Found 670 results
| Compare | Package Form | Product Image | Product Line | Lifecycle Status | Polarity | Tolerance | Operating Temp. (℃) | Rated Life (Hours) | ESR (max.) | ESR Frequency | Rated Ripple Current | 72h Leakage Current (μA) | Max Charge Voltage (V) | Max Charge Current (A) | Peak Current (A) | Continuous Current (A) | Terminal Pitch (mm) | Terminal Material | Weight | Min. Package Qty | Feature Tags | Remark | Dimension L (mm) | AEC-Q200 | 3D-CAD | ||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM27V107FREA | SLM | Mass Production | 有极性 | 27 V | 107 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 195 mΩ | 1 kHz | 0 mArms | 20 µA | 28 V | 5 A | 10 A | 5 A | 7.2 mm | 铜 | 180 g | 15 | — | — | 48 mm | 95 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM27V107FREB | SLM | Mass Production | 有极性 | 27 V | 107 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 195 mΩ | 1 kHz | 0 mArms | 20 µA | 28 V | 10 A | 20 A | 10 A | 7.2 mm | 铜 | 180 g | 15 | — | — | 48 mm | 95 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM27V107FRYA | SLM | Mass Production | 有极性 | 27 V | 107 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 195 mΩ | 1 kHz | 0 mArms | 20 µA | 28 V | 10 A | 20 A | 10 A | 0 mm | 锡 | 180 g | 15 | — | — | 48 mm | 95 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM27V1257FREA | SLM | Mass Production | 有极性 | 27 V | 1257 F | 0%~+20% | -40 ~ 70 ℃ | 1000 h | 20 mΩ | 1 kHz | 0 mArms | 160 µA | 28 V | 10 A | 20 A | 10 A | 7.2 mm | 铜 | 1650 g | 1 | — | — | 133 mm | 180 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM28V27.7FRDA | SLM | Mass Production | 有极性 | 28 V | 27.7 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 500 mΩ | 1 kHz | 0 mArms | 15 µA | 36 V | 0.8 A | 6 A | 0.8 A | 7.2 mm | 铜 | 140 g | 25 | — | — | 41 mm | 50 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM28V35.7FREA | SLM | Mass Production | 有极性 | 28 V | 35.7 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 400 mΩ | 1 kHz | 0 mArms | 15 µA | 28 V | 0.8 A | 6 A | 0.8 A | 7.2 mm | 铜 | 130 g | 25 | — | — | 41 mm | 50 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM34V27.7FREA | SLM | Mass Production | 有极性 | 34 V | 27.7 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 500 mΩ | 1 kHz | 0 mArms | 15 µA | 36 V | 0.8 A | 6 A | 0.8 A | 7.2 mm | 铜 | 140 g | 25 | — | — | 41 mm | 50 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM48V11.5FRDA | SLM | Mass Production | 有极性 | 48 V | 11.5 F | -10%~+30% | -20 ~ 85 ℃ | 1000 h | 1500 mΩ | 1 kHz | 0 mArms | 10 µA | 60 V | 0.6 A | 3 A | 0.6 A | 7.2 mm | 铜 | 160 g | 24 | — | — | 44 mm | 50 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM56V40WHTDA | SLM | Mass Production | 有极性 | 56 V | 40 F | 0%~+30% | -20 ~ 70 ℃ | 1000 h | 135 mΩ | 1 kHz | 0 mArms | 50 µA | 64 V | 10 A | 40 A | 10 A | 60 mm | 铜 | 8000 g | 2 | — | — | 336 mm | 480 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM64V40WHTDB | SLM | Mass Production | 有极性 | 64 V | 40 F | 0%~+30% | -20 ~ 70 ℃ | 1000 h | 140 mΩ | 1 kHz | 0 mArms | 50 µA | 64 V | 10 A | 40 A | 10 A | 60 mm | 铜 | 8200 g | 2 | — | — | 480 mm | 500 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM64V40WHTDC | SLM | Mass Production | 有极性 | 64 V | 40 F | 0%~+30% | -20 ~ 70 ℃ | 1000 h | 140 mΩ | 1 kHz | 0 mArms | 50 µA | 64 V | 10 A | 40 A | 10 A | 60 mm | 铜 | 8100 g | 2 | — | — | 336 mm | 480 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM7.6V1100FREA | SLM | Mass Production | 有极性 | 7.6 V | 1100 F | 0%~+30% | -40 ~ 70 ℃ | 1000 h | 140 mΩ | 1 kHz | 0 mArms | 40 µA | 8.1 V | 6 A | 9 A | 6 A | 2 mm | 铜 | 108 g | 28 | — | — | 38 mm | 41 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM7.6V3300FRCA | SLM | Mass Production | 有极性 | 7.6 V | 3300 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 110 mΩ | 1 kHz | 0 mArms | 70 µA | 8.1 V | 6 A | 9 A | 6 A | 2 mm | 铜 | 350 g | 10 | — | — | 56 mm | 92 mm | — | — | Apply | |
