liquid aluminum electrolytic capacitor
VKLL1651V821MVTMCG
Mass ProductionVKL Series · SMD
Low Leakage CurrentHigh Temp ResistantLong Life @ High TempHigh Ripple Current
Rated Voltage (V)
35 V
Nominal Capacitance
820 µF
Operating Temp
-40 ~ 125 ℃
ESR (max)
—
Rated Lifetime
3000 h
Package Size
ø12.5 × 16.5 mm
Online Store
Min. Order Qty:200
Package:SMD
No online store link available for this part number
Detailed Specifications
Capacitor Categoryliquid aluminum electrolytic capacitor
ShapeSMD
Part NumberVKLL1651V821MVTMCG
SeriesVKL
Lifecycle StatusMass Production
Rated Voltage (V)35
Nominal Capacitance820 µF
ESR (max.)—
PolarityPolarized
Min Operating Temp (°C)-40
Max Operating Temp (°C)125
Rated Lifetime (Hours)3000
Rated Ripple Current1800 mArms
ESR Frequency100 kHz
Diameter D (mm)12.5
Height L (mm)16.5
Terminal Pitch (mm)4.6±0.2
Min. Package Qty200
Tolerance-20%~+20%
Leakage Current (µA) Max287
Dissipation Factor (tanδ max.)16
Terminal Plating Materialtin
Weight (g)0.1
Dissipation Factor Frequency (Hz)120
Remarks—
Product Dimensions & Electrical Parameters
Actual dimensions and electrical parameters for this part number
Dimensions (unit: mm)
| Dimension | Symbol | Value (mm) |
|---|---|---|
| Diameter (D) | D | 12.5 |
| Height (L) | L | 16.5 |
Electrical Parameters
| Rated Ripple Current | Ripple Test Condition | ESR | ESR Frequency |
|---|---|---|---|
| 1800 mArms | — | — | 100 kHz |
Design Tools & Resources
Lifetime Calculator
Online lifetime estimation
3D-CAD Models
STEP / IGES
RoHS/REACH
Compliance certificates
Product PDF
Product datasheet
Cross Reference
The current YMIN part can replace these competitor parts. Verify specifications and application conditions before selection.
Loading cross references…
For replacement options of discontinued models, please contact technical support.
