Found 670 results
| Compare | Package Form | Product Image | Product Line | Lifecycle Status | Polarity | Tolerance | Operating Temp. (℃) | Rated Life (Hours) | ESR (max.) | ESR Frequency | Rated Ripple Current | 72h Leakage Current (μA) | Max Charge Voltage (V) | Max Charge Current (A) | Peak Current (A) | Continuous Current (A) | Terminal Pitch (mm) | Terminal Material | Weight | Min. Package Qty | Feature Tags | Remark | Dimension L (mm) | AEC-Q200 | 3D-CAD | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDH2R7L1550812 | SDH | Mass Production | Polarized | 2.7 V | 1.5 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 120 mΩ | 1 kHz | — | 4 µA | 2.7 V | 0.384250474383302 A | 1.59448818897638 A | 0.384250474383302 A | 3.5 mm | tin | 0 g | 500 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考 | 8 mm | 11.5 mm | ✓ | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDB3R0L2050816 | SDB | Mass Production | polarized | 3 V | 2 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 160 mΩ | 1 kHz | — | 4 µA | 3 V | 0.547445255474453 A | 2.02702702702703 A | 0.547445255474453 A | 3.5 mm | tin | 0 g | 500 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDBG3R0L1861325 | SDB(G) | Mass Production | polarized | 3 V | 18 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 40 mΩ | 1 kHz | — | 40 µA | 3 V | 4.44078947368421 A | 12.9807692307692 A | 4.44078947368421 A | 5 mm | tin | 0 g | 100 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量20F参考 | 12.5 mm | 25 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDBG3R0L5051020 | SDB(G) | Mass Production | polarized | 3 V | 5 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 80 mΩ | 1 kHz | — | 10 µA | 3 V | 1.33928571428571 A | 4.6875 A | 1.33928571428571 A | 5 mm | tin | 0 g | 250 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 20 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L7040609 | SDS | Mass Production | polarized | 2.7 V | 0.7 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 600 mΩ | 1 kHz | — | 2 µA | 2.7 V | 0.16785079928952 A | 0.579754601226994 A | 0.16785079928952 A | 2.5 mm | tin | 0 g | 1000 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量0.5F参考 | 6.3 mm | 9 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L5040812 | SDH | Mass Production | Polarized | 2.7 V | 0.5 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 160 mΩ | 1 kHz | — | 4 µA | 2.7 V | 0.1318359375 A | 0.602678571428571 A | 0.1318359375 A | 3.5 mm | tin | 0 g | 500 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考 | 8 mm | 11.5 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L5040812 | SDB | Mass Production | polarized | 3 V | 0.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 240 mΩ | 1 kHz | — | 3 µA | 3 V | 0.144787644787645 A | 0.635593220338983 A | 0.144787644787645 A | 3.5 mm | tin | 0 g | 500 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考 | 8 mm | 11.5 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDLH2R7L4051016 | SDL(H) | Mass Production | polarized | 2.7 V | 4 F | -10%~+30% | -40 ~ 105 ℃ | 1000 h | 70 mΩ | 1 kHz | — | 6 µA | 2.7 V | 0.996309963099631 A | 3.80281690140845 A | 0.996309963099631 A | 5 mm | tin | 0 g | 500 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量3.3F参考 | 10 mm | 16 mm | ✓ | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDBH3R0L1561325 | SDB(H) | Mass Production | polarized | 3 V | 15 F | -10%~+30% | -40 ~ 105 ℃ | 1000 h | 50 mΩ | 1 kHz | — | 30 µA | 3 V | 3.6734693877551 A | 10.5882352941176 A | 3.6734693877551 A | 5 mm | tin | 0 g | 100 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 25 mm | — | Apply | ||
| Module Type |  | Electric Double-Layer Supercapacitor | SDM6R0M2051622 | SDM | Mass Production | polarized | 6 V | 2 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 140 mΩ | 1 kHz | — | 6 µA | 6 V | 1.1070110701107 A | 4.22535211267606 A | 1.1070110701107 A | 11.5 mm | tin | 0 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1.5F参考 | 8 mm | 16 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM6R0M1051614 | SDM | Mass Production | polarized | 6 V | 1 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 240 mΩ | 1 kHz | — | 4 µA | 6 V | 0.559701492537313 A | 2.20588235294118 A | 0.559701492537313 A | 11.5 mm | tin | 0 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM6R0M2552022 | SDM | Mass Production | polarized | 6 V | 2.