Found 670 results

Package Form	Product Line			Lifecycle Status	Polarity			Tolerance	Operating Temp. (℃)	Rated Life (Hours)	ESR (max.)	ESR Frequency	Rated Ripple Current	72h Leakage Current (μA)	Max Charge Voltage (V)	Max Charge Current (A)	Peak Current (A)	Continuous Current (A)	Terminal Pitch (mm)	Terminal Material	Min. Package Qty	Feature Tags	Remark		Dimension L (mm)	AEC-Q200	3D-CAD
Radial Lead	Electric Double-Layer Supercapacitor	SDLH2R7L1061320	SDL(H)	Mass Production	polarized	2.7 V	10 F	-10%~+30%	-40 ~ 105 ℃	1000 h	35 mΩ	1 kHz	—	20 µA	2.7 V	2.44343891402715 A	8.85245901639344 A	2.44343891402715 A	5 mm	tin	200	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	12.5 mm	20 mm	✓	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDS2R7L4050622	SDS	Mass Production	polarized	2.7 V	4 F	-10%~+30%	-40 ~ 70 ℃	1000 h	120 mΩ	1 kHz	—	14 µA	2.7 V	0.944055944055944 A	3.13953488372093 A	0.944055944055944 A	2.5 mm	tin	750	High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量3.3F参考	6.3 mm	22 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M6052027	SDM	Mass Production	polarized	5.5 V	6 F	-10%~+30%	-40 ~ 70 ℃	1000 h	100 mΩ	1 kHz	—	20 µA	5.5 V	2.79661016949152 A	8.68421052631579 A	2.79661016949152 A	15.5 mm	tin	100	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量5F参考	10 mm	20 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDL2R7L1261025	SDL	Mass Production	polarized	2.7 V	12 F	-10%~+30%	-40 ~ 70 ℃	1000 h	40 mΩ	1 kHz	—	20 µA	2.7 V	2.83216783216783 A	9.41860465116279 A	2.83216783216783 A	5 mm	tin	250	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量10F参考	10 mm	25 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M2551622	SDM	Mass Production	polarized	5.5 V	2.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	10 µA	5.5 V	1.24434389140271 A	4.50819672131148 A	1.24434389140271 A	11.5 mm	tin	50	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDBR3R0L1050812	SDB(R)	Mass Production	polarized	3 V	1 F	-10%~+30%	-40 ~ 85 ℃	1000 h	240 mΩ	1 kHz	—	3 µA	3 V	0.279850746268657 A	1.10294117647059 A	0.279850746268657 A	3.5 mm	tin	500	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	11.5 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M5041614	SDM	Mass Production	polarized	5.5 V	0.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	600 mΩ	1 kHz	—	2 µA	5.5 V	0.252293577981651 A	0.948275862068966 A	0.252293577981651 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量0.47F参考	8 mm	16 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M7552027	SDM	Mass Production	polarized	5.5 V	7.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	60 mΩ	1 kHz	—	30 µA	5.5 V	3.63436123348018 A	12.3134328358209 A	3.63436123348018 A	15.5 mm	tin	100	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	20 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M2051622	SDM	Mass Production	polarized	5.5 V	2 F	0%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	6 µA	5.5 V	1.01476014760148 A	3.87323943661972 A	1.01476014760148 A	11.5 mm	tin	50	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1.5F参考	8 mm	16 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDS2R7L1040509	SDS	Mass Production	polarized	2.7 V	0.1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	1200 mΩ	1 kHz	—	2 µA	2.7 V	0.0260617760617761 A	0.114406779661017 A	0.0260617760617761 A	2 mm	tin	1000	High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量0.5F参考	5 mm	9 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDS2R7L5050622	SDS	Mass Production	polarized	2.7 V	5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	120 mΩ	1 kHz	—	18 µA	2.7 V	1.14406779661017 A	3.55263157894737 A	1.14406779661017 A	2.5 mm	tin	750	High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	6.3 mm	22 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM6R0M5052027	SDM	Mass Production	polarized	6 V	5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	100 mΩ	1 kHz	—	20 µA	6 V	2.60869565217391 A	8.57142857142857 A	2.60869565217391 A	15.5 mm	tin	100	