| Custom Module | — | Electric Double-Layer Supercapacitor | SLM7.6V3300FREA | SLM | Mass Production | 有极性 | 7.6 V | 3300 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 110 mΩ | 1 kHz | 0 mArms | 70 µA | 8.1 V | 6 A | 9 A | 6 A | 2 mm | 铜 | 350 g | 10 | — | — | 56 mm | 92 mm | — | — | Apply | |
| Module Type |  | Electric Double-Layer Supercapacitor | SDM7R5M5053827 | SDM | Mass Production | polarized | 7.5 V | 5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 100 mΩ | 1 kHz | 0 mArms | 30 µA | 7.5 V | 3.26086956521739 A | 10.7142857142857 A | 3.26086956521739 A | 31 mm | tin | 15 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 12.5 mm | 37.5 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM7R5M3053822 | SDM | Mass Production | polarized | 7.5 V | 3 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 140 mΩ | 1 kHz | 0 mArms | 20 µA | 7.5 V | 1.99822380106572 A | 6.90184049079755 A | 1.99822380106572 A | 31 mm | tin | 15 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 12.5 mm | 37.5 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM7R5M2253022 | SDM | Mass Production | polarized | 7.5 V | 2.2 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 140 mΩ | 1 kHz | 0 mArms | 10 µA | 7.5 V | 1.51043573782497 A | 5.64295485636115 A | 1.51043573782497 A | 25 mm | tin | 10 g | 100 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 10 mm | 30 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM7R5M1553022 | SDM | Mass Production | polarized | 7.5 V | 1.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 200 mΩ | 1 kHz | 0 mArms | 10 µA | 7.5 V | 1.03211009174312 A | 3.87931034482759 A | 1.03211009174312 A | 25 mm | tin | 10 g | 100 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 10 mm | 30 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM7R5M1052422 | SDM | Mass Production | polarized | 7.5 V | 1 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 240 mΩ | 1 kHz | 0 mArms | 6 µA | 7.5 V | 0.699626865671642 A | 2.75735294117647 A | 0.699626865671642 A | 20 mm | tin | 8 g | 150 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 8 mm | 24 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM7R5M6042414 | SDM | Mass Production | polarized | 7.5 V | 0.6 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 600 mΩ | 1 kHz | 0 mArms | 2 µA | 7.5 V | 0.406137184115523 A | 1.46103896103896 A | 0.406137184115523 A | 20 mm | tin | 3 g | 150 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 8 mm | 24 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM7R5M3342414 | SDM | Mass Production | polarized | 7.5 V | 0.33 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 800 mΩ | 1 kHz | 0 mArms | 2 µA | 7.5 V | 0.229336545589325 A | 0.886461318051576 A | 0.229336545589325 A | 20 mm | tin | 3 g | 150 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 8 mm | 24 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM9R0M1052422 | SDM | Mass Production | polarized | 9 V | 1 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 240 mΩ | 1 kHz | 0 mArms | 4 µA | 9 V | 0.83955223880597 A | 3.30882352941176 A | 0.83955223880597 A | 20 mm | tin | 5 g | 150 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 8 mm | 24 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM9R0M3342414 | SDM | Mass Production | polarized | 9 V | 0.33 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 800 mΩ | 1 kHz | 0 