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 140 mΩ | 1 kHz | — | 10 µA | 6 V | 1.35746606334842 A | 4.91803278688525 A | 1.35746606334842 A | 15.5 mm | tin | 0 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 20 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L1561330 | SDH | Mass Production | Polarized | 2.7 V | 15 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 30 mΩ | 1 kHz | — | 40 µA | 2.7 V | 3.56828193832599 A | 12.089552238806 A | 3.56828193832599 A | 5 mm | tin | 0 g | 440 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 30 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L3050820 | SDH | Mass Production | Polarized | 2.7 V | 3 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 80 mΩ | 1 kHz | — | 8 µA | 2.7 V | 0.755597014925373 A | 2.97794117647059 A | 0.755597014925373 A | 3.5 mm | tin | 0 g | 1000 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量3.3F参考 | 8 mm | 20 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L4051016 | SDH | Mass Production | Polarized | 2.7 V | 4 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 70 mΩ | 1 kHz | — | 8 µA | 2.7 V | 0.996309963099631 A | 3.80281690140845 A | 0.996309963099631 A | 5 mm | tin | 0 g | 672 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量3.3F参考 | 10 mm | 16 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L1550813 | SDH | Mass Production | Polarized | 2.7 V | 1.5 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 120 mΩ | 1 kHz | — | 4 µA | 2.7 V | 0.384250474383302 A | 1.59448818897638 A | 0.384250474383302 A | 3.5 mm | tin | 0 g | 1000 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考 | 8 mm | 13 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L2050813 | SDH | Mass Production | Polarized | 2.7 V | 2 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 120 mΩ | 1 kHz | — | 5 µA | 2.7 V | 0.503731343283582 A | 1.98529411764706 A | 0.503731343283582 A | 3.5 mm | tin | 0 g | 1000 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 13 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDBH3R0L2261340 | SDB(H) | Mass Production | polarized | 3 V | 22 F | -10%~+30% | -40 ~ 105 ℃ | 1000 h | 40 mΩ | 1 kHz | — | 40 µA | 3 V | 5.22151898734177 A | 14.2241379310345 A | 5.22151898734177 A | 5 mm | tin | 0 g | 280 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量20F参考 | 12.5 mm | 40 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L1550615 | SDS | Mass Production | polarized | 2.7 V | 1.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 400 mΩ | 1 kHz | — | 5 µA | 2.7 V | 0.343220338983051 A | 1.06578947368421 A | 0.343220338983051 A | 2.5 mm | tin | 0 g | 1000 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 6.3 mm | 15 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM6R0M4741312 | SDM | Mass Production | polarized | 6 V | 0.47 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 600 mΩ | 1 kHz | — | 2 µA | 6 V | 0.260003687995574 A | 0.990864371047084 A | 0.260003687995574 A | 9 mm | tin | 0 g | 500 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 6.3 mm | 13 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM5R5M6552027 | SDM | Mass Production | polarized | 5.5 V | 6.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 60 mΩ | 1 kHz | — | 30 µA | 5.5 V | 3.20053715308863 A | 11.2776025236593 A | 3.20053715308863 A | 15.5 mm | tin | 0 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量7.5F参考 | 10 mm | 20 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L5050825 | SDS | Mass Production | polarized | 2.7 V | 5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 120 mΩ | 1 kHz | — | 18 µA | 2.7 V | 1.14406779661017 A | 3.55263157894737 A | 1.14406779661017 A | 3.5 mm | tin | 0 g | 400 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 25 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDLG2R7L1061230 | SDL（G） | Mass Production | polarized | 2.7 V | 10 F | 0%~+30% | -40 ~ 85 ℃ | 1000 h | 40 mΩ | 1 kHz | — | 20 µA | 2.7 V | 2.41071428571429 A | 8.4375 A | 2.41071428571429 A | 5 mm | tin | 0 g | 100 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；脚距按附件三相邻直径Φ12.5结构参考 | 12 mm | 30 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDLG2R7L1050812 | SDL（G） | Mass Production | polarized | 2.7 V | 1 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 160 mΩ | 1 kHz | — | 2 µA | 2.7 V | 0.25763358778626 A | 1.08870967741935 A | 0.25763358778626 A | 3.5 mm | tin | 0 g | 500 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 