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	20 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDL2R7L1261325	SDL	Mass Production	polarized	2.7 V	12 F	-10%~+30%	-40 ~ 70 ℃	1000 h	30 mΩ	1 kHz	0 mArms	20 µA	2.7 V	2.92418772563177 A	10.5194805194805 A	2.92418772563177 A	5 mm	tin	100	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量10F参考	12.5 mm	25 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDA2R7L1050812	SDA	Mass Production	polarized	2.7 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	200 mΩ	1 kHz	—	3 µA	2.7 V	0.254716981132075 A	1.03846153846154 A	0.254716981132075 A	3.5 mm	tin	1000	SDA, EDLC (Electric Double Layer Capacitor), Polarized, High-capacity Standard Grade, Leaded, RoHS Compliant, Low ESR, Low Self-discharge	—	8 mm	11.5 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDB3R0L1050812	SDB	Mass Production	polarized	3 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	240 mΩ	1 kHz	—	3 µA	3 V	0.279850746268657 A	1.10294117647059 A	0.279850746268657 A	3.5 mm	tin	500	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	11.5 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDLG2R7L1261025	SDL（G）	Mass Production	polarized	2.7 V	12 F	-10%~+30%	-40 ~ 85 ℃	1000 h	40 mΩ	1 kHz	—	20 µA	2.7 V	2.83216783216783 A	9.41860465116279 A	2.83216783216783 A	5 mm	tin	250	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量10F参考	10 mm	25 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDLG2R7L1261230	SDL（G）	Mass Production	polarized	2.7 V	12 F	-10%~+30%	-40 ~ 85 ℃	1000 h	30 mΩ	1 kHz	—	20 µA	2.7 V	2.92418772563177 A	10.5194805194805 A	2.92418772563177 A	5 mm	tin	100	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量10F参考；脚距按附件三相邻直径Φ12.5结构参考	12 mm	30 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDMG5R5M2552022	SDM(G)	Mass Production	polarized	5.5 V	2.5 F	-10%~+30%	-40 ~ 85 ℃	1000 h	140 mΩ	1 kHz	—	10 µA	5.5 V	1.24434389140271 A	4.50819672131148 A	1.24434389140271 A	15.5 mm	tin	125	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	20 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SM5R5M2552224	SM	Mass Production	polarized	5.5 V	2.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	10 µA	5.5 V	1.24434389140271 A	4.50819672131148 A	1.24434389140271 A	15.5 mm	tin	50	Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考	11.5 mm	21.5 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M3552022	SDM	Mass Production	polarized	5.5 V	3.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	12 µA	5.5 V	1.67829119442023 A	5.54755043227666 A	1.67829119442023 A	15.5 mm	tin	50	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	20 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M1051618	SDM	Mass Production	polarized	5.5 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	240 mΩ	1 kHz	—	4 µA	5.5 V	0.513059701492537 A	2.02205882352941 A	0.513059701492537 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDS2R7L3561340	SDS	Mass Production	polarized	2.7 V	35 F	-10%~+30%	-40 ~ 70 ℃	1000 h	40 mΩ	1 kHz	—	80 µA	2.7 V	6.65492957746479 A	15.241935483871 A	6.65492957746479 A	5 mm	tin	280	High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量30F参考	12.5 mm	40 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDS2R7L5040609	SDS	Mass Production	polarized	2.7 V	0.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	1200 mΩ	1 kHz	—	2 µA	2.7 V	0.114406779661017 A	0.355263157894737 A	0.114406779661017 A	2.5 mm	tin	1000	High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	6.3 mm	9 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDMH5R5M2552022	SDM(H)	Mass Production	polarized	5.5 V	2.5 F	-10%~+30%	-40 ~ 105 ℃	1000 h	140 mΩ	1 kHz	—	10 µA	5.5 V	1.24434389140271 A	4.50819672131148 A	1.24434389140271 A	15.5 mm	tin	125	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	20 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDMG5R5M2551622	SDM(G)	Mass Production	polarized	5.5 V	2.5 F	-10%~+30%	-40 ~ 85 ℃	1000 h	140 mΩ	1 kHz	—	10 µA	5.5 V	1.24434389140271 A	4.50819672131148 A	1.24434389140271 