mArms | 2 µA | 9 V | 0.275203854707191 A | 1.06375358166189 A | 0.275203854707191 A | 20 mm | tin | 3 g | 150 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 8 mm | 24 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM9R0M6042418 | SDM | Mass Production | polarized | 9 V | 0.6 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 600 mΩ | 1 kHz | 0 mArms | 2 µA | 9 V | 0.487364620938628 A | 1.75324675324675 A | 0.487364620938628 A | 20 mm | tin | 4 g | 150 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR shall be referenced to the 2026 catalog for the same series with identical or adjacent capacitance and dimensions; current shall be calculated per catalog values or the formula in Appendix 1 | 8 mm | 24 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDS2R7L2240509 | SDS | Mass Production | polarized | 2.7 V | 0.22 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 1200 mΩ | 1 kHz | 0 mArms | 2 µA | 2.7 V | 0.0550407709414381 A | 0.212750716332378 A | 0.0550407709414381 A | 2 mm | tin | 0 g | 1000 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量0.5F参考 | 5 mm | 9 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDBG3R0L3350820 | SDB(G) | Mass Production | polarized | 3 V | 3.3 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 100 mΩ | 1 kHz | 0 mArms | 6 µA | 3 V | 0.900818926296633 A | 3.31103678929766 A | 0.900818926296633 A | 3.5 mm | tin | 0 g | 500 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 20 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L1050512 | SDS | Mass Production | polarized | 2.7 V | 1 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 600 mΩ | 1 kHz | 0 mArms | 4 µA | 2.7 V | 0.228813559322034 A | 0.710526315789474 A | 0.228813559322034 A | 2 mm | tin | 0 g | 2100 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 5 mm | 12 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDLG2R7L1061320 | SDL（G） | Mass Production | polarized | 2.7 V | 10 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 35 mΩ | 1 kHz | 0 mArms | 20 µA | 2.7 V | 2.44343891402715 A | 8.85245901639344 A | 2.44343891402715 A | 5 mm | tin | 0 g | 100 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 20 mm | — | Apply | ||
| Module Type |  | Electric Double-Layer Supercapacitor | SM6R0M1551824 | SM | Mass Production | polarized | 6 V | 1.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 200 mΩ | 1 kHz | 0 mArms | 6 µA | 6 V | 0.825688073394495 A | 3.10344827586207 A | 0.825688073394495 A | 11.5 mm | tin | 0 g | 750 | Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考 | 9.5 mm | 18 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM6R0M1551622 | SDM | Mass Production | polarized | 6 V | 1.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 200 mΩ | 1 kHz | 0 mArms | 6 µA | 6 V | 0.825688073394495 A | 3.10344827586207 A | 0.825688073394495 A | 11.5 mm | tin | 0 g | 250 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM5R5M1551324 | SDM | Mass Production | polarized | 5.5 V | 1.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 200 mΩ | 1 kHz | 0 mArms | 6 µA | 5.5 V | 0.756880733944954 A | 2.8448275862069 A | 0.756880733944954 A | 9 mm | tin | 0 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 6.3 mm | 13 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDLG2R7L7051020 | SDL（G） | Mass Production | polarized | 2.7 V | 7 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 50 mΩ | 1 kHz | 0 mArms | 14 µA | 2.7 V | 1.710407239819 A | 6.19672131147541 A | 1.710407239819 A | 5 mm | tin | 0 g | 100 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 20 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDB3R0L1561040 | SDB | Mass Production | polarized | 3 V | 15 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 50 mΩ | 1 kHz | 0 mArms | 30 µA | 3 V | 3.6734693877551 A | 10.5882352941176 A | 3.6734693877551 A | 5 mm | tin | 0 g | 280 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 40 mm | — | Apply | ||