11.5 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L3350816 | SDS | Mass Production | polarized | 2.7 V | 3.3 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 160 mΩ | 1 kHz | — | 14 µA | 2.7 V | 0.769164364640884 A | 2.48604910714286 A | 0.769164364640884 A | 3.5 mm | tin | 0 g | 500 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L1061320 | SDL | Mass Production | polarized | 2.7 V | 10 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 35 mΩ | 1 kHz | — | 20 µA | 2.7 V | 2.44343891402715 A | 8.85245901639344 A | 2.44343891402715 A | 5 mm | tin | 0 g | 100 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 20 mm | — | Apply | ||
| Module Type |  | Electric Double-Layer Supercapacitor | SM5R5M2051824 | SM | Mass Production | polarized | 5.5 V | 2 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 140 mΩ | 1 kHz | — | 8 µA | 5.5 V | 1.01476014760148 A | 3.87323943661972 A | 1.01476014760148 A | 11.5 mm | tin | 0 g | 750 | Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考 | 9.5 mm | 18 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L1561325 | SDL | Mass Production | polarized | 2.7 V | 15 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 30 mΩ | 1 kHz | — | 30 µA | 2.7 V | 3.56828193832599 A | 12.089552238806 A | 3.56828193832599 A | 5 mm | tin | 0 g | 100 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 25 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM5R5M5051627 | SDM | Mass Production | polarized | 5.5 V | 5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 100 mΩ | 1 kHz | — | 20 µA | 5.5 V | 2.39130434782609 A | 7.85714285714286 A | 2.39130434782609 A | 11.5 mm | tin | 0 g | 200 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L5050820 | SDS | Mass Production | polarized | 2.7 V | 5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 120 mΩ | 1 kHz | — | 18 µA | 2.7 V | 1.14406779661017 A | 3.55263157894737 A | 1.14406779661017 A | 3.5 mm | tin | 0 g | 500 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 20 mm | — | Apply | ||
| Module Type |  | Electric Double-Layer Supercapacitor | SDMR6R0M1551622 | SDM(R) | Mass Production | polarized | 6 V | 1.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 200 mΩ | 1 kHz | — | 6 µA | 6 V | 0.825688073394495 A | 3.10344827586207 A | 0.825688073394495 A | 11.5 mm | tin | 0 g | 250 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply | ||
| Module Type |  | Electric Double-Layer Supercapacitor | SMG5R5M5041917 | SM(G) | Mass Production | polarized | 5.5 V | 0.5 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 400 mΩ | 1 kHz | — | 2 µA | 5.5 V | 0.259433962264151 A | 1.05769230769231 A | 0.259433962264151 A | 11.5 mm | tin | 0 g | 750 | Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考 | 10 mm | 18.5 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L2050816 | SDH | Mass Production | Polarized | 2.7 V | 2 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 120 mΩ | 1 kHz | — | 5 µA | 2.7 V | 0.503731343283582 A | 1.98529411764706 A | 0.503731343283582 A | 3.5 mm | tin | 0 g | 1000 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L7051020 | SDB | Mass Production | polarized | 3 V | 7 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 80 mΩ | 1 kHz | — | 14 µA | 3 V | 1.79794520547945 A | 5.70652173913044 A | 1.79794520547945 A | 5 mm | tin | 0 g | 250 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 20 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L1550812 | SDL | Mass Production | polarized | 2.7 V | 1.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 120 mΩ | 1 kHz | — | 2 µA | 2.7 V | 0.384250474383302 A | 1.59448818897638 A | 0.384250474383302 A | 3.5 mm | tin | 0 g | 1000 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考 | 8 mm | 12 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDBG3R0L2050813 | SDB(G) | Mass Production | polarized | 3 V | 2 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 160 mΩ | 1 kHz | — | 4 µA | 3 V | 0.547445255474453 A | 2.02702702702703 A | 0.547445255474453 A | 3.5 mm | tin | 0 g | 500 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 13 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L5050825 | SDL | Mass Production | polarized | 2.7 V | 5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 60 mΩ | 1 kHz | — | 10 µA | 2.7 V | 1.23853211009174 A | 4.6551724137931 A | 1.23853211009174 A | 3.5 mm | tin | 0 g | 400 