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDH2R7L3351013	SDH	Mass Production	Polarized	2.7 V	3.3 F	-10%~+30%	-40 ~ 85 ℃	1000 h	70 mΩ	1 kHz	—	8 µA	2.7 V	0.833255400729449 A	3.30857779428147 A	0.833255400729449 A	5 mm	tin	500	RoHS, high capacitance, low ESR, fast charge & discharge, long service life	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	13 mm	✓	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDH2R7L7050825	SDH	Mass Production	Polarized	2.7 V	7 F	-10%~+30%	-40 ~ 85 ℃	1000 h	50 mΩ	1 kHz	—	20 µA	2.7 V	1.710407239819 A	6.19672131147541 A	1.710407239819 A	3.5 mm	tin	400	RoHS, high capacitance, low ESR, fast charge & discharge, long service life	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	25 mm	✓	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDLR2R7L4050820	SDL(R)	Mass Production	polarized	2.7 V	4 F	-10%~+30%	-40 ~ 85 ℃	1000 h	80 mΩ	1 kHz	—	6 µA	2.7 V	0.985401459854015 A	3.64864864864865 A	0.985401459854015 A	3.5 mm	tin	500	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量3.3F参考	8 mm	20 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDLR2R7L3350820	SDL(R)	Mass Production	polarized	2.7 V	3.3 F	-10%~+30%	-40 ~ 85 ℃	1000 h	80 mΩ	1 kHz	—	6 µA	2.7 V	0.825611564121572 A	3.19126074498567 A	0.825611564121572 A	3.5 mm	tin	500	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	20 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDH2R7L7051020	SDH	Mass Production	Polarized	2.7 V	7 F	-10%~+30%	-40 ~ 85 ℃	1000 h	50 mΩ	1 kHz	—	20 µA	2.7 V	1.710407239819 A	6.19672131147541 A	1.710407239819 A	5 mm	tin	250	RoHS, high capacitance, low ESR, fast charge & discharge, long service life	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	20 mm	✓	Apply
Module Type	Electric Double-Layer Supercapacitor	SDMR5R5M2051622	SDM(R)	Mass Production	polarized	5.5 V	2 F	-10%~+30%	-40 ~ 85 ℃	1000 h	140 mΩ	1 kHz	—	6 µA	5.5 V	1.01476014760148 A	3.87323943661972 A	1.01476014760148 A	11.5 mm	tin	250	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1.5F参考	8 mm	16 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDL2R7L6051020	SDL	Mass Production	polarized	2.7 V	6 F	-10%~+30%	-40 ~ 70 ℃	1000 h	50 mΩ	1 kHz	—	10 µA	2.7 V	1.48623853211009 A	5.58620689655173 A	1.48623853211009 A	5 mm	tin	250	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量5F参考	10 mm	20 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDBG3R0L1061320	SDB(G)	Mass Production	polarized	3 V	10 F	-10%~+30%	-40 ~ 85 ℃	1000 h	60 mΩ	1 kHz	—	20 µA	3 V	2.54237288135593 A	7.89473684210526 A	2.54237288135593 A	5 mm	tin	100	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	12.5 mm	20 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDMG5R5M5052025	SDM(G)	Mass Production	polarized	5.5 V	5 F	-10%~+30%	-40 ~ 85 ℃	1000 h	100 mΩ	1 kHz	—	20 µA	5.5 V	2.39130434782609 A	7.85714285714286 A	2.39130434782609 A	15.5 mm	tin	100	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	20 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDH2R7L1561325	SDH	Mass Production	Polarized	2.7 V	15 F	-10%~+30%	-40 ~ 85 ℃	1000 h	30 mΩ	1 kHz	—	40 µA	2.7 V	3.56828193832599 A	12.089552238806 A	3.56828193832599 A	5 mm	tin	100	RoHS, high capacitance, low ESR, fast charge & discharge, long service life	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	12.5 mm	25 mm	✓	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDB3R0L3350622	SDB	Mass Production	polarized	3 V	3.3 F	-10%~+30%	-40 ~ 70 ℃	1000 h	100 mΩ	1 kHz	—	6 µA	3 V	0.900818926296633 A	3.31103678929766 A	0.900818926296633 A	2.5 mm	tin	750	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	6.3 mm	22 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDS2R7L1050609	SDS	Mass Production	polarized	2.7 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	600 mΩ	1 kHz	—	4 µA	2.7 V	0.228813559322034 A	0.710526315789474 A	0.228813559322034 A	2.5 mm	tin	1000	High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	6.3 mm	9 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDH2R7L1050812	SDH	Mass Production	