| Radial Lead |  | Electric Double-Layer Supercapacitor | SDLH2R7L5051020 | SDL(H) | Mass Production | polarized | 2.7 V | 5 F | -10%~+30% | -40 ~ 105 ℃ | 1000 h | 60 mΩ | 1 kHz | 0 mArms | 10 µA | 2.7 V | 1.23853211009174 A | 4.6551724137931 A | 1.23853211009174 A | 5 mm | tin | 0 g | 250 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 20 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDLG2R7L1061025 | SDL（G） | Mass Production | polarized | 2.7 V | 10 F | 0%~+30% | -40 ~ 85 ℃ | 1000 h | 40 mΩ | 1 kHz | 0 mArms | 20 µA | 2.7 V | 2.41071428571429 A | 8.4375 A | 2.41071428571429 A | 5 mm | tin | 0 g | 200 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 25 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L3040409 | SDB | Mass Production | polarized | 3 V | 0.3 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 240 mΩ | 1 kHz | 0 mArms | 3 µA | 3 V | 0.0880971025841817 A | 0.406137184115523 A | 0.0880971025841817 A | 1.5 mm | tin | 0 g | 1000 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量1F参考 | 4 mm | 9 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDLG2R7L2050813 | SDL（G） | Mass Production | polarized | 2.7 V | 2 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 120 mΩ | 1 kHz | 0 mArms | 4 µA | 2.7 V | 0.503731343283582 A | 1.98529411764706 A | 0.503731343283582 A | 3.5 mm | tin | 0 g | 500 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 13 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SM5R5M5031213 | SM | Mass Production | polarized | 5.5 V | 0.05 F | 0%~+80% | -40 ~ 70 ℃ | 1000 h | 1200 mΩ | 1 kHz | 0 mArms | 2 µA | 5.5 V | 0.0270137524557957 A | 0.126146788990826 A | 0.0270137524557957 A | 7 mm | tin | 0 g | 150 | Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考 | 6.5 mm | 11.5 mm | — | Apply | ||
| Module Type |  | Electric Double-Layer Supercapacitor | SMR5R5M1551824 | SM(R) | Mass Production | polarized | 5.5 V | 1.5 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 200 mΩ | 1 kHz | 0 mArms | 6 µA | 5.5 V | 0.756880733944954 A | 2.8448275862069 A | 0.756880733944954 A | 11.5 mm | tin | 0 g | 750 | Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考 | 9.5 mm | 18 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDH2R7L1050813 | SDH | Mass Production | Polarized | 2.7 V | 1 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 160 mΩ | 1 kHz | 0 mArms | 4 µA | 2.7 V | 0.25763358778626 A | 1.08870967741935 A | 0.25763358778626 A | 3.5 mm | tin | 0 g | 500 | RoHS, high capacitance, low ESR, fast charge & discharge, long service life | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 13 mm | ✓ | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L1061025 | SDB | Mass Production | polarized | 3 V | 10 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 70 mΩ | 1 kHz | 0 mArms | 20 µA | 3 V | 2.47933884297521 A | 7.31707317073171 A | 2.47933884297521 A | 5 mm | tin | 0 g | 250 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 25 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L3350813 | SDB | Mass Production | polarized | 3 V | 3.3 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 100 mΩ | 1 kHz | 0 mArms | 6 µA | 3 V | 0.900818926296633 A | 3.31103678929766 A | 0.900818926296633 A | 3.5 mm | tin | 0 g | 500 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 13 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDL2R7L4050820 | SDL | Mass Production | polarized | 2.7 V | 4 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 80 mΩ | 1 kHz | 0 mArms | 6 µA | 2.7 V | 0.985401459854015 A | 3.64864864864865 A | 0.985401459854015 A | 3.5 mm | tin | 0 g | 500 | EDLC (Electric Double Layer Capacitor), Polarized, Leaded, High Capacity, Ultra Low ESR, Fast Charge & Discharge, Low Self-discharge, Short-time High Current Output, Smart Meter, Industrial Power Supp | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量3.3F参考 | 8 mm | 20 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SDM5R5M7552527 | SDM | Mass Production | polarized | 5.5 V | 7.5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 60 mΩ | 1 kHz | 0 mArms | 30 µA | 5.5 V | 3.63436123348018 A | 12.3134328358209 A | 3.63436123348018 A | 17.5 mm | tin | 0 g | 50 | High Energy Density, High Power Output, Low ESR, Low Leakage Current, Long Cycle Life, Polarized, Smart Instrument, Server Power-loss Protection (PLP) | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 25 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SM5R5M4741414 | SM | Mass Production | polarized | 5.5 V | 0.47 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 400 mΩ | 1 kHz | 0 mArms | 2 µA | 5.5 V | 0.244698977659977 A | 1.0081903276131 A | 0.244698977659977 A | 9 mm | tin | 0 g | 750 | Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考 | 8 mm | 14 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDBG3R0L2050816 | SDB(G) | Mass Production | polarized | 3 V | 2 F | -10%~+30% | -40 ~ 85 ℃ | 1000 h | 160 mΩ | 1 kHz | 0 mArms | 4 µA | 3 V | 0.547445255474453 A | 2.02702702702703 A | 0.547445255474453 A | 3.5 mm | tin | 0 g | 500 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 8 mm | 16 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SM5R5M5052229 | SM | Mass Production | polarized | 5.5 V | 5 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 100 mΩ | 1 kHz | 0 mArms | 20 µA | 5.5 V | 2.39130434782609 A | 7.85714285714286 A | 2.39130434782609 A | 15.5 mm | tin | 0 g | 800 | Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考 | 11.5 mm | 22 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDS2R7L1561025 | SDS | Mass Production | polarized | 2.7 V | 15 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 70 mΩ | 1 kHz | 0 mArms | 50 µA | 2.7 V | 3.07984790874525 A | 7.86407766990291 A | 3.07984790874525 A | 5 mm | tin | 0 g | 250 | High Energy Density, Long Cycle Life, Low Self-discharge, Wide Temperature Range, Fast Charge & Discharge, Polarized, Leaded | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 10 mm | 25 mm | — | Apply | ||
| Module Type | | Electric Double-Layer Supercapacitor | SM5R5M4741816 | SM | Mass Production | polarized | 5.5 V | 0.47 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 400 mΩ | 1 kHz | 0 mArms | 2 µA | 5.5 V | 0.244698977659977 A | 1.0081903276131 A | 0.244698977659977 A | 11.5 mm | tin | 0 g | 750 | Polarized, High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Wide Temperature Range, Reflow Soldering Available, Smart Water Meter, Smart Gas Meter | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算；漏电流按附件三同系列邻近容量NoneF参考 | 9.5 mm | 17.5 mm | — | Apply | ||
| Radial Lead | | Electric Double-Layer Supercapacitor | SDB3R0L2061330 | SDB | Mass Production | polarized | 3 V | 20 F | -10%~+30% | -40 ~ 70 ℃ | 1000 h | 40 mΩ | 1 kHz | 0 mArms | 40 µA | 3 V | 4.83870967741935 A | 13.6363636363636 A | 4.83870967741935 A | 5 mm | tin | 0 g | 100 | High Capacity, Low ESR, Low Self-discharge, Long Cycle Life, Leaded, Polarized | ESR参考2026目录同系列同/邻近容量尺寸；电流按目录值或附件一公式计算 | 12.5 mm | 30 mm | — | Apply |
