liquid aluminum electrolytic capacitor
V3MA0541H1R0MVTMCG
Mass ProductionV3M Series · SMD
Low ESRLow Impedance at High FrequencyHigh Ripple CurrentMiniature SizeHigh Capacitance DensityWide Temperature RangeRoHS Compliant
Rated Voltage (V)
50 V
Nominal Capacitance
1 µF
Operating Temp
-55 ~ 105 ℃
ESR (max)
15.8 Ω
Rated Lifetime
2000 h
Package Size
ø4 × 5.4 mm
Online Store
Min. Order Qty:2000
Package:SMD
No online store link available for this part number
Detailed Specifications
Capacitor Categoryliquid aluminum electrolytic capacitor
ShapeSMD
Part NumberV3MA0541H1R0MVTMCG
SeriesV3M
Lifecycle StatusMass Production
Rated Voltage (V)50
Nominal Capacitance1 µF
ESR (max.)15.8 Ω
PolarityPolarized
Min Operating Temp (°C)-55
Max Operating Temp (°C)105
Rated Lifetime (Hours)2000
Rated Ripple Current20 mArms
ESR Frequency100 kHz
Diameter D (mm)4
Height L (mm)5.4
Terminal Pitch (mm)1.0±0.2
Min. Package Qty2000
Tolerance-20%~+20%
Leakage Current (µA) Max3
Dissipation Factor (tanδ max.)12
Terminal Plating Materialtin
Weight (g)—
Dissipation Factor Frequency (Hz)120
Remarks—
Product Dimensions & Electrical Parameters
Actual dimensions and electrical parameters for this part number
Dimensions (unit: mm)
| Dimension | Symbol | Value (mm) |
|---|---|---|
| Diameter (D) | D | 4 |
| Height (L) | L | 5.4 |
Electrical Parameters
| Rated Ripple Current | Ripple Test Condition | ESR | ESR Frequency |
|---|---|---|---|
| 20 mArms | — | 15.8 Ω | 100 kHz |
