liquid aluminum electrolytic capacitor
VKL(U)E1301J121MVTMCG
Mass ProductionVKL(U) Series · SMD
Low Leakage CurrentHigh Temp ResistantLong Life @ High TempHigh Ripple Current
Rated Voltage (V)
63 V
Nominal Capacitance
120 µF
Operating Temp
-40 ~ 125 ℃
ESR (max)
—
Rated Lifetime
5000 h
Package Size
ø10 × 13 mm
Online Store
Min. Order Qty:400
Package:SMD
No online store link available for this part number
Detailed Specifications
Capacitor Categoryliquid aluminum electrolytic capacitor
ShapeSMD
Part NumberVKL(U)E1301J121MVTMCG
SeriesVKL(U)
Lifecycle StatusMass Production
Rated Voltage (V)63
Nominal Capacitance120 µF
ESR (max.)—
PolarityPolarized
Min Operating Temp (°C)-40
Max Operating Temp (°C)125
Rated Lifetime (Hours)5000
Rated Ripple Current590 mArms
ESR Frequency100 kHz
Diameter D (mm)10
Height L (mm)13
Terminal Pitch (mm)4.6±0.2
Min. Package Qty400
Tolerance-20%~+20%
Leakage Current (µA) Max75.6
Dissipation Factor (tanδ max.)14
Terminal Plating Materialtin
Weight (g)0.1
Dissipation Factor Frequency (Hz)120
Remarks—
Product Dimensions & Electrical Parameters
Actual dimensions and electrical parameters for this part number
Dimensions (unit: mm)
| Dimension | Symbol | Value (mm) |
|---|---|---|
| Diameter (D) | D | 10 |
| Height (L) | L | 13 |
Electrical Parameters
| Rated Ripple Current | Ripple Test Condition | ESR | ESR Frequency |
|---|---|---|---|
| 590 mArms | — | — | 100 kHz |