Polarized	2.7 V	1 F	-10%~+30%	-40 ~ 85 ℃	1000 h	160 mΩ	1 kHz	—	4 µA	2.7 V	0.25763358778626 A	1.08870967741935 A	0.25763358778626 A	3.5 mm	tin	500	RoHS, high capacitance, low ESR, fast charge & discharge, long service life	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	11.5 mm	✓	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDB3R0L2050812	SDB	Mass Production	polarized	3 V	2 F	-10%~+30%	-40 ~ 70 ℃	1000 h	160 mΩ	1 kHz	—	4 µA	3 V	0.547445255474453 A	2.02702702702703 A	0.547445255474453 A	3.5 mm	tin	500	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	11.5 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDB3R0L1061022	SDB	Mass Production	polarized	3 V	10 F	-10%~+30%	-40 ~ 70 ℃	1000 h	70 mΩ	1 kHz	—	20 µA	3 V	2.47933884297521 A	7.31707317073171 A	2.47933884297521 A	5 mm	tin	250	High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	22 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SM6R0M5052229	SM	Mass Production	polarized	6 V	5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	100 mΩ	1 kHz	—	20 µA	6 V	2.60869565217391 A	8.57142857142857 A	2.60869565217391 A	15.5 mm	tin	50	Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考	11.5 mm	22 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SM6R0M2552224	SM	Mass Production	polarized	6 V	2.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	10 µA	6 V	1.35746606334842 A	4.91803278688525 A	1.35746606334842 A	15.5 mm	tin	50	Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考	11 mm	21.5 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDS2R7L1561030	SDS	Mass Production	polarized	2.7 V	15 F	-10%~+30%	-40 ~ 70 ℃	1000 h	70 mΩ	1 kHz	—	50 µA	2.7 V	3.07984790874525 A	7.86407766990291 A	3.07984790874525 A	5 mm	tin	150	High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	10 mm	30 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M1262537	SDM	Mass Production	polarized	5.5 V	12.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	50 mΩ	1 kHz	—	44 µA	5.5 V	5.78947368421053 A	17.741935483871 A	5.78947368421053 A	17.5 mm	tin	280	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量10F参考	12.5 mm	25 mm	—	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDLH2R7L2050816	SDL(H)	Mass Production	polarized	2.7 V	2 F	-10%~+30%	-40 ~ 105 ℃	1000 h	120 mΩ	1 kHz	—	4 µA	2.7 V	0.503731343283582 A	1.98529411764706 A	0.503731343283582 A	3.5 mm	tin	500	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	8 mm	16 mm	✓	Apply
Radial Lead	Electric Double-Layer Supercapacitor	SDLG2R7L1861325	SDL（G）	Mass Production	polarized	2.7 V	18 F	-10%~+30%	-40 ~ 85 ℃	1000 h	28 mΩ	1 kHz	—	40 µA	2.7 V	4.22168172341904 A	13.8382687927107 A	4.22168172341904 A	5 mm	tin	100	EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量20F参考	12.5 mm	25 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M3052624	SDM	Mass Production	polarized	5.5 V	3 F	-10%~+30%	-40 ~ 70 ℃	1000 h	140 mΩ	1 kHz	—	10 µA	5.5 V	1.46536412078153 A	5.06134969325153 A	1.46536412078153 A	9 mm	tin	50	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量2.5F参考	6.5 mm	26 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M1051317	SDM	Mass Production	polarized	5.5 V	1 F	-10%~+30%	-40 ~ 70 ℃	1000 h	240 mΩ	1 kHz	—	4 µA	5.5 V	0.513059701492537 A	2.02205882352941 A	0.513059701492537 A	9 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算	6.3 mm	13 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M7541315	SDM	Mass Production	polarized	5.5 V	0.75 F	-10%~+30%	-40 ~ 70 ℃	1000 h	240 mΩ	1 kHz	—	4 µA	5.5 V	0.391366223908918 A	1.6240157480315 A	0.391366223908918 A	9 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考	6.3 mm	13 mm	—	Apply
Module Type	Electric Double-Layer Supercapacitor	SDM5R5M5041312	SDM	Mass Production	polarized	5.5 V	0.5 F	-10%~+30%	-40 ~ 70 ℃	1000 h	600 mΩ	1 kHz	—	2 µA	5.5 V	0.252293577981651 A	0.948275862068966 A	0.252293577981651 A	9 mm	tin	500	High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP)	ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量0.47F参考	6.3 mm	13 mm	—	Apply

1…4 5 6…14
