarized	5.5 V	0.33 F	-10%~+30%	-40 ~ 70 ℃	1000 h	800 mΩ	1 kHz	—	2 µA	5.5 V	0.168180133432172 A	0.650071633237822 A	0.168180133432172 A	7 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	5 mm	10 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDMH5R5M1051618	SDM(H)	Mass Production	polarized	5.5 V	1 F	-10%~+30%	-40 ~ 105 ℃	1000 h	240 mΩ	1 kHz	—	4 µA	5.5 V	0.513059701492537 A	2.02205882352941 A	0.513059701492537 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