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 25 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L1061025 | SDL | Mass Production | polarized | 2.7 V | 10 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 40 mΩ | 1 kHz | — | 20 µA | 2.7 V | 2.41071428571429 A | 8.4375 A | 2.41071428571429 A | 5 mm | tin | 0 g | 250 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 25 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDLG2R7L3350820 | SDL（G） | Mass Production | polarized | 2.7 V | 3.3 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 80 mΩ | 1 kHz | — | 6 µA | 2.7 V | 0.825611564121572 A | 3.19126074498567 A | 0.825611564121572 A | 3.5 mm | tin | 0 g | 1000 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 20 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L1060825 | SDS | Mass Production | polarized | 2.7 V | 10 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 80 mΩ | 1 kHz | — | 40 µA | 2.7 V | 2.17741935483871 A | 6.13636363636364 A | 2.17741935483871 A | 3.5 mm | tin | 0 g | 400 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 25 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDBG3R0L1261025 | SDB(G) | Mass Production | polarized | 3 V | 12 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 70 mΩ | 1 kHz | — | 20 µA | 3 V | 2.87539936102236 A | 7.96460176991151 A | 2.87539936102236 A | 5 mm | tin | 0 g | 250 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量10F参考 | 10 mm | 25 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDBG3R0L1050813 | SDB(G) | Mass Production | polarized | 3 V | 1 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 240 mΩ | 1 kHz | — | 3 µA | 3 V | 0.279850746268657 A | 1.10294117647059 A | 0.279850746268657 A | 3.5 mm | tin | 0 g | 500 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 13 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDBG3R0L7051020 | SDB(G) | Mass Production | polarized | 3 V | 7 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 80 mΩ | 1 kHz | — | 14 µA | 3 V | 1.79794520547945 A | 5.70652173913044 A | 1.79794520547945 A | 5 mm | tin | 0 g | 250 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 20 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDMR5R5M1551622 | SDM(R) | Mass Production | polarized | 5.5 V | 1.5 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 200 mΩ | 1 kHz | — | 6 µA | 5.5 V | 0.756880733944954 A | 2.8448275862069 A | 0.756880733944954 A | 11.5 mm | tin | 0 g | 250 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM5R5M4741614 | SDM | Mass Production | polarized | 5.5 V | 0.47 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 600 mΩ | 1 kHz | — | 2 µA | 5.5 V | 0.238336713995943 A | 0.908292340126493 A | 0.238336713995943 A | 11.5 mm | tin | 0 g | 250 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L3050816 | SDH | Mass Production | Polarized | 2.7 V | 3 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 80 mΩ | 1 kHz | — | 8 µA | 2.7 V | 0.755597014925373 A | 2.97794117647059 A | 0.755597014925373 A | 3.5 mm | tin | 0 g | 500 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量3.3F参考 | 8 mm | 16 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L1061320 | SDH | Mass Production | Polarized | 2.7 V | 10 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 35 mΩ | 1 kHz | — | 30 µA | 2.7 V | 2.44343891402715 A | 8.85245901639344 A | 2.44343891402715 A | 5 mm | tin | 0 g | 100 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 20 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDLH2R7L1561325 | SDL(H) | Mass Production | polarized | 2.7 V | 15 F | -10%~+30% | -40 ~ 105 ℃ | 1000 h | 30 mΩ | 1 kHz | — | 30 µA | 2.7 V | 3.56828193832599 A | 12.089552238806 A | 3.56828193832599 A | 5 mm | tin | 0 g | 100 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 25 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDLG2R7L2050816 | SDL（G） | Mass Production | polarized | 2.7 V | 2 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 120 mΩ | 1 kHz | — | 4 µA | 2.7 V | 0.503731343283582 A | 1.98529411764706 A | 0.503731343283582 A | 3.5 mm | tin | 0 g | 500 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L3350816 | SDL | Mass Production | polarized | 2.7 V | 3.3 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 80 mΩ | 1 kHz | — | 6 µA | 2.7 V | 0.825611564121572 A | 3.19126074498567 A | 0.825611564121572 A | 3.5 mm | tin | 0 g | 500 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply |
